N S T A L L A T I O N
I
N S T R U C T I O N S
For Superior's
TM And TMC
Series Fireplace
Models
TM-4500
And TMC-4500
SUPERIOR
The Fireplace Company
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
This installation manual will enable you to ob-
tain a safe, efficient and dependable installation
of your fireplace system. Please read and un-
derstand these instructions before beginning
your installation.
Do not alter or modify the fireplace or its
components under any circumstances. Any
modification or alteration of the fireplace sys-
tem, including but not limited to the fireplace,
chimney components and accessories, may
void the warranty, listings and approvals of this
system and could result in an unsafe and poten-
tially dangerous installation.
PLEASE RETAIN THIS MANUAL FOR FUTURE
REFERENCE.
Warnock Hersey
Report No. 620-1058A
®
