Using The Footswitch - Voodoo Lab Guitar Preamp Owner's Manual

Your Preamp comes equipped with a footswitch for channel selection. To use it, simply plug the
jack from the captured cord into the footswitch jack on the back panel. Plugging into this jack dis-
ables the channel select switches on the front panel.
SWITCHING CHANNELS WITH A GCX AUDIO SWITCHER
You can also switch the channels of your Guitar Preamp with an external switching device like the
Digital Music GCX Guitar Audio Switcher. In order to do this you will need an insert point cable,
which goes from a stereo
jacks will be ring/sleeve and the other will be tip/sleeve. You will need to have two loops open in
your GCX to switch channels.
Take the stereo end of the cable and plug it into the Footswitch jack on the back panel. Then tale the
two mono ends and plug them into the OUT/N.O. jacks of two free GCX loops like this:
FOOTSWITCH DIRECT OUT
T I P / S L E E V E R I N G / S L E E V E
When Loop 3 is open and Loop 4 is closed, the Clean channel will be selected. When both loops are
closed the Rhythm channel will be selected, and when Loop 3 is closed and Loop 4 is open the
Lead channel will be selected.
6

USING THE FOOTSWITCH

1
⁄ " plug on one end to two mono
4
PREAMP OUT
G C X A U D I O S W I T C H E R
1
⁄ " plugs on the other. One of the mono
4
To prevent electrical shock, do not remove cover.
No user serviceable parts inside. Refer servicing
GUITAR PREAMP
to qualified service personnel.
MADE IN U.S.A.
AC IN (100W MAX)
CAUTION
1 ⁄ "
4
FUSE
F U S E
1 AMP
