Voodoo Lab Guitar Preamp Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PREAMP MANUAL
OWNER'S MANUAL
D I G I T A L M U S I C C O R P O R A T I O N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Guitar Preamp and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Voodoo Lab Guitar Preamp

  • Page 1 PREAMP MANUAL OWNER’S MANUAL D I G I T A L M U S I C C O R P O R A T I O N...

  • Page 2: Safety Precautions

    INTRODUCTION Congratulations on your choice of product! The three channel, all tube Voodoo Lab Guitar Preamp was designed to be simply the most effective and organic direct recording tool available for guitar, as well as a centerpiece to the live rig of any tone connoisseur. Careful attention was paid in the design stage to provide tighter and more even bass response than you find in many vintage circuits, with an emphasis on string definition and picking dynamics.

  • Page 3: Front Panel

    BASS GAIN VOLUME VOLUME TREBLE BASS GAIN GAIN INPUT CABINET CHANNEL SIMULATOR SELECT GUITAR PREAMP OPEN PUNCH BRIGHT CLEAN RHYTHM SHIFT BRIGHT BRIGHT CLOSED LEAD 11 12 1. Power switch 2. Cabinet Simulator – In/Out 3. Cabinet Simulator – 2x12 Open/4x12 Closed 4.

  • Page 4: Back Panel

    PREAMP OUT FUSE CAUTION F U S E To prevent electrical shock, do not remove cover. No user serviceable parts inside. Refer servicing GUITAR PREAMP to qualified service personnel. MADE IN U.S.A. 1 AMP 1. Footswitch Jack – ⁄ " TRS input jack for footswitch 2.
  • Page 5 FUSE CAUTION FUSE To prevent electrical shock, do not remove cover. No user serviceable parts inside. Refer servicing GUITAR PREAMP to qualified service personnel. MADE IN U.S.A. 1 AMP C A B I N E T C A B I N E T...
  • Page 6 CAUTION FUSE To prevent electrical shock, do not remove cover. No user serviceable parts inside. Refer servicing GUITAR PREAMP to qualified service personnel. MADE IN U.S.A. 1 AMP A M P L I F I E R H E A D...

  • Page 7: Using The Footswitch

    SWITCHING CHANNELS WITH A GCX AUDIO SWITCHER You can also switch the channels of your Guitar Preamp with an external switching device like the Digital Music GCX Guitar Audio Switcher. In order to do this you will need an insert point cable, which goes from a stereo ⁄...

  • Page 8: Operation

    OPERATION Your Guitar Preamp is designed to bring the warmth of an all tube signal path to any musical situation. Here is a brief description of the character of each channel: CLEAN CHANNEL The Clean channel is modeled after the legendary “black face era” American amps of the mid-60’s.

  • Page 9: Warranty

    RMA and given shipping and packaging instructions. HOW TO REACH US You can reach us by any of the following: Tel: 707 545 0600 Fax: 707 545 9777 Mail: Voodoo Lab 3165 Coffey Lane, Santa Rosa, CA 95403 Email: info@voodoolab.com Website: www.voodoolab.com...
