750 WATT Power Inverter
Converts 12V DC Vehicle Power to 120V AC
IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR
PURCHASE CALL TOLL FREE (866) 584-5504. IN MOST
CASES A SERVICE REPRESENTATIVE CAN RESOLVE YOUR
KEY INFORMATION YOU
SHOULD KNOW:
• Supplies 750 watts of
continuous power
• Runs most household or
electronic appliances
• Automatic shutdown
• Low battery alarm
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ
CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE.
4140 S.W. 28th Way, Ft. Lauderdale, FL 33312
Household Power
PROBLEM OVER THE PHONE.
OWNER'S MANUAL AND
WARRANTY INFORMATION
Toll Free: (866) 584-5504
HSK065HD

Advertisement

Table of Contents
loading

Related Manuals for Husky HSK065HD

Summary of Contents for Husky HSK065HD

  • Page 1 HSK065HD 750 WATT Power Inverter Converts 12V DC Vehicle Power to 120V AC Household Power IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR PURCHASE CALL TOLL FREE (866) 584-5504. IN MOST CASES A SERVICE REPRESENTATIVE CAN RESOLVE YOUR PROBLEM OVER THE PHONE.

  • Page 2: Table Of Contents

    1. INTRODUCTION ....................4 2. CONTROLS, INDICATORS AND CONNECTORS ..........4 3.HOW YOUR INVERTER WORKS ..............5 3.1 Principal of Operation ................5 3.2 The Husky Power Inverter Output Waveform ..........5 4. INSTALLATION ......................6 4.1 Power Source Requirements ...............6 4.2 Connection to Power Source...............6 4.3 Connection to Load..................7...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS To ensure reliable service, your power inverter must be installed and used properly. Please read the installation and operating instructions thoroughly prior to installation and use. Pay particular attention to the WARNING and CAUTION statements in this manual.

  • Page 4: Introduction

    INTRODUCTION Your new Husky Power Inverter is one in a series of the most advanced DC to AC inverters available. With proper care and appropriate usage, it will give you years of dependable service in your car, truck, RV or boat.

  • Page 5: How Your Inverter Works

    3.2 THE OUTPUT WAVEFORM The AC output waveform of the Husky Power Inverter is known as “modified sine wave”. It is a waveform that has characteristics similar to the sine wave shape of utility power. This type of waveform is suitable for most AC loads, including linear and switching power supplies used in electronic equipment, transformers, and motors.

  • Page 6: Installation

    Use the provided cables to connect the Husky Power Inverter directly to the 12 volt power source using the following guidelines: 1. Check to be sure the Husky Power Inverter power is turned off and that no flammable fumes are present.

  • Page 7: Connection To Load

    The inverter should only be used in locations that meet the following criteria: DRY - Do not allow water and/or other liquids to come into contact with the Husky Power Inverter inverter. VENTILATED - Keep the area surrounding the inverter clear to ensure free air...

  • Page 8: Operating Tips

    750 watts or less. The inverter will shut down if it is overloaded. The overload must be removed before the inverter will restart. Resistive loads are the easiest for the Husky Power Inverter to run. However, larger resistive loads, such as electric stoves or heaters, usually require more wattage than the Husky Power Inverter can deliver on a continuous basis.

  • Page 9: Common Problems

    When the condition is corrected, the unit may be restarted. Over Voltage Protection - The Husky Power Inverter will automatically shut down when the input voltage exceeds 15.5 volts DC. Short Circuit Protection - Reverse polarity or short circuit condition may cause external or internal fuses to open and may cause irreversible damage to the inverter.

  • Page 10: Fuse Replacement

    Internal fuses are replaceable, however, only electronically knowledgeable people should attempt fuse replacement. If the unit is damaged during fuse replacement, the warranty may be voided. Husky recommends contacting Technical Support for guidance. Call toll free: (866) 584-5504. 10. SPECIFICATIONS Output Connection .

  • Page 11: Warranty

    HUSKY 2-YEAR LIMITED WARRANTY PROGRAM The Home Depot warrants this Husky Power Product to the original user to be free from defects in materials and workmanship for a period of two years from the date of purchase. If you believe that this...
