  • Page 1 BEDIENUNGS- UND MONTAGEANWEISUNG GB INSTRUCTIONS FOR ASSEMBLY AND USE GR ΟΓΗΓΙΔ΢ ΥΔΙΡΙ΢ΜΟΤ ΚΑΙ ΢ΤΝΑΡΜΟΛΟΓΗ΢Η΢ KD7580.0GE KD9970.0GE KD9960.0GE KD9580.0GE...
  • Page 4: Table Of Contents

    CONTENTS General Contents Your appliance data Safety Instructions Installation Assembly instructions Electrical connection Other assembly instructions and tips Dimensioned drawings Assembly instructions Operation Switching your appliance on / off Power controls Automatic delayed stop Switching the lamp on / off Dimmer function Filter saturation display Remote control...
  • Page 5: Your Appliance Data

    Please note: We require the following details for your request for customer service so that our customer service technicians can be well-prepared to carry out repairs and have the required spare parts available: Your exact address Your telephone number and, if available, fax number When can customer service call? An exact appliance designation: model no.
  • Page 6: Safety Instructions

    Safety Instructions This appliance complies with valid safety regulations. Improper handling may cause damage to property and injury to persons. Please read these instructions carefully before installing your appliance and using it. It contains important information and tips on assembly, safety and maintenance. Information concerning structural requirements The following instructions must be observed when cooker hoods are used in the extraction mode:...
  • Page 7 Safety instructions for assembly and use The metal grease filters must always be in place when the cooker hood is in operation. Greasy vapours may otherwise be deposited in the hood and in the extraction air system. In the case of gas cookers it is important to ensure that the cooking zones are not operated without any cookware.
  • Page 8: Installation

    INSTALLATION Depending on the model, a minimum clearance of 40-65 cm must be maintained between an electric hob and the bottom of the cooker hood when installing the hood. A minimum clearance of 55-70 cm must be maintained for gas hobs (Fig. 1). Fig.
  • Page 9: Other Assembly Instructions And Tips

    Other important information In order to make sure that ventilation is optimal and that the hood operates quietly, the extraction air system, including the wall box, must be at least 150 mm in diameter. Please observe the following when installing the exhaust air pipe: Use short, straight exhaust air ducts Use as few pipe bends as possible Use only smooth pipes...
  • Page 10: Dimensioned Drawings

    KD9580.0GE / KD7580.0GE dimensioned drawing KD9580.0GE / KD7580.0GE dimensioned drawing of installation dimensions (back view)
  • Page 11 KD9970.0GE dimensioned drawing KD9970.0GE dimensioned drawing of installation dimensions (back view)
  • Page 12 KD9960.0GE dimensioned drawing KD9970.0GE dimensioned drawing of installation dimensions (back view)
  • Page 13: Assembly Instructions

    MOUNTING ON A WALL Take the wall mounting bracket shown in Fig. 2 and place it on the wall so that you have the height you want when you mount the cooker hood. Make sure that you maintain a minimum clearance of 40-65 cm between the hob and the bottom of the cooker hood for electric hobs and a minimum clearance of 55-70 cm for gas hobs.
  • Page 14 You have several options for aligning the hood thanks to its multiaxial mounting system. To align the hood on the right and left hand side, you can either move the wall mounting bracket to the left or right until it is in the ideal position by loosening the screws and then fastening them again (if the hood needs to be moved by more than 0.5 cm) (Fig.
  • Page 15 To mount the chimney take the assembly clamp that has been provided (Fig. 5), place it at the required height, generally right below the ceiling (Fig. 5) and then fasten it. You will then need to make the connection for the extraction air and mount the chimneys according to Fig.
  • Page 16: Operation

    OPERATION This cooker hood is regulated with touch-sensitive sensor controls located on the front of the hood. The controls react when the corresponding symbol is touched lightly. You can regulate the power settings, the lamp, including the brightness level, as well as the automatic delayed stop function with the sensor controls.
  • Page 17: Filter Saturation Display

    Deleting the filter change display “C” When the letter “C” is shown in the LED display, the charcoal filter will need to be replaced (see also the section on “maintenance, cleaning and care”). Hold the on/off key for approx. 5 seconds to reset the display. The function is reset and the letter “C”...
  • Page 18: Maintenance, Cleaning And Care

    Maintenance, Cleaning and Care It is absolutely essential to have your cooker hood regularly serviced in order to ensure that it operates efficiently for a long time. When the metal grease filter is clogged with particles of grease and dirt it will not work properly. The charcoal filter (only used for the circulation mode) cannot be rinsed or regenerated and must therefore be replaced at regular intervals.
  • Page 19: Grease Filter

    Grease filter To remove the grease filter press the bar rail handle of the filter down and remove the grease filter from the hood (Fig. 8). Then remove the grease filter from the stainless steel frame (Fig. 8.2). To replace the grease filter, first of all replace it in the stainless steel frame and then return it to the hood.
  • Page 20: Charcoal Filter

    The metal grease filters (not the stainless steel frames) may also be rinsed in the dishwasher, using a standard 55 °C programme. The metal grease filters should not be washed with dishes and glasses as grease may be deposited on the dishes or scraps of food may collect on the metal grid. Metal grease filters that are very clogged should be soaked well beforehand in hot soapy water.
