GE Profile Arctica PTS22LCP Dimension Manual

TM
PTS22LCP – GE Profile Arctica

Dimensions (in inches)

B
A
Specification Revised 6/03
™ 21.7 Cu. Ft. Top-Freezer Refrigerator
H
G
C
D
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
E
Width (in.) G
Width with door open 90° with door handle (in.) H
F
Each side (in.)
Top (in.)
Back (in.)
Total volume and shelf
area are calculated by the
Association of Home
Appliance Manufacturers'
standards.
For answers to your Monogram,
GE ® appliance questions, visit our website at
R
GEAppliances.com or call
GE Answer Center
67-1/2
66-7/8
27-5/8
31-5/8
33-5/8
63
32-7/8
35
1/8
1
1
Listed by
Underwriters
As an ENERGY STAR ® Partner,
GE has determined that this product
Laboratories
R
®
meets the ENERGY STAR
guidelines for energy efficiency.
® GE Profile ™ or
® service, 800.626.2000.
