GE Profile Arctica PTS22LBM Dimension Manual

TM
PTS22LBM—GE Profile

Dimensions (in inches)

Front View
A B
Specification Revised 3/01
™ Arctica ™ 21.7 Cu. Ft. Top-Freezer Refrigerator
Top View
C
D
H
G
E
F
Height with hinge (in.) A
Height without hinge (in.) B
Depth without Doors (in.) C
Depth with Doors (in.) D
Depth plus Handle with Doors Closed (in.) E
Depth with Doors open 90° (in.) F
Width with Doors Closed (in.) G
Width with Doors open 90° (in.) H
Each side (in.)
Top (in.)
Back (in.)
For answers to your Monogram, ® GE Profile
GE appliance questions, visit our website at
WWW.GEAppliances.com or call
GE Answer Center ® service, 800.626.2000.
Total volume and shelf
VOLUME and
area are calculated by the
SHELF AREA
Association of Home
Manufacturer Certified to
Appliance Manufacturers'
ASSOCIATION OF HOME R
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
standards.
67-1/2
66-7/8
27-5/8
31-5/8
33-5/8
63
32-7/8
33
1/8
1
1
™ or
Listed by
Underwriters
Laboratories
