- Page 1 OWNER S MANUAL Please Read the Manual First before Operation PT980AUH 7.1 Channel 350 Watts Built-In AM/FM Radio/ USB/SD Card HDMI Amplifier Receiver WWW.PYLEAUDIO.COM...
-
Page 2: Table Of Contents
Table of Contents Important Safety Information For Customers Caution System Features Front Panel Function Front Panel Display Window Real Panel Connectors Using the Remote Control Battery Installation Note Basic Operation Turn on/off the Power Master Volume Control Side Left Channel Volume Control Side Right Channel Volume Control Rear Left Channel Volume Control... -
Page 3: Important Safety Information
Output: 5 Channel Speaker Output Terminal for L, R, Center, SL, SR, And 1 line Out for Subwoofer. Total Power Consumption: 350W. Front Panel Function PT980AUH Digital 7.1 Channel HDMI Receiver 1.Tuner band adjustment knob. 8.HDMI3 input selector. 15.Mic bass adjustment knob. -
Page 4: Front Panel Display Window
Front Panel Display Window Name Function 1.STEREO AUX/TUNER/USB/SD INPUT Light up when AUX1/2/3, FM/AM,USB/SD input. 2.AC-3 PROLOGIC HDMI INPUT Light up when 7 .1 channel or HDMI1/2/3/4 input. 3.DSP DSP STATE ICON Light up when play DSP effect. 4.DIGITAL DISPLAY Light up to display value of current input mode. -
Page 5: Using The Remote Control
Using the Remote Control 1.Power on/off control selector 2.HDMI audio switch selector 3.Tuner band control selector 4.Tuner memory selector 5.Channel source output selector 6.Treble volume increase selector 7.Left balance selector 8.Treble volume decrease selector 9.USB/SD play selector 10.USB/SD-skip selector 11.Side left volume adjustment selector 12.Center volume adjustment selector Rear left volume adjustment selector 14.Tuner number selector... -
Page 6: Basic Operation
Basic Operation Turn on/off the Power Press " " key to control the power on and off. Master Volume Control Press the " " " " Key to adjust the main channel volume. Side Left Channel Volume Control Press " "... -
Page 7: Trouble Shooting
Introduction of DSP Control Key Press the key " " repeatedly to switch to different operations: Live, Hall, Church or Rock. All the above functions can give different sound effects. Introduction of Channel Source Output Selector Press " " key to select the channel source(7.1 CH/5.1 CH/3.1 CH/2.1CH) , the 7.1 CH is the default mode. Trouble Shooting Use this chart to help you solve operational problems.
