Data Sheet
FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel® Xeon® processor server
Slots
PCI-Express 3.0 x16
PCI-Express 2.0 x1 (mech. x4)
PCI-Express 2.0 x4 (mech. x8)
PCI-slots
Slot Notes
Drive bays
Storage drive bays
Accessible drive bays
Notes accessible drives
Drive bays (Base unit specific)
Storage drive bays
Accessible drive bays
General system information
Number of fans

Fan configuration

Fan notes

Operating panel

Operating buttons

Status LEDs
BIOS
BIOS features
Page 4 / 9
1 x
1 x
1 x
1 x PCI 32/33 MHz, 1x long, 5V
In SAS configuration 1x PCI-Express occupied by modular RAID controller.
In configurations with Intel® Core™ i3 or Intel® Pentium® processors slots are operated with PCI-Express 2.0.
3.5-inch or 2.5-inch hot-plug SAS/SATA
3 x 5.25/1.6-inch
all possible options described in relevant system configurator
Max 4 x 3.5-inch
3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD
1
1 standard fan
non redundant / non hot-plug
On/off switch
NMI button
Reset button
System status (orange / yellow)
Identification (blue)
Hard disks access (green)
Power (orange / green)
At system rear side:
System status (orange / yellow)
Identification (blue)
LAN connection (green)
LAN speed (green / yellow)
CSS (yellow)
ROM based setup utility
Recovery BIOS
BIOS settings save and restore
Local BIOS update from USB device
Online update tools for main Windows and Linux versions
Local and remote update via ServerView Update Manager
Remote PXE boot support
Remote iSCSI boot support
Max 8 x 2.5-inch
3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD
www.fujitsu.com/fts
