Model No. WCTL95335.0
TREADMILL EXERCISER
Serial No.
User's Manual
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Monday through Friday 8:00 to
17:00 EST (excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for Weslo Crosswalk 365e Treadmill
Summary of Contents for Weslo Crosswalk 365e Treadmill
- Page 1 Model No. WCTL95335.0 TREADMILL EXERCISER Serial No. User’s Manual Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 1-888-936-4266 Monday through Friday 8:00 to 17:00 EST (excluding holidays).
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the center of this manual. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Failure to use a properly functioning surge that all users of this treadmill are adequately suppressor could result in damage to the con- informed of all warnings and precautions. - Page 4 21. When folding or moving the treadmill, make maintenance and adjustment procedures de- sure that the storage latch is fully closed. scribed in this manual. Never remove the motor hood unless instructed to do so by an 22. Inspect and properly tighten all parts of the authorized service representative.
-
Page 5: Before You Begin
And when you’re not exercising, be found on a decal attached to the treadmill (see the the CROSSWALK 365e treadmill can be folded up, re- front cover of this manual for the location). quiring less than half the floor space of other treadmills. -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 2. Insert the tab on one of the Handrail Brackets (17) into the slot in the right Upright (38). Attach the Handrail Bracket with a 3/4” Screw (43) and a Star Washer (25). Attach the other Handrail Bracket to the left Upright (not Slot shown) in the same way.
- Page 8 5. Loosen the two (one shown) Crossbar Screws (98) sev- eral turns. Place the Console Base (87) on the Right Handrail (16) and the Left Handrail (not shown). Make sure that the Wire Harness is not pinched in the Right Handrail.
- Page 9 7. Attach the Storage Latch (66) to the left Upright (38) with two 3/4” Screws (43) as shown. Do not overtighten the Screws. 8. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may be included.
-
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT plug. Plug the power cord into a surge suppressor, and plug the surge suppressor into an appropriate outlet that is properly installed and grounded in Your treadmill features a walking belt coated with high- performance lubricant. - Page 11 CONSOLE DIAGRAM Displays Note: If there is a thin sheet of Pulse Sensor plastic on the console, remove it. Clip Stand on the foot rails of the treadmill. Find the clip at- CAUTION: tached to the key (see the drawing above), and slide Before operating the the clip onto the waistband of your clothes.
- Page 12 To stop the walking belt, press the Stop button. hold down the Stop button, insert the key into the The elapsed time will begin to flash in the console, and continue to hold the Stop button for a Time/Distance display. moment.
- Page 13 HOW TO USE THE UPPER BODY ARMS As you walk on the treadmill, you can either hold the handrails or use the upper body arms. To exercise your arms, shoulders, and back for a total body workout, move the upper body arms forward and back as you walk on the treadmill.
-
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be- come damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. - Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Press the storage latch to the left. Pivot the treadmill down until the frame and the foot rail are past the storage latch. Storage Latch Catch...
-
Page 16: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
-
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian. - Page 19 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
-
Page 20: Ordering Replacement Parts
To order replacement parts, call toll-free 1-888-936-4266, Monday through Friday 8:00 until 17:00 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • the MODEL NUMBER OF THE PRODUCT (WCTL95335.0) • the NAME OF THE PRODUCT (WESLO ® CROSSWALK 365e treadmill) •... - Page 21 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 22 PART LIST—Model No. WCTL95335.0 R0805A No. Qty. Description No. Qty. Description No. Qty. Description Front Endcap Screw Wheel Rear Roller Upper Body 3/4” Console Screw Frame Arm Endcap Handrail Bolt Bookrack Plastic Tie Reset/Off Right Front Endcap Left Handrail Circuit Breaker Console Base Front Isolator Grommet...
Need help?
Do you have a question about the Crosswalk 365e Treadmill and is the answer not in the manual?
Questions and answers
How can you set up incline angle at certain percentage for example 3%? Is there any indicator for the incline level ?
To set the incline angle on a Weslo Crosswalk 365e Treadmill, press either of the Incline buttons until the desired incline level, such as 3%, is reached. The context does not specify whether there is an indicator for the incline level.
This answer is automatically generated
How do I tighten the belt?
The document mentions that the large Allen wrench is used to adjust the walking belt but does not provide detailed steps for tightening it. However, typically, to tighten the belt on a treadmill like the Weslo Crosswalk 365e, follow these general steps:
1. Unplug the treadmill to ensure safety.
2. Locate the rear roller adjustment bolts at the back of the treadmill.
3. Use the large Allen wrench to turn both bolts clockwise in small increments (1/4 turn at a time) to tighten the belt.
4. Check belt tension by lifting the belt in the center; it should lift about 2-3 inches.
5. Test the treadmill by running it at a low speed to ensure the belt moves smoothly and is centered.
6. Make further adjustments if needed, ensuring the belt is not too tight or too loose.
If further details are needed, refer to the treadmill manual.
