30.8 CT
Model No. WLTL38410
USER'S MANUAL
Serial No.
Serial Number
Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.weslo.com
this equipment. Save this manual
for future reference.
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo Cadence 30.8 ct
Summary of Contents for Weslo Cadence 30.8 ct
- Page 1 CUSTOMER HOT LINE: 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Save this manual for future reference. new products, prizes, fitness tips, and much more!
-
Page 2: Table Of Contents
120 volts AC and 15 amps. To purchase a surge suppressor, see 6. Keep children under the age of 12 and pets your local WESLO dealer or call 1-800-999- away from the treadmill at all times. 3756 and order part number 146148. - Page 3 14. Never start the treadmill while you are sure that the storage latch is fully closed. standing on the walking belt. Always hold the handrails or upper body arms while 19. Inspect and tighten all parts of the treadmill using the treadmill. every three months.
-
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new WESLO ® 30.8 CT at 1-800-999-3756, Monday through Friday, 6 a.m. treadmill. The 30.8 CT treadmill combines advanced until 6 p.m. Mountain Time (excluding holidays). To technology with innovative design to let you enjoy an... -
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Refer to the drawings below to identify the parts used in assembly. Assembly requires the following tools: The included allen wrench and your own phillips screwdriver , mallet... - Page 6 3. Refer to the inset drawing. If there is a plastic tie holding the Cage Nut (104) in the Right Handrail (1), remove the plastic tie. Pull 4” to 5” of the Wire Harness (21) out of the Right Upright (11). Feed the Wire Harness up through the bracket on the Right Handrail and out of the indicated hole.
-
Page 7: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local WESLO dealer or call 1-800-999-3756 and order part number 146148. Use only a single-outlet surge sup- Metal Screw pressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). - Page 8 CONSOLE DIAGRAM Note: If there is a thin sheet of clear plastic on the face of the console, remove it before operating the console. CAUTION: Before operating the console, read the following precautions. • Do not stand on the walking belt when turn- ing on the power.
- Page 9 Follow the steps below to operate the console. Monitor your progress with the two displays. TIME/DISTANCE dis- Insert the key fully into the power switch. Arrow play—This display Inserting the key will shows the elapsed time not turn on the dis- and the distance that you have walked or plays.
-
Page 10: How To Fold And Move The Treadmill
HOW TO USE THE UPPER BODY ARMS Upper Body Arms As you exercise on the treadmill, you can hold either the handrails or the upper body arms. The upper body arms are designed to exercise your arms, shoulders, and back for a total body workout. - Page 11 HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the stor- age position as described on page 10. Make sure that the storage latch is closed fully over the catch. 1. Hold the upper ends of the handrails. Place one foot on the base as shown.
-
Page 12: Trouble-Shooting
TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES control on the console to FAT BURN to help you main- tain the proper intensity level. (See page 9.) WARNING: Before beginning this or any exercise program, consult your Aerobic Exercise physician. This is especially important for in- dividuals over the age of 35 or individuals If your goal is to strengthen your cardiovascular sys- with pre-existing health problems. - Page 15 Training Zone Exercise to cool down. This will increase the flexibility of your muscles and will help to prevent post-exercise problems. After warming up, increase the intensity of your exer- cise until your pulse is in your training zone for 20 to EXERCISE FREQUENCY 60 minutes.
- Page 16 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 17 PART LIST—Model No. WLTL38410 R0801A Key No. Qty. Description Key No. Qty. Description Right Handrail 3/8” Washer Key/Clip Frame Pivot Bolt Incline Leg Pivot Bolt Latch Decal Battery Cover Motor Belly Pan Foot Rail Cable Tie Clamp Lift Motor Rear Platform Screw Rear Roller Releasable Tie Speed Potentiometer...
- Page 18 EXPLODED DRAWING—Model No. WLTL38410 R0801A...
-
Page 19: Ordering Replacement Parts
If possible, place the treadmill near your telephone for easy reference when calling. WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
