GE JGBP26GEN Use And Care & Installation Manual

Self-cleaning gas range

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Anti-Tip Device .................................3, 35,43

Operating Instructions, Tips

Aluminum Foil ............................5, 17, 18,20

Features ........................................................6, 7

Oven. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-24

Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-17

Broiling, Broiling Guide ....................20, 21

Clock and Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10, 11

Door Latch .............l4, 15, 18,20,22-24

Light; Bulb Replacement . . . . . . . . . . . . . . . . . 13,30

Oven Control ......................................10, 11

Preheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Roasting, Roasting Guide ................l8, 19

Self-Cleaning Instructions ..............22-24

Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12, 16–1 8,29

Thermostat Adjustment .........................13

Surface Cooking .........................................8, 9

Control Settings ..........................................8

Electric lgnition............................................8

Surface Light; Bulb Replacement 13,32

Care and Cleaning ....................25-32

Broiler Pan and Rack ..........................................29

Burner Assembly .................................25, 26,27

Door Removal ...........,...................................2 8

Oven Bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Oven Vents ........................................5, 13,32

Storage Drawer ............................................3 1

GE Appliances

Problem Solver .......................49, 50

Summary of Contents for GE JGBP26GEN

Page 1 Oven Vents ...5, 13,32 Storage Drawer ...3 1 GE Appliances XLMTM Self-Cleaning Gas Range Problem Solver ...49, 50 More questions ?...call GE Answer Center” 800.626.2000 preparation Flame Size ...9, 41,48,49 Flooring Under the Range ...36 Installation Instructions ...34 -48 Leveling ...43 Minor Adjustments ...33...
Page 2 Write down the model and serial numbers. Depending on your range, you’ll find the model and serial numbers on a label on the front of the range, behind the kick panel, storage drawer or broiler drawer. These numbers are also on the...
Page 3 When You at Your Range Have the installer show you the location of the range gas cut-off valve and how to shut it off if necessary. Q Have your range installed and properly grounded by a qualified installer, in accordance with the Installation Instructions.
Page 4: Surface Cooking
Air openings are located at the rear of the cooktop, at the top and bottom of the oven door, and at the bottom of the range, under the kick panel, storage drawer or broiler drawer (depending on the model).
Page 5 If you smell gas, turn off the gas to the range and call a qualified service technician. Never use an open flame to locate a leak.
Page 6 JGBP26GEN JGBP27GEN JGBP31GEP JGBP34GEP JGBP35GEP FEATu~s OF YO Your range is equipped with one of the two types of surface burners shown above. RANGE Drip (on Some models) Burner...
Page 7: Features
(Not all models have all features. Appearance of features varies.) 1 Air Int&e (under storage drawer or kick panel) Model and Serial Numbers (on front frame of range, behind storage drawer or kick panel) Anti-Tip Device (Lower right rear corner on range back. See Installation Instructions.)
Page 8: Electric Ignition
In case of a power failure, you can light the surface burners on your range with a match. Hold a lighted match to the burner, then turn the knob to the LITE...
Page 9: Wok Cooking
Follow cookware manufacturer’s recommendations for cooking methods. Glass: There are two types of glass cookware-those for oven use only and those fo; top-of-range cooking (saucepans, coffee and teapots). Glass conducts heat very slowly. Wok Cooking (on models with sealed burners)
Page 10 Make sure the latch is moved to the right as far as it will go. Press the CLEAWOFF pad. Allow oven to cool for one hour. Put oven back into operation. If function error code repeats, disconnect power to the range and call for service.
Page 11: Display Messages
OVEN CONTROL, CLOCK Am T~R Clock The clock must be set for the automatic oven timing functions to work properly. The time of day cannot be changed during a TIME BAKE or CLEAN cycle. Timer The timer is a minute timer; it does not control oven operations.
Page 12: Before Using Your Oven
Read the information and tips on the following pages. Keep this book handy where you can refer to it, especially during the first weeks of using your new range. Mlectrlc lgnltlon...
Page 13: Oven Light
Oven Moisture As your oven heats up, the temperature change of the air in the oven may cause water droplets to form on the door glass. These droplets are harmless and will evaporate as the oven continues to heat up. Oven Ven@ The oven is vented through duct openings at the rear of the cooktop.
Page 14 Your oven temperature is controlled very accurately using an oven control system. We recommend that you operate the range for a number of weeks to become familiar with your new oven’s performance. If you think an adjustment is necessary, see the Using Your Oven or Minor Adjustments section.
Page 15 The oven control allows you to turn the oven on or off automatically at specific times that you set. NOTE: Before beginning make sure the oven clock shows the correct time of day. How to Set Delay Start and Stop Quick Reminder: 1.
Page 16: Preheating
For best baking results, follow these suggestions: Oven Shelf Arrange the oven shelf or shelves in the desired locations while the oven is cool. The correct shelf position depends on the kind of food and the browning desired. As a general rule, place most foods in the middle of the oven, on either the second or third shelf from the bottom.
Page 17: Aluminum Foil
Baking Guides When using prepared baking mixes, follow package recipe or instructions for best baking results. Cookies When baking cookies, flat cookie sheets (without sides) produce better-looking cookies. Cookies baked in a jelly roll pan (short sides all around) may have darker edges and pale or light browning may occur.
Page 18 not lock the oven door with the door latch during roasting. This is used for self-cleaning only. Roasting is cooking by dry heat. Tender meat or poultry can be roasted uncovered in your oven. Roasting temperatures, which should be low and steady, keep spattering to a minimum.
Page 19 Questions and Answers Q. Is it necessary to check for doneness with a meat thermometer? A. Checking the finished internal temperature at the completion of cooking time is recommended. Temperatures are shown in Roasting Guide. For roasts over 8 lbs., check with thermometer at half- hour intervals after half the time has passed.
Page 20: Use Of Aluminum Foil
Broiling is cooking food by intense radiant heat from the upper unit in the oven. Most fish and tender cuts of meat can be broiled. Follow these steps to keep spattering and smoking to a minimum. The oven door should be closed during broiling. Do not lock the oven door with the door latch during broiling.
Page 21: Broiler Pan And Rack
1. Always use broiler pan and rack that comes with your oven. It is designed to minimize smoking and spattering by trapping juices in the shielded lower part of the pan. 2. Broiling should always be done with the oven door closed.
Page 22: Oven Bottom
OPEMT~G THE SELF-CLEANING OWN Before a Clean Cycle Quick Reminder: 1. Prepare the oven for cleaning. 2. Close and latch the oven door. 3. Press the CLEAN pad. 4. Press the INCREASE pad. m M ~ “~~ If you wish to change preset clean time of 4 hours; press the 1~ DECREASE pad until desired stop time appears in the display.
Page 23 After a Clean Cycle When the clean cycle is finished, the word “CLEAN” will go out in the display and the oven will begin to cool. When the oven temperature has fallen below the locking temperature the word “LOCK” goes out and the door can be opened.
Page 24 OPEWT~G T~ SELF-CLEA~G OWN Questions and Answers If my oven clock is not working, can I still self- clean my oven? A. If the clock is not working then the entire control is not working. If the clock is not set to the correct time of day you will not be able to set a delay clean to end at a specific time.
Page 25: Sealed Burner Assemblies
Proper care and cleaning are important so your range will give you efficient and satisfactory service. Follow these directions carefully in caring for it to help assure safe and proper maintenance. BE SURE ELECTRICAL POWER IS DISCONNECTED BEFORE CLEANING ANY PART OF YOUR RANGE.
Page 26 Dry them in a warm oven or with a cloth—don’t reassemble them wet. Range Burner Heads The holes in the burners of your range, and the spark electrodes, must be kept clean at all times for proper ignition and an even, unhampered flame.
Page 27: Burner Grates
After cleaning, dry them thoroughly by putting them in a warm oven for a few minutes. Don’t put the grates back on the range while they are wet. When replacing the grates, be sure they’re positioned securely over the burners.
Page 28: Lift-Off Oven Door
— CA~ Am CLEANING (continued) Lift-Off Oven Door The oven door is removable but it is heavy. You may need help removing and replacing the door. remove the door, open it a few inches to the special “stop” position that will hold the door open. Grasp firmly on each side and lift the door straight up and off the hinges.
Page 29: Oven Bottom
Wash; scour if necessary. Rinse and dry. The broiler pan and rack may also be cleaned in a dishwasher. Do not store a soiled broiler pan and rack anywhere in the range. (continued next page)
Page 30: Control Panel And Knobs
(continued) Oven Lamp Replacement CAUTION: Before replacing your oven bulb, disconnect electrical power to the range at the main fuse or circuit breaker panel. the lamp cover and bulb cool completely. The oven lamp (bulb) is covered with a removable glass cover that is held in place with a bail-shaped wire.
Page 31: Storage Drawer 3
4. Slide drawer the rest of the way in. To replace, insert the two slots at bottom of panel onto the two tabs at base of range and push top of panel forward to engage spring clips. (on some models)
Page 32 Air openings are located at the rear of the cooktop, at the top and bottom of the oven door, and at the bottom of the range, under the kick panel, storage drawer or broiler drawer (depending on the model).
Page 33 2. Grasp the oven bottom at finger slots on each side. 3. Lift the rear of the oven bottom enough to clear the lip of the range frame, then pull out. Remove Screw Burner Baffle To remove the burner ba~e, use a nut driver to remove the 1/4”...
Page 34 I ~UTION Do not attempt to operate the oven of this range during a power failure. lM~~ANT Remove d pacting material and literature from oven before connecting gas and electrical supp~ to range. DIMENSIONS AND CLEARANCES Provide adequate clearances betieen the range and adjacent combustible surfaces.
Page 35 Clearance between the cooking surface and the I ventilation hood surface MUST N~R BE :,;!~ ‘i ~SS THAN 24 INCHES. H cabinets are placed above the range, allow a f ! minimum clearance of 30” between the cooking . surface and the bottom of unprotected cabinets.
Page 36 (or similar material). men thefloor at the front of the range, the area covering etih that the range will rest on should be built up with plywood to the same level or higher than the floor covering. This will allow the range to be moved for cleaning or servicing.
Page 37 This range is convertible for use on natural or propane gas, if you decide to use this range on a different type of gas, conversion adjustments must be made by a service technician or other qualtiled person before attempting to operate the range on that gas.
Page 38 ~STALLATION ~STRUCTIONS CONNECT THE WNGE TO GM (continued) Flexible Connector Hookup for Models Equipped with Sealed Burners Pressure Regulator ~ @* -. 90°Elbow~ (provided) Adapter ,,a:,:,L; Rigid Pipe Hookup for Models Equipped with Sealed Burners Pressure + Regulator ;;:2::;+ ~iT”~=T ~=-!:i (continued) Flexible Connector and Rigid Pipe Hookups...
Page 39 5. men all connections have been made, make sure all range controls are in the off position and turn on the main gas supply valve. Use a liquid leak detector at all joints and connections to check for leaks in the system.
Page 40 Z240/MH Mobile Home Installation Code. Electric Disconnect bcate 2. Pinch sides of connector and pull out of range back. Models Equipped with Dual Burners Situations where Appliance Power disconnect plug on the range back. Models Equipped with Waled Burners ——...
Page 41 SU1 THE OPENINGS Seal any openings in the wall behind the range and in the floor under the range when hookups are completed. CHECK SUR~CE BURNER IGNITION Operation of all cooktop and oven burners should be checked after range and gas supply lines have been carefully checked for leaks.
Page 42 2. Grasp the oven bottom at finger slots on each side. 3. Lift the rear of the oven bottom enough to clear the lip of the range frame, then pull out. ‘urnerBaff’e~N*2 To remove the burner baffle (on some models): a nut driver to remove the 1/4”...
Page 43: Leveling
6. Adjust the leveling legs until the range is level. 7. After the range is level, slide the range away from the wall so that the Anti-Tip device can be installed. INSTALLING THE ANTI-TIP DEVICE...
Page 44 (depending on the size of the spuds) PREPARE RANGE FOR CONVERSION (1) Turn off gas supp& at tie wall. (2) Turn off tie electicd power to tie range. range has not yet been connected to gas supply, or if flexible connection was made, range maybe pulled out from the wall to make conversion easier.
Page 45 CONVERTING SURFME BURNERS ON MODELS EQUIPPED WITH S~LED BURNERS (See Step 4 if range is equipped with dual burners.) Burnercap~ Burner Head Bu::a Orifice Spud —. Gas Inlet Tube ~~~a\ Remove grates, burner caps and burner heads. 2. Remove burner bases by unscrewing the 3 small screws in each base.
Page 46 To prevent leakage, make sure spuds are securely screwed Electrode into gas inlet tubes. 4. Replace the burner assemblies. 5. Keep all spuds with your range so you have them if you move or get a different gas hook-up.
Page 47 CHECK FOR LEAKS When all connections have been made, make sure all range controls are in the off position and turn on the main gas supply valve. Use a liquid leak detector at all joints and connections to check for leaks in the system.
Page 48 ~STALLATION ~STRUCTIONS HOW TO CONVERT THE RANGE FOR WITH 1P GAS OR HATURAL GAS CONVERT BURNER VALVES Turn all top burners to LOW. 2. Remove all four knobs. 3. With a small flat blade screwdriver, turn the valve set screws...
Page 49 If burner flames look like (A), cdl for service. Normal burner flames should look Q With LP gas, some yellow tipping on outer cones is normal. BURNER FLAMES VERY “ If range is connected to LP gas, check all steps in the Instrdlation Instructions. LARGE OR YELLOW OVEN DOES NOT Q Make sure thermostat capillary bulb (located in upper portion of oven) is in correct position, not touching oven sides and not coated with anything.
Page 50 Make sure tie latch is moved to the right as far as it will go. Press the CLEAWOFF pad. Allow oven to cool for one hour. Put oven back into operation. If the failure code repeats, disconnect all power to the range. Call for service.
Page 51 Telecommunication Dtice for the Deaf For Customers Wtih SpecialNeeds... Upon request, GE wfll provide Braflle controls for a variety of GE appliances, and a brochure to assist in planning a barrier-free kitchen for persons with limited mobdity To ob~in these items free of charge, cdl 800.626.2000.
Page 52: What Is Not Covered
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General. If further help is needed concerning this warranty, write: Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225 Thjs book is printed on recycled paper...
