- Page 1 Powered Subwoofer Owner’s Manual 2013 PINNACLE LOUDSPEAKERS...
- Page 2 ® We congratulate and thank you for choosing a PINNACLE subwoofer. Our subwoofers exemplify the best in modern audio technology, and are designed to produce remarkable amounts of deep bass. Please read this manual completely to ensure the best possible performance from your Home Theater or sound system.
- Page 3 CONNECTIONS: Complete all wire connections in your Home Theater / sound system before plugging in your subwoofer or turning on your receiver (amplifier). Connecting Your Subwoofer: To connect your subwoofer your receiver must have a dedicated "subwoofer output" jack (sometimes called Sub Out, Low Pass or LFE). Simply connect your subwoofer using a standard RCA cable (the same kind of audio cable used to connect a CD player or tape deck, etc.) from your receiver’s subwoofer output to the input on the subwoofer.
- Page 4 POWER-UP AND CONTROL ADJUSTMENTS: With the VOLUME control at minimum (fully counter-clockwise) plug your subwoofer’s power cord into any ordinary wall outlet. If for any reason you do not want your subwoofer on it can simply be turned off either by unplugging it, or connecting its powercord to a switched power strip or outlet (found on the back of some Home Theater receivers) or by using a remote controlled switched outlet.
- Page 5 With high volume levels of certain types of signals, your subwoofer may be audibly strained. If you hear the subwoofer “breaking-up” or distorting, turn down the volume level. ® If you have any problems or questions, please contact your PINNACLE dealer for further assistance.
- Page 6 TROUBLESHOOTING: No Sound only from Subwoofer - Check the subwoofer's volume setting and all connections. If your receiver has a subwoofer on/off or variable subwoofer output level control, ensure that the subwoofer option it is turned on and that the output level is at maximum. Ensure that the center channel mode on the receiver is in the NORMAL or SMALL position.
- Page 7 Parts replacement and labor will be performed at the discretion of Pinnacle Loudspeakers and will be provided free of charge unless (in the opinion of our service department, service representatives, or engineering department) the system has failed due to abuse or negligent operation.
- Page 8 415 Oser Ave, Suite M Hauppauge, NY 11788 www.pinnaclespeakers.com PR MAN Q5 REV0113...
