M4 x 16mm
M4 x 28mm
M8 x 45mm Button
Screw (92)–6
Screw (99)–4
Bolt (76)–4
M8 x 20mm
M10 x 20mm Patch
Shoulder Patch Bolt (31)–2
Patch Screw
Screw (79)–6
(80)–2
M10 x 48mm Patch
M10 x 95mm Patch Screw (82)–4
Screw (75)–6
M8 Jam Nut
M8 Washer
M10 Split
(77)–4
Washer (78)–10
(33)–2
