Hotel Fitness Xt9800 Elliptical Manual

English manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. HF-XT9800-I.0
Serial No.
USER’'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, please see
HOW TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
www.HotelFitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hotel Fitness Xt9800 Elliptical and is the answer not in the manual?

Questions and answers

Related Manuals for Hotel Fitness Hotel Fitness Xt9800 Elliptical

Summary of Contents for Hotel Fitness Hotel Fitness Xt9800 Elliptical

  • Page 1 Model No. HF-XT9800-I.0 Serial No. USER’’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, please see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. Hotel Fitness and FreeMotion Fitness assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary HOTEL reading this manual, please see the back cover of this FITNESS ® HF-XT9800-I elliptical. The HF-XT9800-I manual. To help us assist you, note the product model elliptical provides an impressive selection of features number and serial number before contacting us.

  • Page 7: Assembly

    ASSEMBLY Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing materials until you finish all assembly steps. 1. Call or email Customer Care (see the back cover of this manual) today and register your product.
  • Page 8 3. Plug the Power Cord (104) into the Power Receptacle (35) on the frame of the elliptical. Note: To plug the Power Cord (104) into an out- let, see HOW TO PLUG IN THE POWER CORD on page 10. 4. Make sure that all parts are properly tightened before you use the elliptical. Note: Extra parts may be included.

  • Page 9: How To Upgrade The Console

    HOW TO UPGRADE THE CONSOLE Your console has been preconfigured to operate with a 17" Digital TV (see the drawings below). To learn about the features of the basic console, see page 13. To learn about the features of the 17" Digital TV, see the user’’s manual included with the 17"...

  • Page 10: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should malfunc- be used to tion or break down, grounding provides a path of least connect the Adapter resistance for electric current to reduce the risk of...
  • Page 11 HOW TO MOVE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL Due to the size and weight of the elliptical, mov- To mount the elliptical, hold the upper body arms or ing it requires two persons. Remove the rear frame the handlebars and step onto the pedal that is in the cover.
  • Page 12 HOW TO CONNECT A CATV CABLE WARRANTY INFORMATION If your elliptical has the 17" Digital TV, a CATV The warranty for this product does not cover damage cable must be connected to the elliptical for cable TV or equipment failure caused by electric wiring not in stations to be viewed.
  • Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode, you can change the resistance of the pedals and the incline of the ramp The console offers an impressive array of features with the touch of a button. designed to make your workouts more effective and enjoyable.
  • Page 14 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the elliptical has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before turning on the power.
  • Page 15 HOW TO SET UP THE CONSOLE The Internet browser will open to the iFit.com account creation page. Then, fill in the information Before using the elliptical for the first time, set up the fields on the screen to create your iFit account. console.
  • Page 16 HOW TO USE THE MANUAL MODE 4. Follow your progress. 1. Begin pedaling or press any button on the The console offers several display modes. The console to turn on the console. display mode that you select will determine which workout information is shown.
  • Page 17 When your pulse is detected, your heart rate will be HOW TO USE AN ONBOARD WORKOUT shown. For the most accurate heart rate read- ing, hold the contacts for at least 15 seconds. 1. Begin pedaling or press any button on the console to turn on the console.
  • Page 18 If the resistance level and/or incline level for the HOW TO USE A SET-A-GOAL WORKOUT current segment is too high or too low, you can manually override the setting by pressing the 1. Begin pedaling or press any button on the Resistance buttons or the Incline/Decline but- console to turn on the console.
  • Page 19 IMPORTANT: The target rpm is intended only to HOW TO USE AN IFIT WORKOUT provide motivation. Your actual pedaling speed may be slower than the target rpm. Make sure Note: To use an iFit workout, you must have access to pedal at a speed that is comfortable for you. to a wireless network (see HOW TO USE THE WIRELESS NETWORK MODE on page 23.
  • Page 20 For more information about the iFit workouts, HOW TO USE THE EQUIPMENT SETTINGS MODE please see www.iFit.com. The console features an equipment settings mode that When you select an iFit workout, the screen will allows you to change various settings for the elliptical. show the name, duration, and distance of the work- out.
  • Page 21 6. Enable or disable the Internet browser. 10. Enable or disable street view. You can disable the Internet browser, which will You can disable the street view for maps workouts, help to restrict the bandwidth used on your wireless which will help to restrict the bandwidth used on network.
  • Page 22 HOW TO USE THE ENTERTAINMENT MODE HOW TO USE THE MAINTENANCE MODE The console features an entertainment mode that The console features a maintenance mode that allows allows you to connect the console to a remote TV. you to update the console firmware, calibrate the incline of the ramp, view machine information, view If you purchase the 17"...
  • Page 23 4. Calibrate the incline of the ramp. HOW TO USE THE WIRELESS NETWORK MODE Touch the Calibrate Incline button. Then, touch the The console features a wireless network mode that Begin button to calibrate the incline of the ramp. allows you to set up a wireless network connection. The ramp will automatically rise to the maximum incline level, lower to the minimum incline level, Note: You must have your own wireless network and...
  • Page 24 An information box will ask if you want to connect HOW TO USE AN IPOD WITH THE SOUND SYSTEM to the wireless network. Touch the Connect button to connect to the network or touch the Cancel but- This console has been designed specifically to work ton to return to the list of networks.

  • Page 25: Maintenance And Troubleshooting

    HOW TO USE THE INTERNET BROWSER To use the keyboard, see HOW TO USE THE TOUCH SCREEN on page 14. Note: To use the browser, you must have access to a wireless network including an 802.11b/g/n router with To enter a different web address in the URL bar, first SSID broadcast enabled (hidden networks are not slide your finger down the screen to view the URL bar, supported).

  • Page 26: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 27: Part List

    PART LIST Model No. HF-XT9800-I.0 R0113A Key No. Qty. Description Key No. Qty. Description Frame Disc Upright Ring Console Left Shield Console Back Right Shield Accessory Tray Crank Arm Cover Pulse Bar/Pulse Wire Front Shield Media Module Top Shield Sensor Plate Right Roller Arm Front Pulse Cover Right Pedal Arm...
  • Page 28 Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw 5/16" x 1 1/4" Flat Head Screw #8 x 1" Screw #8 x 3/4" Screw #10 x 3/8" Screw #8––32 x 3/4" Screw 3/8" x 2 1/2" Screw 5/16"...

  • Page 29: Exploded Drawing

    EXPLODED DRAWING A Model No. HF-XT9800-I.0 R0113A...
  • Page 30 EXPLODED DRAWING B Model No. HF-XT9800-I.0 R0113A...
  • Page 31 EXPLODED DRAWING C Model No. HF-XT9800-I.0 R0113A...

  • Page 32: How To Contact Customer Care

    HOW TO CONTACT CUSTOMER CARE If you have questions after reading this manual, or if parts are damaged or missing, please contact the store where you purchased this product. If you are unable to contact the store, contact Customer Care at the phone number, email address, or postal address listed below.

This manual is also suitable for:

Hf-xt9800-iHf-xt9800-i.0

Table of Contents
