GE PB3-POS-RP ProBridge User Manual page 23

SW2 - Switches 5-8
Switches 5-8 on SW2 are used to modify the communication
transfer protocol on Port 2 of the PB3 should the POS device
you are using require it. The protocol listed here consists of 3
user definable settings: The Start Bit, The Stop Bit, and Parity.
These can be expressed as follows:
•
Stop Bit: 7 or 8-bit ASCII
•
Stop Bit: 1 or 2-Stop bits
•
Parity: Odd, Even, or None
In the following table 8,1,E would translate to 8-start bits, 1-stop
bit, and Even parity.
Protocol
7,1,N
7,1,O
7,1,E
8,1,N
8,1,O
8,1,E
7,2,N
7,2,O
7,2,E
8,2,N
8,2,O
8,2,E
SW2
5 6
U U
U U
U U
U U
U D
U D
U D
U D
D U
D U
D U
D U
7 8
U U
U D
D U
D D
U U
U D
D U
D D
U U
U D
D U
D D
23
