PN-T322B
LCD MONITOR
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Sharp PN-T322B

Summary of Contents for Sharp PN-T322B

  • Page 1 PN-T322B LCD MONITOR OPERATION MANUAL...
  • Page 2 IMPORTANT: To aid reporting in case of loss or theft, please record the Model No.: product’s model and serial numbers in the space provided. The numbers are located in the rear of the product. Serial No.: U.S.A. ONLY...

  • Page 3: Important Information

    IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the CAUTION user to the presence of uninsulated “dangerous voltage”...

  • Page 4: Dear Sharp Customer

    DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
  • Page 5 SAFETY PRECAUTIONS (Continued) 19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: •...

  • Page 6: Tips And Safety Instructions

    - Never rub or tap the monitor with hard objects. - Unplug the power cord if it is not used for a long time. - Please understand that SHARP CORPORATION bears no - Do not attempt to repair the power cord if it is broken responsibility for errors made during use by the customer or or malfunctioning.

  • Page 7: Mounting Precautions

    Operation panel Unit: inch [cm] Logo 7-7/8 [20] 1-7/16 [3.5] - B e careful not to cover the remote control sensor or buttons. Mounting precautions (for SHARP dealers and service 2 [5] engineers) For the monitor in vertical orientation • Be sure to use a wall-mount bracket designed or Unit: inch [cm] designated for mounting the monitor. 7-7/8 [20] 1-13/16 [4.5] • To attach a VESA-compliant mounting bracket, use M6...

  • Page 8: Table Of Contents

    Basic Operation .............16 MOUNTING PRECAUTIONS ..........5 Auto playback of image and audio files (Slideshow) ..18 Mounting precautions Menu Items ..............19 (for SHARP dealers and service engineers) ....5 Displaying the menu screen ........19 Supplied Components .............6 Menu item details ............20 System Requirements .............6 List screen ..............21...

  • Page 9: Part Names

    Part Names nFront view 1. Sensor 2. Reflective surface 3. Power LED (See page 13.) 4. Power switch (See page 13.) 5. Input switch (See page 16.) 6. Remote control sensor (See page 12.) TIPS • Use a pointed object such as a pen tip to press the switches at the operation panel.
  • Page 10 Part Names nRemote control unit 1. Signal transmitter 2. POWER button (See page 13.) 3. MUTE button (See page 16.) 4. VOL +/- buttons (See page 16.) BRIGHT +/- buttons (See page 16.) Cursor control ( / ) buttons 5. DISPLAY button (See page 16.) 6.

  • Page 11: Connecting Peripheral Equipment

    Connecting Peripheral Equipment • The volume of the output sound can be fixed by setting Caution AUDIO OUTPUT on the OPTION menu. • Be sure to turn off the main power switch and disconnect • It is not possible to control the sound output from the the plug from the power outlet before connecting/ audio output terminal with the AUDIO menu.

  • Page 12: Connecting The Power Cord

    Connecting the Power Cord Caution • Do not use a power cord other than the one supplied with the monitor. 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the AC power outlet. Main power switch For power outlet...

  • Page 13: Binding Cables

    Binding Cables The cables connected to the terminals on the rear of the monitor can be fastened with the cable clamp. Attach the cable clamp to the back of the monitor, and fasten the cables. Cable Cable clamp Setting the USB flash drive cover 1.

  • Page 14: Preparing The Remote Control Unit

    Preparing the Remote Control Unit Remote control operation range Batteries and an insulation sheet are preinstalled in the remote control at the factory. Before using the remote control, be sure to remove the insulation sheet. The operation range of the remote control unit is approx. 16.4 feet (5 m) at an angle of approx 10°...

  • Page 15: Turning Power On/Off

    Turning Power On/Off Turning power on/off Caution • Turn on the monitor first before turning on the PC or Press the POWER button or POWER switch to turn the power playback device. ON/OFF. When the main power is off, the power cannot be turned on with the POWER button.

  • Page 16: Touch Action

    Touch Action Operations that can be performed vary depending on the OS. Drag-and-drop Same action as drag-and-drop with a mouse. Windows XP/ Touch the screen with your finger and move without lifting. Windows 7 Windows Vista When you have finished the movement, lift your finger. Single-tap Double-tap Drag-and-drop...

  • Page 17: Other Functions

    Touch Action Other functions Zoom Use in a screen that is capable of enlargement/reduction. In Windows 7, touch pointer and input panel functions can be Touch the screen with two fingers and move your fingers used. closer together to reduce the view, or apart to enlarge the For information on these functions, see Windows Help.

  • Page 18: Basic Operation

    Basic Operation 3. MENU Displays and turns off the menu screen (see page 20). 4. VOL +/- (Volume adjustment) Pressing displays the VOLUME menu when the menu screen is not displayed. VOLUME Press to adjust the volume of the sound. * If you do not press any buttons for about 4 seconds, the VOLUME menu automatically disappears.

  • Page 19: Basic Operation

    Basic Operation nSwitching the screen size Even when the screen size is changed, the display may remain the same depending on the input signal. WIDE Displays image so it fills the entire screen. ZOOM 1 An image with a 4:3 aspect ratio is enlarged to fill the entire screen without changing the aspect ratio.

  • Page 20: Auto Playback Of Image And Audio Files (Slideshow)

    Basic Operation Auto playback of image and audio files (Slideshow) When the input mode is set to USB and a USB flash drive is inserted in the USB port, the image files in the root folder of the USB flash drive will be automatically displayed as a slideshow. If there is an audio file in the root folder, the audio file will also automatically play.

  • Page 21: Menu Items

    Menu Items Displaying the menu screen TIPS • The menu will differ depending on the input mode. Video and audio adjustment and settings of various functions • The menu screen will close automatically if no operation is are enabled. This section describes how to use the menu performed for about 15 seconds.

  • Page 22: Menu Item Details

    Menu Items Menu item details nPICTURE CONTRAST The menu will differ depending on the input mode. Adjusts the brightness of the image. nSCREEN (D-SUB input) BLACK LEVEL Adjusts the entire brightness of the video signals. AUTO The CLOCK, PHASE, H-POS, and V-POS are automatically TINT (AV signal input) adjusted.

  • Page 23: List Screen

    Menu Items List screen nSETUP THERMAL SENSOR SETTING nSpecifying a folder and presenting a Sets the orientation of the temperature sensor. Change this slideshow setting if you change the installation orientation (vertical or horizontal) of the monitor. In the list screen, you can specify the folder to be used for a LANDSCAPE ..

  • Page 24: Adjustments For Pc Screen Display

    Menu Items Adjustments for PC screen display nAutomatic adjustment When you use the PC D-sub input terminal to display a PC screen for the first time, or when you change the setting of the PC, use the automatic screen adjustment. 1.

  • Page 25: Initialization/Functional Restriction Setting (Function Menu)

    Initialization/Functional Restriction Setting (FUNCTION Menu) You can return the settings to their factory-preset values and restrict operations. 1. After pressing for about 5 seconds, press , and in that order. 2. Press 3. Select and set the items. ALL RESET , to reset the settings to the factory default Press settings.

  • Page 26: Controlling The Monitor With A Pc (Rs-232C)

    Controlling the Monitor with a PC (RS-232C) Communication procedure You can control this monitor from a PC via RS-232C (COM port) on the PC. nCommand format PC connection When a command is sent from the PC to the monitor, the monitor operates according to the received command and Connect with RS-232 straight cable between the PC’s COM sends a response message to the PC.
  • Page 27 Controlling the Monitor with a PC (RS-232C) nResponse code format When a command has been executed correctly Return code , 0A A response is returned after a command is executed. When a command has not been executed Return code , 0A TIPS •...

  • Page 28: Rs-232C Command Table

    Controlling the Monitor with a PC (RS-232C) RS-232C command table How to read the command table Command: Command field (See page 24.) Direction: W When the “Parameter” is set in the parameter field (see page 24), the command functions as described under “Control/Response Contents”.
  • Page 29 Controlling the Monitor with a PC (RS-232C) Others Function Command Direction Parameter Reply Control/Response contents SCREEN SIZE WIDE 1-5 1: WIDE, 2: NORMAL, 3: Dot by Dot, 4: ZOOM1, 5: ZOOM2 (DVI-D, D-SUB) SCREEN SIZE WIDE 1-5 1: WIDE, 2: ZOOM1, 3: ZOOM2, 4: NORMAL, 5: Dot by Dot (HDMI, COMPONENT, VIDEO) VOLUME VOLM...

  • Page 30: Troubleshooting

    Internal temperature rises quickly if the vents on the monitor are blocked. - Internal temperature rises quickly if dust accumulates inside the monitor or around the vents. Remove dust if possible. Ask Sharp dealer about removing internal dust.

  • Page 31: Specifications

    D-SUB input (factory default setting) As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from...
  • Page 32 When mounting the monitor, be sure to use a wall-mount bracket that complies with the VESA-compatible mounting method. SHARP recommends using M6 screws and tighten the screws. Note that screw hole depth of the monitor is 3/8 inch (10 mm). Loose mounting may cause the product to fall, resulting in serious personal injuries as well as damage to the product.
  • Page 33 Specifications nCompatible signal timing (PC) Digital Screen resolution Hsync Vsync Dot frequency Analog DVI-D HDMI VESA 640 × 480 31.5kHz 60Hz 25.175MHz 37.9kHz 72Hz 31.5MHz 37.5kHz 75Hz 31.5MHz 800 × 600 35.1kHz 56Hz 36.0MHz 37.9kHz 60Hz 40.0MHz 48.1kHz 72Hz 50.0MHz 46.9kHz 75Hz 49.5MHz...
  • Page 34 Specifications nCompatible signal timing (AV) Screen resolution Frequency DVI-D HDMI Component 1920 × 1080p * 24Hz 50Hz 59.94Hz 60Hz 1920 × 1080i * 50Hz 59.94Hz 60Hz 1280 × 720p 50Hz 59.94Hz 60Hz 720 × 576p 50Hz 720 × 480p 59.94Hz 60Hz 720(1440) ×...
  • Page 35 PN-T322B M EN11D(1)
