HP Server Slide Mount Kit AB294A
for NEBS 2000 Rack

Installation Instructions

Manufacturing Part Number: AB294-96001
April 2004
U.S.A.
© Copyright 2004 Hewlett-Packard Development Company, L.P..

Advertisement

Table of Contents

   Also See for HP Integrity cx2600

   Related Manuals for HP Integrity cx2600

   Summary of Contents for HP Integrity cx2600

  • Page 1: Installation Instructions

    HP Server Slide Mount Kit AB294A for NEBS 2000 Rack Installation Instructions Manufacturing Part Number: AB294-96001 April 2004 U.S.A. © Copyright 2004 Hewlett-Packard Development Company, L.P..
  • Page 2: Legal Notices

    Legal Notices Copyright Notices. © Copyright 2004 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
  • Page 3 HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions Introduction This manual provides instructions for installation of the hp Integrity cx2600 server chassis on slides in a NEBS 2000 rack. Cabinet Safety Precautions WARNING Ensure that the rack is level and stable before working on the rack. Be sure the leveling jacks (feet) extend to the floor and that the full weight of the rack rests firmly on the floor.
  • Page 4 HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions Introduction Mounting Kit Contents This manual provides installation instructions for server mount kit AB294A. This kit is intended for use with the hp Integrity cx2600 server, and includes the following: • Two Slide Assemblies •...
  • Page 5: Installation Procedure

    HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions Installation Procedure Installation Procedure Figure 1-1 HP Integrity cx2600 Servers Mounted in a NEBS 2000 Rack 2600inrack1 Mounting Kit Before mounting your server in the NEBS 2000 rack, inspect the mounting kit hardware. Check that all required mounting hardware is available.
  • Page 6 HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions Installation Procedure Figure 1-2Attach the Cable Routing Brackets and Inner Slides to the Server Cable Routing Brackets Waferscrews Inner Slide Rail Inner Slide Rail chasrails1 Step 3. Remove the inner rail assemblies (inside track slides) from the slide assemblies and attach an inner rail to each side of the server chassis with T15 waferscrews.
  • Page 7 HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions Installation Procedure Step 6. Tighten the rear screws (loosened in step 4) on the outer slide rails. Step 7. Install the rack mount retainer bars on the inner side of each column, above the slides as shown in Figure 1-3.
  • Page 8 HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions AB294A Rack Mount Kit AB294A Rack Mount Kit The HP Server Mounting Kit, part number AB294A includes the items listed below. Table 1-1 Mounting Kit Parts List Item Quantity HP Part Number Slide assembly...
