Telephone
Paging Amplifier
Model TPU15A
Description
The Bogen Model TPU15A is a unique 15-watt, wall-
mounting amplifier, specifically designed for telephone
paging applications. This compact unit provides
voice-activated muting of music when paging,
completely eliminating the need for manual activation
of switches and the use of external relays. The page
channel features automatic output leveling (ALC) as
channel input varies, which is particularly important in
Features
Compact wall-mount design
Inputs for 600-ohm balanced telephone line
and background music
25V, 70V, or 8-ohm output
Built-in night ringer triggered by external
contact closure
Integral automatic level control (ALC) circuit
Signal-activated music muting circuit
telephone paging applications, where persons with
varying voice levels and paging techniques have
access to the system.
Installation and maintenance are simple; all connec-
tions, adjustments, and mounting are accomplished
with a screwdriver.
Individual controls for tone, page volume, back-
ground music volume, night ringer volume
Lo-cut switch
LED overload indicator
Circuit breaker
Black finish
Listed to UL Standard 60065 for U.S. & Canada
Specifications subject to change without notice.
© 1995 Bogen Communications, Inc.
Part No. 54-7797-03D 1210

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPU15A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bogen TPU15A

  • Page 1 Telephone Paging Amplifier Model TPU15A Description The Bogen Model TPU15A is a unique 15-watt, wall- telephone paging applications, where persons with mounting amplifier, specifically designed for telephone varying voice levels and paging techniques have paging applications. This compact unit provides access to the system.
  • Page 2 The telephone paging amplifier shall be a Bogen The amplifier components shall mount directly to a Architect Model TPU15A, or equivalent, with a power rating wall. Electronic circuitry shall provide voice-activated and Engineer of 15 watts. Distortion shall be less than 2%.
