Electrical Specifications

OPEN COLLECTOR OUTPUTS
LEDs (LED, OUT1 and OUT2) for each door reader
Buzzer (Buz) for each door reader
OUTPUTS
1 for 12 VDC Auxiliary Power (11.2 to 13.75 VDC) polyswitch
protected, shared with SPI expansion port
4 for Controlled Readers (11.2 to 13.75 VDC)
4 for Controlled Readers 5 VDC
4 for Locks (11.2 to 13.75 VDC) when jumper JP4 is on INT
(internal)
4 for Locks (11.2 to 28 VDC) when jumper JP4 is on EXT
(external)

KT-400 Ethernet Four-Door Controller Models, Expansion Modules Models,

Related Documentation and Miscellaneous Items
Part number
KT-400 KT-400 Ethernet Four-Door Controller, IP Ready with Accessory Kit in Metal Cabinet, see Table 2
KT-400-PCB KT-400 Ethernet Four-Door Controller PCB only, IP Ready with Accessory Kit, see Table 2
KT-400-CAB KT-400 Black Metal Cabinet with Lock and Keys, see Table 2
KT-MOD-INP16 KT-400 Expansion Module 16-Zone Inputs with SPI Cable 41 cm (16 in)
KT-MOD-REL8 KT-400 Expansion Module 8-Relay with SPI Cable 41 cm (16 in)
KT-MOD-OUT16 KT-400 Expansion Module 16-Output with SPI Cable 41 cm (16 in)
KT-MOD-CAB KT-400 Expansion Module Cabinet, Black, with SPI Cable 91 cm (36 in), Lock and Two Keys
KT-MOD-SPI16 KT-400 SPI Cable 41 cm (16 in) for SPI Interconnection within the Cabinet
KT-MOD-SPI36 KT-400 SPI Cable 91 cm (36 in) for SPI Interconnection between Cabinets
DN1420 EntraPass Special Edition, Reference Manual - English version
DN1415 EntraPass Corporate Edition, Reference Manual - English version
DN1316 EntraPass Global Edition, Reference Manual - English version
DN1474 EntraPass Special Edition, Reference Manual - French version
DN1435 EntraPass Corporate Edition, Reference Manual - French version
DN1289 EntraPass Global Edition, Reference Manual - French version
16
KT-400 Ethernet Four-Door Controller Models
Expansion Modules Models
Related Documentation
DN1726-0811
MAXIMUM CURRENT
(Typical)
25 mA (each)
25 mA (each)
MAXIMUM CURRENT
500 mA
500 mA
400 mA
1 Amp for KT-400
3 Amp
Description
COMBINED MAXIMUM
CURRENT
2 Amps for KT-400
