Technical Specifications - Kantech Ethernet Four-Door Controller KT-400 Installation Manual

Technical Specifications

Type
Power input (KT-400)
Battery back-up (KT-BATT-12)
Operating Temperatures
Humidity Level
Cabinet Dimensions
(High-Wide-Deep)
Cabinet Weight (KT-400)
PCB dimension
Reader types
Reader power output
Monitored points (inputs)
Points maximum wiring
Door strike power
Reader outputs
Auxiliary outputs
Relay controlled output
Communication ports
Expansion port
Auxiliary port
Communication speed
Flash memory
RAM memory
Network autonomy
Certifications / Listing
KT-400 Ethernet Four-Door Controller Installation Manual
Transformer class 2, IN 120 VAC; OUT 16 VAC, 75 VA
12 VDC, 7 Ah battery supervised, provides up to 12 hours of operation
From 2°C to 49°C (35°F to 120°F) indoor use only
0 to 85% (relative humidity non-condensing).
37.59 cm (14.8 in) x 30.48 cm (12.0 in) x 12.57 cm (4.95 in)
4.0 kg (8.82 lb)
22.86 cm (9 in) X 13.97 cm (5.5 in) X 5.20 cm (2.04 in)
Wiegand, proximity, ABA Clock and Data, bar code, magnetic, integrated keypad,
smartcard and others
12 VDC and 5 VDC @ 175 mA max each, protected and supervised
16 monitored points, single EOL (End of Line), double EOL, without EOL and
1 fixed-function tamper switch input
AWG #22 - 600 m (2,000 ft)
12 VDC, 250 mA max for KT-400 supervised
16 outputs, 25mA max each, open collector outputs
LEDs (LED, OUT1 and OUT2) and buzzer (Buz) for each individual door, 25mA max each,
open collector outputs
4 onboard Form C Relay controlled outputs, 30 VDC, 3 Amps max each
1 x RS-232 with RJ-12, 1 x RS-485, 1 x Ethernet 10/100Base-T with RJ-45
1 x SPI 6-pin connector, bidirectional data exchange supported. Supplies 12 VDC, 500 mA
max shared with 12 VDC Auxiliary port
1 x Auxiliary 12 VDC, 500 mA maximum shared with SPI expansion port
- Up to 115200 Bauds (automatic detection) over RS-232 and RS-485
- 10/100 Mb/s BaseT over Ethernet
16 MB for application storage
64 MB for application loading and running, protected by a Lithium-Ion battery for a
minimum of 75 hours
Distributed data and processing
EN55022, EN61000-6-1, EN61000-6-2
FCC: Class A
UL 294, UL 1076
DN1726-0811
Description
15
