1 data/power cable
5. Replace the computer cover (see
6. Verify that your computer works correctly by running the Dell Diagnostics (see

Optical Drive

CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before replacing the cover.

Removing an Optical Drive

1. Follow the procedures in Before You
2. Remove the computer cover (see
3. Disconnect the power and data cables from the back of the drive.
4. Grasp the sliding plate lever and slide it towards the top of the computer until the drive panel snaps open; while holding the lever in place, slide the
drive out of the computer.
1 optical drive
Installing an Optical Drive
1. Follow the procedures in Before You
2. Remove the computer cover (see
3. If you are replacing an optical drive, remove the shoulder screws from the existing drive and attach the screws to the replacement drive.
4. If you are installing a new optical drive, remove the drive-panel insert, remove the shoulder screws from the inside of the drive-panel insert, and attach
the screws to the new drive.
2 media card reader
Replacing the Computer Cover).
Begin.
Removing the Computer Cover).
2 drive release latch
Begin.
Removing the Computer Cover).
Dell Diagnostics).
