- Page 1 Owner’s Manual Dishwasher ZBD6400 ZBD6500 ZBD6600 ZBD6700 ZBD6900 ZBD7000 ZBD7100...
-
Page 2: Table Of Contents
Operating Instructions ....8–19 Control Panel and settings for ZBD6400 and ZBD6500 ... . .8, 9 Control Panel and settings for ZBD6600 . -
Page 3: Consumer Services
Explain why you are not pleased. In most cases, this will solve the problem. NEXT, if you are still not pleased, write all the details—including your phone number—to: Manager, Customer Relations GE Appliances Appliance Park Louisville, KY 40225 Consumer Information Dishwasher If you don’t understand something or need... -
Page 4: Safety Instructions
Before You Throw Away Your Old Dishwasher: •Take off the door of the washing compartment or remove the door latch keeper (as shown). AVERTISSEMENT! RISQUE D’ENFANT MIS AU PIÈGE BONNE DISPOSITION DU LAVE-VAISSELLE Les machines à laver la vaisselle abandonnée ou jetée sont dangereuses...même si elles sont... -
Page 5: Water Heater Safety
WATER HEATER SAFETY Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. SÉCURITÉ DU CHAUFFE-EAU Dans certaines conditions, il peut se former de l’hydrogène à... - Page 6 PROPER INSTALLATION AND MAINTENANCE This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by visiting our Website at www.monogram.com.
-
Page 7: Save These Instructions
WHEN USING YOUR DISHWASHER Use this appliance only for its intended purpose as described in this Owner’s Manual. CAUTION: in Sanitization cycle may be hot to the touch. Use care before unloading. •Use only powder, tabs or liquid detergents or wetting agents recommended for use in a dishwasher and keep them out of the reach of children. -
Page 8: Operating Instructions
CRYSTAL SANI WASH NOTE: NSF certified residential dishwashers are not intended for licensed food establishments. Control Panel — ZBD6400 & ZBD6500 Cycle Selections This display tells you what is happening while the dishwasher is in operation. All of the Cycle Status Indicators will flash on and off if either the door is opened during a cycle or if the cycle has been paused. - Page 9 If you have selected a new wash cycle, remember to add more detergent to the detergent compartment if required. Control Panel/Operation — ZBD6400 & ZBD6500 will extend the cycle by 30 minutes. When this is NOT selected, the fan will turn on to dry your dishes without added heat—and energy is saved.
-
Page 10: Control Panel And Settings For Zbd6600
You can locate ZBD6600 your model number on the inside upper tub flange. Throughout this manual, features and appearance may var y from your model. 1. WASH CYCLES Knob—Use to select the desired wash cycle based on dishware and soil level. Control Settings POTS &... - Page 11 Start a To start the dishwasher, close the door until it locks in place. To start the last selected cycle, press the START button. To select a different cycle, turn the knobs to the desired WASH CYCLE and wash load HEAT OPTIONS and press the START button.
-
Page 12: Zbd6700 And Zbd6900
You can locate ZBD6700 & ZBD6900 your model number on the inside upper tub flange. Throughout this manual, features and appearance may var y from your model. 1. Cycle Status Control Indicators— Settings SENSING WASHING RINSING DRYING CLEAN 2. Cycle Selections—The light on the selected pad will illuminate to indicate which cycle has been POTS &... - Page 13 3. SMART DRY— 4. WATER TEMP— This button provides extra heat options to increase water temperature for NORMAL HIGH SANI NOTE: NSF certified residential dishwashers are not intended for licensed food establishments. 5. DELAY START—This option will allow you to delay the start time of any wash cycle except •...
-
Page 14: Zbd7000 And Zbd7100
You can locate ZBD7000 & ZBD7100 your model number on the inside upper tub flange. Throughout this manual, features and appearance may var y from your model. 1. Cycle Selections—The light on the selected pad will illuminate to indicate which cycle has been Control Settings POTS &... - Page 15 4. DELAY START—This option will allow you to delay the start time of any wash cycle except Control RINSE ONLY for up to 6 hours. Settings • Select the delay start time you want by pressing the DELAY START button. Multiple pressing will alternate the delay time between 2, 4 or 6 hours and OFF.
-
Page 16: Clean Sensor
Features — ZBD6400, ZBD6500, ZBD6700, ZBD6900, ZBD7000 & ZBD7100 The Clean Sensor monitors the circulating water during the cycles and sets the water temperature Clean and cycle length to match soil levels. Cycle length is automatically increased to handle increasing Sensor levels of soil. -
Page 17: Water Temperature
The entering water must be at least 120°F Water (49°C) and not more than 150°F (66°C), for Temperature effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet A rinse agent improves dry performance, Use a Rinse reduces spots and prevents new film build-up... -
Page 18: Dishwasher Racks
Upper Rack The upper rack is for glasses, cups, bowls and saucers. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics. The cup shelf may be placed in the up or down position to add flexibility. - Page 19 Features and appearance of racks and silverware baskets may vary from your model. Silverware Put flatware in the removable basket with fork and knife handles up to protect your hands. Place spoons in the basket with handles down. Mix knives, forks and spoons so they don’t nest together. Basket Distribute evenly.
-
Page 20: Care And Cleaning
Use stainless steel cleaner on stainless steel panel. You can order Stainless Steel Magic # WX10X15 through GE Parts in the USA, by calling 800.626.2002. In Canada, call 1.888.880.3030. The stainless steel tub can be cleaned with Stainless Steel Magic or a similar product using Interior a clean, soft cloth. - Page 21 Periodically, remove and clean the spray arms Removing to make sure that none of the nozzles have and Cleaning become blocked. the Spray To remove the lower spray arm, grasp the Arms and center of the spray arm and pull upwards, it Glass Trap will unclip.
- Page 22 In addition to the glass trap, your dishwasher The Wash has three fine filters— Filters • a two piece round perforated stainless steel filter located in the base of the dishwasher. • a finer micro-mesh filter located under the stainless steel filter. •...
-
Page 23: Optional Accessories
You can change the door panel appearance of your dishwasher by ordering one of these Dishwasher’s optional accessories: Appearance for • 1/4″ Wood Panel Trim Kit ZBD6400 and ZBD6500 only • 3/4″ Trimless Panel Kit Care and Cleaning/Optional Accessories ZPF625B (Black) ZPF625W (White) -
Page 24: Before You Call For Service
PROBLEM Questions? Dishwasher will not run Use this problem solver Unusual noises Detergent left in dispenser cups Water will not pump out of the tub Before You Call For Service POSSIBLE CAUSE WHAT TO DO Door not properly closed • Press door until it clicks shut. Door is opened during •... - Page 25 PROBLEM Questions? Use this Suds in the tub problem solver Dishes and flatware not clean POSSIBLE CAUSE WHAT TO DO Correct detergent • Use only automatic dishwasher detergents was not used to avoid sudsing. • To remove suds from the tub, open the dishwasher and let suds evaporate.
- Page 26 Questions? PROBLEM Use this Spots and filming on glasses and flatware problem solver Cloudiness on glassware Black or gray marks on dishes Dishes do not dry Water leaks through door handle Before You Call For Service POSSIBLE CAUSE WHAT TO DO Extremely hard water •...
- Page 27 Child Lockout mode is • Press and hold desired button for two selected seconds. See Child Lockout mode section for models ZBD6400, ZBD6500, ZBD6700, ZBD6900, ZBD7000 and ZBD7100. Power supply not • Check dishwasher is plugged in and switch connected is on.
- Page 28 800.626.2000 Service Contracts You can have the secure feeling that GE Consumer Service will still be there after your warranty expires. Purchase a GE contract while your warranty is still in effect and you’ll receive a substantial discount. With a multiple-year contract, you’re assured of future In the USA: service at today’s prices.
-
Page 29: Usa Warranty
Any part of the dishwasher which fails due to a defect in materials or workmanship. During this COVERED full one-year warranty, GE will also provide, free of charge, all labor and in-home service to From the Date replace the defective part. -
Page 30: Canada Warranty
Any part of the dishwasher which fails due to a defect in materials or workmanship. During this COVERED full one-year warranty, GE will also provide, free of charge, all labor and in-home service to From the Date replace the defective part. -
Page 31: Appliance Registration
Today Registration Product General Electric Company Warranty Registration Department P.O. Box 32150 Louisville, KY 40232-2150 Important Mail Ownership Consumer Appliances Place 1st Class Letter Stamp Here... - Page 32 Consumer Product Ownership Registration Dear Customer: Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer! Follow these three steps to protect your new appliance investment: Complete and mail your Consumer Product Ownership...
