Installation
Instructions
If you have questions, call 800.626.2000 or visit our website at: www.monogram.com
Built-In Dishwashers
ZBD6400, ZBD6500, ZBD6600
ZBD6700, ZBD6900, ZBD7000,
ZBD7100
Chef's Washers
ZBD6605, ZBD6905, ZBD7005,
ZBD7105
Design Guide with
Installation Instructions
Monogram.
We bring good things to life.
®
Advertisement
Table of Contents
Related Manuals for GE Monogram ZBD6400
Summary of Contents for GE Monogram ZBD6400
- Page 1 Installation Instructions If you have questions, call 800.626.2000 or visit our website at: www.monogram.com Built-In Dishwashers ZBD6400, ZBD6500, ZBD6600 ZBD6700, ZBD6900, ZBD7000, ZBD7100 Chef’s Washers ZBD6605, ZBD6905, ZBD7005, ZBD7105 Design Guide with Installation Instructions Monogram. We bring good things to life.
-
Page 2: Table Of Contents
Prepare Dishwasher Enclosure ... 5 Drain Requirements ...6 Prepare Electrical Wiring ...7 Prepare Hot Water Line ...8 Custom Panel Dimensions Custom Panels for ZBD6400 ... 9 Custom Panels for ZBD7000, ZBD7005 ...9 Safety Information IMPORTANT – • be installed to allow for future removal from the enclosure if service is required. -
Page 3: Design Information
35" *24" 23-7/8" DISHWASHER MODELS Traditional Built-In ZBD6400 BB, Black - Accepts 1/4" or 3/4" custom panels ZBD6400 WW White - Accepts 1/4" or 3/4" custom panels Trim Kits for models ZBD6400 • ZPF625W (white) or ZPF625B (black) custom panel kits, supports a 1/4"... -
Page 4: Installation Preparation
MATERIALS YOU WILL NEED: Materials Required for All Installations 90 Elbow (3/8”NPT external thread on one end, opposite end sized to fit water supply) Note: Use new ferrule. Do not use old parts. Strain relief for electrical connection Thread seal tape UL Listed wire connectors (3) Screw type hose clamps Materials For New Installations Only:... -
Page 5: Parts Supplied
PARTS SUPPLIED: Remove the hardware accessory bag and other parts from inside or taped to the outside of the dishwasher. Check contents against illustrations to insure that all parts are included. 2-piece toekick 6 screws (see illustration) 2 leveling legs Template for the installation of a custom panel packed with models ZBD7000 and ZBD7005 only... -
Page 6: Drain Requirements
Installation Preparation DRAIN REQUIREMENTS • Follow local codes and ordinances. • Do not exceed 10 feet distance to drain. • To prevent back flow into the dishwasher, connect drain line to an air gap or use a 30” high drain loop, depending on local codes. -
Page 7: Prepare Electrical Wiring
PREPARE ELECTRICAL WIRING FOR PERSONAL SAFETY: Remove house fuse or open circuit breaker before beginning installation. Do not use an extension cord or adapter plug with this appliance. AVERTISSEMENT POUR ASSURER LA SÉCURITÉ PERSONNELLE, il faut enlever le fusible ou couper le courant au disjoncteur avant de commencer l’installation. -
Page 8: Prepare Hot Water Line
PREPARE HOT WATER LINE The line may enter from either side, rear or floor within the shaded area shown. • The water line may pass through the same hole as the electrical cable and drain hose. Or, cut an additional 1-1/2" dia. hole to admit the line. If a power cord with plug is used, it must pass through a separate hole. -
Page 9: Custom Panel Dimensions
Custom Panel Dimensions CUSTOM PANEL FOR MODELS ZBD6400 ONLY Panel kits must be ordered separately. Installation of any custom panel should be completed before the dishwasher is installed. 1/4" PANEL WITH ZPF625 TRIM KIT 1/4" Thick Door Panel 1/4" Radius 23-1/8"... -
Page 10: Installation Instructions
BEFORE YOU BEGIN: CUSTOM PANEL INSTALLATION: If you intend to install custom door panels, (on some models) refer to trim kit installation instructions. Custom panels should be in place before installing the dishwasher. STEP 1 REMOVE PACKAGING Cut the shipping carton and use it as a pad beneath the dishwasher. -
Page 11: Step 5 Install Power Cord
STEP 5 INSTALL POWER CORD SKIP THIS STEP IF DISHWASHER WILL BE DIRECT WIRED • Maximum power cord length is 6 ft. • The power cord and connections must comply with the National Electrical Code, Section 422 and/or local codes and ordinances. Insert power cord wires through strain relief and tighten. -
Page 12: Step 9 Connect Drain Line
Installation Instructions STEP 9 CONNECT DRAIN LINE FOLLOW ALL LOCAL CODES AND ORDINANCES. • The dishwasher is supplied with a 72" long drain hose. • If a longer drain hose is required, add up to 48” of length for a total of 10 ft. length. •... -
Page 13: Step 11, Position And Level Dishwasher
STEP 11 POSITION AND LEVEL THE DISHWASHER • Check to be sure the dishwasher is adjusted to correct height and is centered in the cutout. • Open and close the door to insure proper operation of the door. If there is any binding or rubbing, readjust leveling legs. -
Page 14: Step 14 Secure Dishwasher
STEP 14 SECURE DISHWASHER TO CABINET AND COUNTERTOP To maintain position and alignment, the dishwasher must be secured to the countertop and adjacent cabinets. Secure dishwasher to countertop: • Drill pilot holes through the mounting bracket and into the underside of the countertop. Secure with screws A provided. -
Page 15: Panel Installation For Models Zbd7000 And Zbd7005
Panel Installation for Models ZBD7000 and ZBD7005 The custom panel should be prepared by your cabinet manufacturer according to the instructions shown on page 9. Use the supplied installation template to locate the mounting screws for the door. STEP 1 DRAW CENTERLINE •... - Page 16 Note: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram 1-800-444-1845. Note: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice. Monogram. ®...
