Lanzar SVDVD3 Owner's Manual

Mobile video system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
EJECT
DISPLAY
POWER
OSD
AUX
STOP
PLAY/PAUSE
MUTE
MENU
SUBTITLE
AUDIO
TITLE
SLOW
PBC
REPEAT
ANGLE
A-B
GOTO
ZOOM
ENTER
1
2
3
4
5
6
7
8
9
0
SETUP
+10
•
Multi-subtitle Languages Function
•
Multi-audio Languages Function
•
Multi-angle Function
•
Parental Control
•
Built-in FM Modulator
SVDVD3
Mobile Video System
www.lanzar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVDVD3 and is the answer not in the manual?

Questions and answers

Related Manuals for Lanzar SVDVD3

Summary of Contents for Lanzar SVDVD3

  • Page 1 SVDVD3 OWNER'S MANUAL Mobile Video System EJECT DISPLAY POWER STOP PLAY/PAUSE MUTE MENU SUBTITLE AUDIO TITLE SLOW REPEAT ANGLE GOTO ZOOM ENTER SETUP • Multi-subtitle Languages Function • Multi-audio Languages Function • Multi-angle Function • Parental Control • Built-in FM Modulator...

  • Page 2: Use This Product Safely

    FEATURES Use Authorized Service Centres Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD) Do not attempt to disassemble or adjust this precision product. Please This player can play discs recorded in refer to the Service Centre list included either PAL or NTSC format.

  • Page 3: Table Of Contents

    CONTENTS Safety Information ..................4 Disc Notes .....................5 Installation .....................6 Electric Connection ..................7 Remote Control.....................8 Preparing the Remote Control..................9 Basic Operation ..................10 On-Screen Display Function ..................11 Multi-audio Language Function .................11 Title Menu Function (For DVD only)................12 Multi-subtitle Language Function (For DVD only)............12 Multi-angle Function (For DVD only) ................12 MP3 Disc Play ......................12 Using the FM modulator (For FM modulator version only).........12...

  • Page 4: Safety Information

    SAFETY INFORMATION CAUTION: Region Management Information: MOBILE DVD PLAYER IS A CLASS I This Mobile DVD Player is designed and LASER PRODUCT. HOWEVER THIS manufactured to respond to the Region MOBILE DVD PLAYER USES A Management Information that is recorded VISIBLE/INVISIBLE LASER BEAM on a DVD disc.

  • Page 5: Disc Notes

    DISC NOTES Disc formats supported by this player Note these scratches are not an indication of any problem with the player. 12 cm disc Label side up (Single-sided disc only) Video CD 12 cm disc Do not touch the underside 12 cm disc of the disc 12 cm disc...

  • Page 6: Installation

    INSTALLATION SCREW M5x25 SCREWS LOCKED THE UNIT CORE SCREW M4x6 SCREW M4x6 Note: 1. First remove the two screws that locket the unit core, then attach the brackets on both sides of unit with screws (M4x6), last install the unit with screws (M5x25). 2.

  • Page 7: Electric Connection

    ELECTRIC CONNECTION DVD PLAYER DC 12 V IN DC 12 V OUT A/V OUT DIGITAL REMOTE L/R VIDEO AUDIO YELLOW BLACK YELLOW BLACK VIDEO OUT AUDIO R OUT AC/DC WHITE ADAPTOR AUDIO L OUT (OPTIONAL) (OPTIONAL) DIGITAL AUDIO REMOTE CONTROL RECEIVER FUSE CIGARETTE LIGHTER CIGARETTE LIGHTER...

  • Page 8: Remote Control

    REMOTE CONTROL EJECT DISPLAY POWER STOP PLAY/PAUSE MUTE MENU SUBTITLE AUDIO TITLE SLOW REPEAT ANGLE GOTO ZOOM ENTER SETUP Press the AUX to switch to external Audio/Video input. (AUX is enabled in Disc Mode only) EJECT Press it to eject the disc from the disc compartment. STOP Press it to stop playback.

  • Page 9: Preparing The Remote Control

    REMOTE CONTROL PREPARING THE REMOTE CONTROL Inserting the Batteries 1. Remove the battery cover as the direction indicated by the arrow. 2. Put the batteries properly with the positive and negative terminals of the batteries are oriented indicated. 3. Close the battery cover. Using the Remote Control Face the remote control towards the player front face IR mark (remote control signal receiver).

  • Page 10: Basic Operation

    BASIC OPERATION Note: For VCD, in any slow mode, press ENTER button to return to normal playback. Pause (still picture) Pressing during playback will stop REMOTE play temporary. Return to normal playback, press once again. Loading a DVD/VCD/CD Disc Repeat 1.

  • Page 11: On-Screen Display Function

    BASIC OPERATION On-Screen Display Function (2) Press DISPLAY for the second time: Press the DISPLAY button during playback to display the contents of the T: 03/17 P: 00:01:25 current disc on the screen. Example: SINGLE REMAIN DVD: (3) Press DISPLAY for the third time: (1) Press DISPLAY for the first time: T: 03/17 P: 00:01:25 T: 01/03 C: 002/025...

  • Page 12: Title Menu Function (For Dvd Only)

    BASIC OPERATION TITLE Menu Function MP3 Disc Play MP3 disc is playing in the DISC REPEAT mode by default. If the DVD has multiple titles recorded on For example: the disc. It can select preferred title from the title menu to start playback. Mp3 PLAYER 1.

  • Page 13: Setup

    SET UP INITIAL SETUP GENERAL SETUP SETUP MENU --- MAIN PAGE --- GENERAL PAGE --- GENERAL SETUP TV DISPLAY NORMAL/PS SPEAKER SETUP PIC MODE NORMAL/LB AUDIO SETUP ANGLE MARK WIDE PREFERENCES OSD LANG CAPTIONS SCR SAVER EXIT SETUP FM FREQUENCY 1.
  • Page 14 SET UP --- GENERAL PAGE --- --- GENERAL PAGE --- TV DISPLAY TV DISPLAY PIC MODE AUTO PIC MODE ANGLE MARK HI-RES ANGLE MARK OSD LANG N-FLICKER OSD LANG ENGLISH CAPTIONS CAPTIONS FRENCH SCR SAVER SCR SAVER GERMAN FM FREQUENCY FM FREQUENCY ITALIAN SPANISH...

  • Page 15: Speaker Setup

    SET UP --- GENERAL PAGE --- SPEAKER SETUP --- SPEAKER SETUP PAGE --- TV DISPLAY DOWNMIX LT/RT PIC MODE STEREO ANGLE MARK MAIN PAGE OSD LANG CAPTIONS SCR SAVER FM FREQUENCY MAIN PAGE SCR SAVER setup This is to activate the audio output from Select the SCR SAVER output ON/OFF.

  • Page 16: Preferences Setup

    SET UP --- AUDIO SETUP --- --- AUDIO SETUP --- AUDIO OUT AUDIO OUT OP MODE LINE OUT OP MODE DYNAMIC RF REMOD DYNAMIC LPCM OUTPUT LPCM OUTPUT LPCM 48K LPCM 96K MAIN PAGE MAIN PAGE OP MODE LPCM OUTPUT There are two operating modes for the Select the LPCM OUTPUT between Dolby Digital decoder: LINE OUT and...
  • Page 17 SET UP --- PREFERENCES PAGE --- --- PREFERENCES PAGE --- TV TYPE TV TYPE AUDIO AUDIO ENGLISH SUBTITLE FRENCH SUBTITLE DISC MENU DISC MENU SPANISH ENGLISH PARENTAL CHINESE PARENTAL FRENCH PASSWORD PASSWORD JAPANESE SPANISH DEFAULTS GERMAN DEFAULTS CHINESE FM MODULATOR FM MODULATOR ITALIAN JAPANESE...
  • Page 18 SET UP --- PREFERENCES PAGE --- --- PREFERENCES PAGE --- TV TYPE TV TYPE AUDIO AUDIO SUBTITLE SUBTITLE DISC MENU DISC MENU PARENTAL PARENTAL PASSWORD PASSWORD CHANGE DEFAULTS DEFAULTS FM MODULATOR FM MODULATOR MP3 PLAYER MP3 PLAYER MAIN PAGE MAIN PAGE PASSWORD FM Modulator ON/OFF setup Select the change and press ENTER...

  • Page 19: Defaults Table

    SET UP DEFAULTS TABLE General Setup TV Display Normal/PS PIC Mode AUTO Angle Mark OSD Language English Captions SCR Saver Speaker Setup Downmix Stereo Audio Setup Audio Out Analog OP Mode Line Out Dynamic FULL LPCM Output LPCM 96K Preferences TV Type AUTO Audio English...

  • Page 20: Specifications

    SPECIFICATIONS Supply Voltage : 12V DC (11V-15V), test voltage 14.4V, negative ground Current Consumption : Less than 2A Signal System : Compositive video 1.0Vp-p 75 Discs Played : (1) DVD-VIDEO Disc 5” (12 cm) single-sided, single-layer 5” (12 cm) single-sided, double-layer (2) Compact Disc (CD-DA, VIDEO CD) 5”...
