- Page 1 USB 3.0 Camera User’s Guide Rev 1.0 Leopard Imaging Inc. June, 2013...
-
Page 2: About This Manual
The information in this document is subject to change without notice. Copyright © Copyright 2011 This manual contains proprietary information, protected by copyright. All rights reserved. Contact Information Leopard Imaging Inc. 1130 Cadillac CT Milpitas, CA 95035 Phone: (408) 263-0988 Fax: (408) 217-1960 Email: sales@leopardimaging.com Technical Support: support@leopardimaging.com... -
Page 3: Table Of Contents
USB 3.0 Camera User’s Guide Contents Introduction ........................... 4 Package contents ........................... 4 Product Introduction ......................5 1.1 Product outline ........................5 1.2 Key features ........................5 1.3 Applications ........................6 1.4 Device Requirements ......................6 1.5 Temperature and Humidity ..................... 6 Product Views ........................ -
Page 4: Introduction
USB 3.0 Camera User’s Guide Introduction This section covers unpacking your new USB 3.0 camera, its key features, Applications and basic technical information about the Sensor boards. Refer to later chapters for information on setting up and configuring the product in more detail. -
Page 5: Product Introduction
USB 3.0 Camera User’s Guide 1. Product Introduction 1.1 Product outline Leopard Imaging USB 3.0 camera is new generation supper speed USB Video camera which supports more than 3G video bandwidth to stream 1080p 30fps video without compression, it provides sharper and high quality... -
Page 6: Applications
32 bit / 64 bit Microsoft Windows 7 32 bit / 64 bit Microsoft Windows 8 Software Leopard Imaging Camera USB3.0 Demo Software GraphEdit AMcap Other video capture softwate 1.5 Temperature and Humidity Housing temperature during operation: 0 ° C ~ 50 ° C (32 ° F~ 122 ° F) ... -
Page 7: Product Views
Main board mainly includes FX3 USB 3.0 Controller, Power Management, USB 3.0 connector interface, Dual 26-PIN 1.27mm socket for Sensor board interface. 2.2 Sensor Boards Figure 2: Sensor Board Leopard Imaging USB 3.0 Camera supports different sensor boards from different manufacturers. Technical Specs: LI-USB30-V034... - Page 8 CS / M12 lens mount support (Default: M12 lens) Interface USB 3.0 interface Power USB 3.0 +5VDC power source Compact size 26mmx26mm Part# LI-USB30-V034 Machine Vision Application Medical Camera Scientific Camera LI-USB30-M021 Sensor Aptina MT9M021 Global Shutter 720p HD Sensor...
- Page 9 USB 3.0 Camera User’s Guide Power USB 3.0 +5VDC power source Compact size 26mmx26mm Part# LI-USB30-M034WDR Machine Vision Application Medical Camera Video Conference Scientific Camera LI-USB30-AR0330ICP Sensor Aptina AR0330 3Mega-pixel Sensor Active pixel 2304H x 1536V Frame rate 30fps Optical format...
- Page 10 USB 3.0 Camera User’s Guide Machine Vision Application Medical Camera Scientific Camera LI-USB30-V034STEREO Sensor Aptina MT9V034 Global Shutter WVGA Sensor Active Pixels 752H x 480V Frame rate 60fps stereo output Optical format 1/3" Pixel size 6.0x6.0um Global Shutter For high speed application Color Monochrome...
-
Page 11: Product Dimensions
USB 3.0 Camera User’s Guide 2.3 Product Dimensions (mm) -
Page 12: System Installation
USB 3.0 Camera User’s Guide 3. System Installation 3.1 Install USB 3.0 Demo Software 1) Download CameraUSB30Demo software from LeopardImaging Website. 2) Click Setup.exe, then click Next. 3) In next window, choose the folder to which you want to install the software, then click Next. - Page 13 USB 3.0 Camera User’s Guide 5) If there is a User Account Control pop up window, click Yes. 6) The software will be installed to your PC. 7) After Installation completes, click Close to close the window.
-
Page 14: Install Driver
USB 3.0 Camera User’s Guide 3.2 Install Driver 1) Connect the USB 3.0 cable to camera. 2) Plug the USB into USB 3.0 port on PC. 3) PC will search and install driver automatically. 4) After install the driver, you can find it in Device Manager. 4. - Page 15 USB 3.0 Camera User’s Guide 2) Properties...
-
Page 16: Graphedit
USB 3.0 Camera User’s Guide 4.2 GraphEdit 4.2.1 M034WDR and AR0330ICP 1) Open GraphEdit. Go to Graph Insert Filters. 2) Click Video Capture SourcesFX3, then click Insert Filter. - Page 17 USB 3.0 Camera User’s Guide 3) Click Close to close above window. 4) In the GraphEdit interface , right click Capture, then click Render Pin. 5) Click the Play icon. 6) You will get the Video.
- Page 18 USB 3.0 Camera User’s Guide 7) Properties 4.2.2 V034, M021 and P031 1) Open GraphEdit. Go to Graph Insert Filters.
- Page 19 USB 3.0 Camera User’s Guide 2) Click Video Capture SourcesFX3, then click Insert Filter. 3) In the same window, click Direct Show FiltersBayer Filter, then click Insert Filter.
- Page 20 USB 3.0 Camera User’s Guide 4) Click Close to close above window. 5) In the GraphEdit main interface, connect Caputer and XForm In.
- Page 21 USB 3.0 Camera User’s Guide 6) Right click XForm Out, then click Render Pin. 7) Click the Play icon. 8) You will get the Video.
- Page 22 USB 3.0 Camera User’s Guide 9) Properties...
