GE Nautilus GSD4000J Datasheet

GE Appliances
GSD4000/60J – GE Nautilus
Built-In Dishwasher Dimensions
(in inches)
25-3/4
24
MAX.
23-3/8
34 MIN.
adj. to 35
21-1/2
3-1/4
4 (Adjustable)
Specification Created 7/03
350351
™ Built-In Dishwasher
Installation Information
(in inches)
90°
24"
MIN.
Hot
water
24-3/4
34-1/2±1/4"
line on
6
Underside
left
of countertop
to floor
2
19" MIN. from wall
Note: Dishwasher must not be installed more than 10 feet from
sink for proper drainage. All plumbing and electrical work must
be in accordance with local codes.
Electrical Rating
Voltage AC . . . . . . . . . . . . . . . . . . . . . . . 120
Hertz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Total connected load amperage . . . . . . . 6.2
Calrod ® heater watts max. . . . . . . . . . . . 500
For use on adequately wired 120-volt, 15-amp
circuit having 2-wire service with a separate
ground wire. This appliance must be grounded
for safe operation.
Countertop
This wall area
must be free of
90°
pipes or wires
Electrical
4 4
wiring is
4 3" from
cabinet
5 5
Electrical
wiring on
6
right
Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
Wood Insert Cut-Out
Dimensions (in inches)
Detail D
A
Door insert
Panel Thickness
Detail D
Front
of
Panel
C
Access insert
1-1/2
B
Models/Kits A B C
GE Models/
GPF425 Kit 19-3/4" 23-9/16" 3-11/16"
GE Models/
GPF475 Kit 19-7/8" 23-5/8"* 3-11/16"**
**Bottom of panel must be notched 1-1/2"x 1/2" to clear across panel
**Adjustment required to match adjacent cabinet fronts due to leveling
leg adjustment, 4" nominal.
Listed by
Underwriters
R
Laboratories
As an ENERGY STAR ® partner,
GE has determined that this product
meets the ENERGY STAR ®
guidelines for energy efficiency.
For answers to your Monogram, ® GE Profile
GE ® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center ® service, 800.626.2000.
