SPLIT-TYPE, HEAT PUMP AIR CONDITIONER
SERVICE MANUAL
Inverter-controlled multi system
Model
MXZ-24UV -
MXZ-24UV -
This manual describes technical data of the outdoor unit.
For the indoor unit refer to the service manuals No. OB229, OB227 REVISED EDITION-B, OB252, OB212,
OB239 and OC165 of corresponding models.
E1
E2
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················3
4. INDOOR UNITS COMBINATION ·······················5
5. SPECIFICATION·················································7
6. NOISE CRITERIA CURVES ······························ 8
7. OUTLINES AND DIMENSIONS ························ 9
8. WIRING DIAGRAM ··········································10
Model indication
9. REFRIGERANT SYSTEM DIAGRAM ··············11
10. PERFORMANCE CURVES ······························12
11. MICROPROCESSOR CONTROL·····················18
12. TROUBLESHOOTING······································24
13. DISASSEMBLY INSTRUCTIONS·····················36
14. PARTS LIST······················································39
15. OPTIONAL PARTS···········································42
Revision:
• MXZ-24UV -
• Please void OB287.
CORRESPONDENCE TABLE ···························4
has been added.
E2
No. OB287
REVISED EDITION-A
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Mitsubishi Electric MXZ-24UV-E1
Summary of Contents for Mitsubishi Electric MXZ-24UV-E1
-
Page 1: Table Of Contents
SPLIT-TYPE, HEAT PUMP AIR CONDITIONER Revision: • MXZ-24UV - has been added. • Please void OB287. No. OB287 REVISED EDITION-A SERVICE MANUAL Inverter-controlled multi system Model MXZ-24UV - MXZ-24UV - CONTENTS 1. TECHNICAL CHANGES ····································2 2. PART NAMES AND FUNCTIONS······················3 3. -
