MPLS TE Configuration

Basic Steps to Configure Traffic Engineering

ASR903-R1 Configuration
interface GigabitEthernet0/1/0
ip address 10.10.12.1 255.255.255.248
negotiation auto
mpls ip
!
interface GigabitEthernet0/1/1
ip address 10.10.13.1 255.255.255.248
negotiation auto
mpls ip
!
router ospf 100
router-id 10.10.1.1
network 10.10.1.1 0.0.0.0 area 0
network 10.10.12.1 0.0.0.0 area 0
network 10.10.13.1 0.0.0.0 area 0
Once connectivity and MPLS configuration are verified, the next step is to enable TE and configure IGP for MPLS
TE support.
mpls traffic-eng tunnels
interfaces.
interface GigabitEthernet0/1/1
mpls traffic-eng tunnels
interface GigabitEthernet0/1/0
mpls traffic-eng tunnels
router ospf 100
mpls traffic-eng router-id Loopback10
mpls traffic-eng area 0
Next, specify the bandwidth can be used for traffic engineering. This is the total bandwidth which can be used for
TE under the configured interface. The bandwidth can be lower or higher than actual bandwidth and care should be
taken to make sure other traffic has enough bandwidth. The following command allocates 40M bandwidth under
interface gig0/1/1 and 30M under gi0/1/0 for traffic engineering.
interface GigabitEthernet0/1/1
ip rsvp bandwidth 40000
interface GigabitEthernet0/1/0
ip rsvp bandwidth 30000
OL-30526-01
Basic Steps to Configure Traffic Engineering ▀
! Enable MPLS TE globally and under the
! Configure IGP for TE support
! Specify TE router ID
! Enable TE in area 0
! Reserved bandwidth in kbps
! Reserved 30M under another interface
Cisco ASR 903 Router Design and Deployment Guide▄
93
