Keston Celsius 25 Installation And Servicing Instructions

Fan powered high efficiency modulating domestic condensing gas boiler
Hide thumbs Also See for Celsius 25:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Using
WD209/1/2000
Fan Powered High Efficiency
Modulating Domestic Condensing Gas Boiler

Installation And Servicing Instructions

These instructions must be left either with
the user or next to the site gas meter.
email : info@keston.co.uk web : www.keston.co.uk
Celsius 25 & 25P Models
CE/PI No : 87BL49
GC No : 41-930-06
34 West Common Road
Hayes, Bromley, Kent BR2 7BX
Tel. +44 (0)20 8462 0262 Fax. +44 (0)20 8462 4459
The Keston Celsius 25 & 25P
