Volvo 1990 780 Model
Essential Information
Please take the time to fill out the forms on this page. When completed, these forms will provide
information essential to the proper servicing and ordering of parts for your Volvo.
Owner
Name_________
Address_______
City, State____Zip/Code_____
Tel. No________
Notice:
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the
certification labels attached to the door opening sheet metal and on the left wheel housing in the engine
compartment. For further information regarding these regulations, please contact your dealer.
Vehicle Information (see "Label information" section)
Vehicle License Number_____
Vehicle Identification Number (VIN)_____
Service Designation Number_____
Engine Designation_____ See "Specifications" section
Color Code_____
Upholstery_____
Tire designation_____ See "Tires" section
Vehicle Capacity_____
© VOLVO NORTH AMERICA CORPORATION
pg. 1 Contents
file:///K|/ownersdocs/1990/1990_780/90780_00.htm (1 of 5)12/30/2006 8:27:49 AM
1990 780 Owner's Manual
U.S.A. & Canada

Advertisement

Table of Contents
loading

Related Manuals for Volvo 780

Summary of Contents for Volvo 780

  • Page 1 Tel. No________ Notice: Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels attached to the door opening sheet metal and on the left wheel housing in the engine compartment. For further information regarding these regulations, please contact your dealer.
  • Page 2 2 This manual deals with the operation and care of your Volvo. Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
  • Page 3 Despite our strongest recommendations, and your best intentions, not wearing a seat belt is like believing "It'll never happen to me!". Volvo urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
  • Page 4 Volvo 1990 780 Model Do not export your Volvo to another country before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render you Volvo not certifiable for legal operation in the U.S., Canada, and other countries.
  • Page 5 The back of the tag is coated with adhesive tape. In the event the original keys are lost, duplicates may be ordered from your Volvo dealer. The central locking system is described in detail in section Doors and locks.
  • Page 6 Volvo 1990 780 Model Instruments and controls pg. 6 Instruments, Switches and controls pg. 7 Instruments, switches and controls pg. 21 1 Air louver pg. 14 2 Headlights, parking lights pg. 14,pg. 3 Turn signals, Cruise Control pg. 14 4 Hazard warning lights pg.
  • Page 7 Volvo 1990 780 Model pg. 19 12 Electrically-heated driver's seats pg. 19 13 Electrically-heated passenger seat pg. 18 14 Parking brake pg. 17 15 Rear fog lamps pg. 17 16 Fog lights pg. 20 17 Power antenna pg. 43 18 Fuel cap cover 19 Horn pg.
  • Page 8 Volvo 1990 780 Model Note: Canadian model speedometers/odometers indicate kilometers only. pg. 9 Instruments (cont.) Quartz crystal clock To reset the hands, push in the reset knob and turn. Tachometer Reads thousands of engine rpm. Engine should not be operated in red range.
  • Page 9 1/2 - 1 US qts. remaining in the washer fluid reservoir. 16 4th gear disengaged 17 Fasten seat belts 18 Check engine (780 Turbo) pg. 11 Warning lights file:///K|/ownersdocs/1990/1990_780/90780_01.htm (4 of 6)12/30/2006 8:27:50 AM...
  • Page 10 WARNING! Fluid level below MIN mark: Do NOT drive. Tow car to shop for check/repair of brake system. Fluid level between MIN and MAX mark: proceed immediately and with caution to a Volvo dealer for an inspection of the brake file:///K|/ownersdocs/1990/1990_780/90780_01.htm (5 of 6)12/30/2006 8:27:50 AM...
  • Page 11 If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Take the car to an authorized Volvo dealer for an inspection of the system. See the SRS section for more information.
  • Page 12 Volvo 1990 780 Model pg. 13 Audio Cassette/Tuner controls and indicators Operating instructions For complete operating instructions, maintenance guidelines, and specifications, please consult your Audio Cassette/Tuner instruction Booklet. The Booklet also contains information on radio reception and the radio antenna.
  • Page 13 Volvo 1990 780 Model If the headlight switch is in position all lights will go out when starting switch is switched off. With the headlight switch in position the parking lights will stay on. The high beams can only be switched on if the headlight switch is in position Switch from high to low beams, and vice versa, by moving the turn signal switch lever on the left side of the steering column towards the steering wheel.
  • Page 14 Volvo 1990 780 Model Hazard warning flasher The four-way flasher should be used to indicate that the vehicle has become a traffic hazard. NOTE: Regulations regarding the use if the hazard warning flasher may vary from state to state. pg. 15 Windshield, wipers/washers, Ignition switch...
  • Page 15 Volvo 1990 780 Model Wipers/washer 1 Intermittent wiper. With switch in this position, the wipers will sweep approximately every seventh second. 2 "Single sweep" position. Switch returns automatically when released 3 Wipers, low speed. 4 Wipers, high speed 5 Windshield wiper/washer The wiper will make 2-3 complete sweeps after lever is released.
  • Page 16 Volvo 1990 780 Model 0 Locked position: remove the key to lock the steering wheel. I Intermediate position: heater blower, cigarette lighter, accessories, etc. on. II Drive position: key position when engine is running. III Starting position: release the key when the engine start. The key returns automatically to the driving position.
  • Page 17 Volvo 1990 780 Model 3. Depress SET SPEED switch (A). Operating brake pedal This will automatically disengage the cruise control. Previously selected cruise control speed is retained in the memory and by momentarily setting the switch to RESUME position, that speed will be re- engaged.
  • Page 18 Volvo 1990 780 Model pg. 17 Rear fog lights, Front fog lights Rear fog lights The rear fog lights are considerably brighter than the normal tail lights and should be used only when the atmospheric conditions, such as fog, rain, snow, smoke or dust reduce the daytime or nighttime visibility of other vehicles to less than 500 ft (150 meters).
  • Page 19 Volvo 1990 780 Model Auxiliary front fog lights can be switched on only with the low-beam headlights on. pg. 18 Parking brake, Cigarette lighter, Ash trays Parking brake (hand brake) The lever is situated between the front seats. The brake is applied to the rear wheels.

  • Page 20: Cigarette Lighter

    Volvo 1990 780 Model Cigarette lighter To operate, depress the knob fully. When the knob automatically releases, the cigarette lighter is ready for use. The starting (ignition) switch must be switched on (position I or II) for the cigarette lighter to function.
  • Page 21 Volvo 1990 780 Model Ash trays To remove the ash trays depress the center spring and remove. pg. 19 Rear window demister, Heated front seats Rear window demister Heated side-view mirrors Depress the switch to start heating of rear window and side mirrors. Both orange control lights in the switch will light.
  • Page 22 Volvo 1990 780 Model Heated front seats The heated front seats can be switched on or off as required. When switched on, the seats are heated until the optimal temperature is reached, at which time the heating switches off automatically.
  • Page 23 Volvo 1990 780 Model Electrically-operated windows The electrically operated windows are controlled by switches from the driver's armrest as shown in the above illustration. The starting (ignition) switches must be ON (position II) for the electrically operated windows to function. The window is lowered if the rear part of the switch is pressed and raised if the front part of the switch is pressed.

  • Page 24: Heating And Ventilation

    Volvo 1990 780 Model pg. 21 Heating and ventilation ECC- Electronic Climate Control This is an automatic system that also permits manual operation. The in-car temperature is automatically monitored by two sensors located in the passenger compartment. One sensor is located on the top of the dashboard where it can sense sunlight.
  • Page 25 Volvo 1990 780 Model Air louvers (dash) A Open B Closed C Directing air flow horizontally D Directing air flow vertically A certain amount of air will always enter through the dash air louvers as long as they are open, regardless of the position of the air distribution control.
  • Page 26 Volvo 1990 780 Model Air conditioning disengaged when this button is in the depressed position. The light has two functions: Air in the passenger compartment recirculates. Will not function in defrost setting. Light is on when function air conditioning disengaged is engaged.
  • Page 27 Volvo 1990 780 Model Select the desired temperature The fan will run at its maximum speed in either the max cooling or max heating positions. Optimum defrosting Set the function dial to The air conditioning light will go on, even if the button is not depressed, to indicate that the air conditioning system is also activated to dehumidify the air.
  • Page 28 If the light continues to flash more than 20 seconds, a more serious fault is indicated. While the system will again attempt to substitute a standard value, some reduction in system performance will become apparent. Contact your authorized Volvo dealer for service. pg. 24...

  • Page 29: Rear-View/Side-View Mirrors

    Volvo 1990 780 Model Body and interior pg. 25 Body and interior Rear-view/side-view mirrors Interior light, moon roof Child safety Seat belts Supplemental Restraint System (SRS) Doors and locks Trunk, long load storage Hood Passenger compartment, storage spaces Front seats pg.

  • Page 30: Rear-View Mirror

    Volvo 1990 780 Model Rear-view mirror A Normal position B Night position, reduces glare from following headlights WARNING! The mirrors should always be adjusted prior to driving. file:///K|/ownersdocs/1990/1990_780/90780_05.htm (2 of 6)12/30/2006 8:27:53 AM...

  • Page 31: Control Switches

    Volvo 1990 780 Model Control switches Electrically-operated side-view mirrors The control switches are located in the driver's door armrest. A Adjustment sideways B Adjustment up/down WARNING! Objects seen in the wide-angle right side-view mirror are closer than they appear to CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface.

  • Page 32: Vanity Mirror

    Volvo 1990 780 Model Vanity mirror Vanity mirrors are located on each sun visor. Illumination is controlled by the mirror covers. pg. 27 Interior light, Moon roof Interior light file:///K|/ownersdocs/1990/1990_780/90780_05.htm (4 of 6)12/30/2006 8:27:53 AM...
  • Page 33 Volvo 1990 780 Model 1 Light always on. 2 Light always off 3 Light is on when either of the front doors are opened. A time-delay device keeps the interior light illuminated for approx. 7 seconds after closing the driver's door.
  • Page 34 Volvo 1990 780 Model Reading lights, rear seats There are two adjustable reading lights for rear seat passengers. The lights are turned on and off by the switches on the rear arm rests. The starting (ignition) key must be in position I.
  • Page 35 28 Child safety Child safety Volvo recommends the proper use of restraint systems for all occupants including children. Regardless of age and size, a child should always be properly restrained in a car. Special child restraint systems are designed to be secured in the vehicle by lap belts or the lap portion of a lap-shoulder belt.
  • Page 36 A specially designed and tested safety cushion for this purpose can be obtained from your Volvo dealer. pg. 29 Child safety (cont.) Child Restraint Anchorages Volvo cars are fitted with Child Restraint Top Tether Anchorages in the rear seat.
  • Page 37 Volvo 1990 780 Model WARNING! Child Restraint Anchorages are designed to withstand only those loads imposed by correctly fitted Child Restraints. Under no circumstances are they to be used for adult seat belts or harnesses. The anchorages are not able to withstand excessive forces on them in the event of collision if full harness seat belts or adult seat belts are installed to them.
  • Page 38 Volvo 1990 780 Model In order for the seat belt to provide maximum protection in the event of an accident, it must be worn correctly. When wearing remember: The belt should not be twisted or turned. The lap belt must be positioned low on the hips (not pressing against the abdomen). Make sure that the shoulder belt is rolled up into its retractor and that the shoulder and lap belts are taut.
  • Page 39 If necessary, guide the belt back into the retractor slot. Warning! Aftermarket devices used to induce slack into the shoulder belt portion of Volvo's three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 40 As the seat belts lose much of their strength when exposed to violent stretching, they should be replace after any collision, even though they may appear to be undamaged. Never repair the belt on you own; have this done by an authorized Volvo dealer only. Maintenance Check periodically that the anchor bolts are secure and that the belts are in good condition.
  • Page 41 32 Supplemental Restraint System As an enhancement to the three-point seat belt system, your Volvo 780 is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of a driver's side airbag with a driver's side knee bolster.
  • Page 42 When installing any accessories, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo Dealer for inspection as soon as possible.
  • Page 43 WARNING! If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo Dealer for inspection as soon as possible. The following items are monitored by the diagnostic system: Sensor unit electronics integrity.
  • Page 44 (wiring, connectors, etc.) should also be inspected at this time. This service must be performed by an authorized Volvo dealer. Should you have any questions about the SRS system, please contact your authorized Volvo Dealer or Consumer Affairs Department: In the U.S.A.:...
  • Page 45 Volvo 1990 780 Model pg. 34 Doors and locks Door locks Your car is equipped with a central door-locking system. This means that the lock on the driver's door also controls the lock on the passenger's door. If the driver's door is locked or unlocked from the outside using the key, the other door will be locked or unlocked automatically.
  • Page 46 Volvo 1990 780 Model To avoid battery drain The interior light and the warning lights in the rear of the doors come on when a door is opened. To avoid battery drain when the doors are opened for prolonged periods, these lights can be switched off by pushing in and turning the door light switches slightly clockwise.
  • Page 47 Volvo 1990 780 Model Always lock the trunk with the key when leave the car. The lock is situated in the door pillar on the driver's side. pg. 36 Trunk, Long load storage Trunk light A Light always off. B Light is on when trunk lid is opened.
  • Page 48 Volvo 1990 780 Model Warning: Cover sharp edges on load to help prevent injury to occupants. Secure load to help prevent shifting during sudden stops by wrapping seat belt around the armrest as shown. Warning: Always turn engine off and apply parking brake when loading/unloading the vehicle. Place transmission selector in P (PARK) position to help prevent inadvertent movement of selector.
  • Page 49 Volvo 1990 780 Model The normal opening angle for the hood approximately 55°. By turning the catches on the hinges as illustrated, the hood can be opened to the vertical position. The catches will return to their normal position when the hood is closed.
  • Page 50 Volvo 1990 780 Model WARNING! Do not place heavy objects on the rear window shelf. These objects can become dangerous projectiles in the event of sudden braking. Always secure large of heavy objects with the seat belts. pg. 39 Front seats Electrically operated front seats The front seats are electrically operated.
  • Page 51 Volvo 1990 780 Model WARNING: Do not adjust seat while driving. The seat should be adjusted so that the brake pedal can be depressed fully. To gain access to the rear seats - fold the backrests forward To gain access to the rear seat, the front seat backrest must be folded forward. The backrest lock is released by pressing the control on the side of the backrest upward.
  • Page 52 Volvo 1990 780 Model Starting and driving pg. 41 Starting and driving Starting and driving This section on starting and driving contains items such as starting the engine, operating gear selector, towing, trailers. Break-in period, Fuel requirements Refueling Starting the engine...
  • Page 53 The use of specially formulated gasoline which contains so called "detergent injector cleaning" additives is allowed and recommended by Volvo. The use of these detergent additives in gasoline has been shown to be effective in reducing the build up certain injector deposits.
  • Page 54 Octane Rating Volvo recommends the use of premium unleaded gasoline with an (R+M)/2 octane rating, also called the Anti-Knock Index or AKI, of 91 or higher. This is generally equivalent to a Research Octane Number (RON) of 95 or higher.
  • Page 55 Volvo 1990 780 Model to accommodate possible expansion of the fuel in hot weather. When the gauge's needle enters the red zone, approximately 2.4 US gal. (9 liters) of fuel remain the tank. Be aware that the "usable" tank capacity will be somewhat less than the 21.1 US gallons (80 liters) maximum.
  • Page 56 Volvo 1990 780 Model Refueling The fuel cap is located behind the flap on the left hand fender. The cap can be placed in the bracket on the inside of the cover when refuelling. After filling the tank, screw on the cap until a click is heard.
  • Page 57 Volvo 1990 780 Model 2 Apply the parking brake, if not already set. Depress brake pedal firmly. 3 Place the gear selector lever in Park (or Neutral). 4 Without touching the accelerator pedal, turn the ignition key to the starting position. Release the key as soon as the engine starts.
  • Page 58 Volvo 1990 780 Model WARNING! Always place gear selector securely in Park and apply parking brake before leaving vehicle. Never leave car unattended with engine running. Always open the garage doors fully before starting the engine inside a garage to ensure adequate ventilation.
  • Page 59 Volvo 1990 780 Model pg. 45 Automatic transmission Gear selector positions P park R reverse N neutral D drive 2 intermediate 1 low P (Park) Use this position when parked with the engine running or stopped Never use P while car is in motion.
  • Page 60 Volvo 1990 780 Model WARNING! Never leave the car when the engine is running. If, by mistake, the gear selector is moved from P, the car may start moving. R (Reverse) Never engage R while is moving forward. N (Neutral) Neutral position = no gear is engaged.
  • Page 61 Volvo 1990 780 Model Use position 1 to select low gear when no upshift is desired, for instance, when entering and descending steep grades. Shift gate The gear selector can be moved freely between D and 2. Selections of other positions are obtained by depressing the selector knob prior to moving the selector.
  • Page 62 Volvo 1990 780 Model 4th gear disengagement: The 4th gear is engaged automatically after the transmission has shifted through 1st, 2nd and 3rd gears at certain speeds and loads. By pressing in the button at the rear of the selector level, the 4th gear can be disengaged, thus providing a three-speed transmission.
  • Page 63 Volvo 1990 780 Model Caution: Never select P or R while the car is in motion. When initially selecting positions D, 2, 1, or R, your foot should press firmly on the brake pedal to ensure that the car is standing still with the engine idling.
  • Page 64 Volvo 1990 780 Model pg. 48 Points to remember Driving economy Better driving economy may be obtained by thinking ahead, avoiding rapid starts and stops and adjusting the speed of your vehicle to immediate traffic conditions. Observe the following rules: Bring the engine to normal operating temperature as soon as possible by driving with a light foot on the accelerator pedal for the first few minutes of operation.
  • Page 65 Volvo 1990 780 Model Stopping the engine suddenly after high speed driving (so-called "after-boiling" can occur). To avoid overheating, the following rules should be followed: Reduce speed and downshift when towing a trailer up long, steep inclines. The risk of overheating can be reduced by switching off the air conditioning system for a short time.
  • Page 66 Volvo 1990 780 Model Warning! Do not drive with trunk lid open! Poisonous exhaust gases may enter via the open trunk lid. If the trunk lid must be kept open for any reason, proceed as follows: Close the windows. Set heater control to...
  • Page 67 Roof racks (removable and permanent) Roof rails are available as Volvo accessories. Observe the following points when is use: Avoid single-point loads. Distribute the load evenly. Place heavier cargo at bottom of load.
  • Page 68 Max. roof load is 70 lbs (30 kg) for permanent rack mounted directly on roof. Warning An extra non-Volvo mat on the driver's floor may cause the accelerator pedal to catch. Check that the movement of the accelerator pedal is not impeded.
  • Page 69 Volvo 1990 780 Model pg. 51 Emergency towing (pulling of vehicle) Front eyelet Rear eyelet Precautionary steps to observe when car is in tow Steering must be unlocked. Please check with state and local authorities before attempting this type of towing, as vehicles being towed are subject to regulations regarding maximum towing speed, length and type of towing device, lighting, etc.
  • Page 70 Volvo 1990 780 Model CAUTION: The towing eyelets must not be used for pulling another vehicle out of a ditch or any similar purpose involving severe strain. pg. 52 Vehicle towing information Only use wheel lift or flat bed equipment.
  • Page 71 Volvo 1990 780 Model CAUTION: file:///K|/ownersdocs/1990/1990_780/90780_11.htm (3 of 3)12/30/2006 8:27:57 AM...
  • Page 72 Volvo 1990 780 Model Wheels and tires pg. 60 Wheels and tires Wheels and tires The handling and riding comfort of the vehicle is dependent on the inflation pressure and the type of tires fitted. Read the following pages carefully.
  • Page 73 Volvo 1990 780 Model NOTE: When storing wheel/tire assemblies (e.g. winter tires and wheels), either lay the assemblies on their sides or suspend them off the ground. Laying wheel/tire assemblies on their sides for prolonged periods can cause wheel and/or tire damage.
  • Page 74 The tire temperature rises after driving just a few miles. Vehicle Loading The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label located on the rear facing side on the right front door. This label lists both the tire and vehicle design limits.
  • Page 75 Volvo 1990 780 Model Do not load your car beyond the load limits indicated. Sample tire pressure label Contents Top of Page file:///K|/ownersdocs/1990/1990_780/90780_12.htm (4 of 4)12/30/2006 8:27:57 AM...
  • Page 76 Volvo 1990 780 Model In case of emergency pg. 63 In case of an emergency In case of emergency Even if you maintain your car in good running condition, there is always the possibility that something might go wrong and prevent you from driving, such as a punctured tire, blown fuse or bulb, etc. For additional information, see section "ON CALL Road Assistance".
  • Page 77 Tire pressure must be 40 psi (280 kPa) irrespective of load or in which position the wheel is placed. In the event of damage to this tire a new one can be purchased from your Volvo dealer. pg. 65 Tire changing Changing a tire The spare tire is located in the trunk, beneath the carpet.
  • Page 78 Volvo 1990 780 Model Remove the wheel cap, using the screwdriver in the tool kit. With the car still on the ground, use the box wrench from the tool kit to loosen the wheel nuts 1/2 - 1 turn. Turn the nuts counterclockwise to loosen.
  • Page 79 Volvo 1990 780 Model There is a jack attachment adjacent to each wheel location. Hang the jack from the attachment as shown in the illustration and crank while simultaneously guiding the base to the ground. Before raising the car check that the jack is still correctly positioned in the attachment . Now raise the vehicle until the wheel is free of the ground.
  • Page 80 Volvo 1990 780 Model you align the wheel with the guide stud on the wheel hub prior to installation. Install the wheel nuts crosswise and tighten lightly. The bevelled side of the nuts should face the wheel. Lower the vehicle to the ground and alternately tighten the nuts to 63 lbs.
  • Page 81 Volvo 1990 780 Model pg. 67 Replacing bulbs NOTE! The method for replacement of bulbs in the various lighting units is shown on the following pages. Make sure when installing bulbs, that the guide pin on the socket fits into its corresponding recess.
  • Page 82 Volvo 1990 780 Model Note: One of the tabs on the bulb holder is slightly wider than the other two. 5 Turn the bulb holder clockwise to secure it. Check the bulb function. Note: It may be necessary to remove the washer fluid reservoir fill tube in order to gain access to the bulb holder.
  • Page 83 Volvo 1990 780 Model Replacing tail lights bulbs All tail lamp bulbs are replaced from inside of trunk. 1 Unscrew and remove tail lamp inside cover. Note that inside cover is hooked at the lower edge. 2 Turn bulb holder approx. 3/8" (1cm) counterclockwise and remove it.

  • Page 84: High-Level Brake Light

    Volvo 1990 780 Model 3 Rear marker 4(5) bulb 4 Brake light 1156 (21) 5 Rear turn signal 1156 (21) 6 Rear turn signal 1156 (21) 7 Tail light 4(5) 8 Tail light 4(5) pg. 70 Replacing bulbs (cont.) Press and pull off High-level brake light file:///K|/ownersdocs/1990/1990_780/90780_14.htm (4 of 11)12/30/2006 8:28:02 AM...
  • Page 85 Volvo 1990 780 Model Remove the cover by pressing downwards. Access to the bulb is gained by turning the bulb holder counter clockwise. To remove the bulb turn counter clockwise Replace bulb and cover. Bulb Power Socket High-level brake light 21 W Ba 15s...

  • Page 86: Vanity Mirrors

    Volvo 1990 780 Model Inset screwdriver and turn Vanity mirrors Insert a screwdriver and turn it to remove the lens. Replace the bulb and press the lens back into place. Bulb Power Socket Vanity mirror 3 W SV 7 pg. 71 Replacing bulbs (cont.)

  • Page 87: Engine Compartment Light

    Volvo 1990 780 Model Engine compartment light Insert a screwdriver and pry off the light assembly. Lift it out to remove. Replace the bulb. Bulb Power Socket Engine compartment light 10 W SV8.5 Trunk light file:///K|/ownersdocs/1990/1990_780/90780_14.htm (7 of 11)12/30/2006 8:28:02 AM...
  • Page 88 Volvo 1990 780 Model Depress the catch with a screwdriver and remove the light assembly. Lift it out remove. Replace the bulb. Bulb Power Socket Trunk light 10 W SV8.5 License plate light Slide the bulb housing backwards until it is released from the front edge. Pull out the lamp housing and replace the bulb.
  • Page 89 Volvo 1990 780 Model Interior light and reading lights Take hold of the front section of the light as shown and pull straight down. Push out the glass from the inside, replace the blown bulb and check operation before reinstalling the bulb housing.
  • Page 90 Volvo 1990 780 Model Door Warning lamps All doors are equipped with red warning lamps. To replace a bulb, insert a screwdriver as shown in picture and gently turn it to remove the lens. Withdraw the bulb, replace it and re-insert the lens.
  • Page 91 Volvo 1990 780 Model Contents Top of Page file:///K|/ownersdocs/1990/1990_780/90780_14.htm (11 of 11)12/30/2006 8:28:02 AM...
  • Page 92 Volvo 1990 780 Model pg. 73 Fog lights, Fuses Fog lights Remove the Phillips screws securing the corner strips and pull out the reflector. Remove the spring clips holding the bulb. Withdraw the connector and install a new bulb. Replace parts in the reverse order.
  • Page 93 Volvo 1990 780 Model Fuse replacement A blown fuse is indicated by the failure of all the units protected by it, and it is caused by overloading the circuits. The fuses (and relays) are located in the central electrical unit behind the ashtray in the center console.
  • Page 94 Volvo 1990 780 Model It is necessary to remove the fuses to see if they are blown, see next page for information on fuses and related circuits. If you find it difficult to obtain access to the fuses, unclip the fuse tool on the right-hand side of the fuse compartment and use it to remove the fuse, see illustration.
  • Page 95 Volvo 1990 780 Model The fuses are removed by pulling them straight out. If they are defective, the metal wire is broken. When fitting a new fuse, be certain to use one with the same amperage and color as the one removed (see top of fuse)! Spare fuses are located on each side of the fusebox (1x15A, 1x25A, 1x30A).
  • Page 96 Volvo 1990 780 Model 16 Spare 17 High beam (left) 15 18 High beam (right) 15 19 Low beam (left) 15 20 Low beam (right) 15 21 LH parking lights (front and rear), license plate light, light for: ash tray, heater, control panel, switch...
  • Page 97 Volvo 1990 780 Model Install new blade (installation is the reverse of removal) and make sure that it is properly attached to the wiper arm. For reasons of safety, you should change the windshield wiper blades as soon as they start to leave marks on the windshield or fail to wipe efficiently and cleanly.
  • Page 98 Volvo 1990 780 Model pg. 77 Service diagnosis This section contains information which can be of help in the event of a breakdown. Only those faults which can be rectified with the vehicle's tool kit are listed. The engine does not start or is difficult to start.
  • Page 99 Volvo 1990 780 Model Faulty ignition system Check spark plugs, electrode gap should be 0.028" (0.7 mm), and wipe clean. Check distributor cap for cracks and wipe clean on inside. Check that all electric leads in the distributor ignition system are clean and correctly connected.
  • Page 100 Volvo 1990 780 Model Check and fill coolant, see section "Cooling system". Fan belt frayed or belt tension incorrect Replace or adjust tension. pg. 79 Service diagnosis (cont.) Emergency moon roof operation If, because of an electrical fault (e.g. a blown fuse) it is not possible to operate the moon roof electrically, then it is possible to operate it manually.
  • Page 101 Volvo 1990 780 Model Emergency power seat operation If, because of an electrical fault (e.g. a blown fuse - check fuses 23, 24 and 26), it is not possible to operate the power seat electrically, then it is possible to operate it manually, using the crank supplied with the tool kit.
  • Page 102 Volvo 1990 780 Model Car care pg. 81 Car care Car care includes not only maintaining the appearance of the car, but also protecting the car exterior from the effects of air pollution, rain and mud. The rustproofing compound under the car should be checked regularly and, if necessary, damaged areas should be repaired.
  • Page 103 Rustproofing, inspection and touching-up Your Volvo was carefully and thoroughly rustproofed at the factory. The underbody and wheelhousings were sprayed with a thick, durable rustproofing compound and the beams, internal cavities and end sections were sprayed with a low viscous, penetrating rustproofing agent.
  • Page 104 Volvo 1990 780 Model The visible rustproofing The visible (external) rustproofing must be inspected by an authorized Volvo dealer at least once a year. Consult your Warranty Information booklet for details of Volvo's Eight Year Corrosion Protection Warranty. If it is necessary to touch-up the rustproofing, this should be done immediately to prevent moisture penetration.
  • Page 105 Volvo 1990 780 Model Contents Top of Page file:///K|/ownersdocs/1990/1990_780/90780_17.htm (4 of 4)12/30/2006 8:28:03 AM...
  • Page 106 Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo dealer, use the paint code indicated on the model plate. The plate is located on the panel above the right-side head lights.
  • Page 107 Volvo 1990 780 Model If the stone chip has not penetrated down to the metal and undamaged layer of paint remains, the touch- up paint can be applied as soon as the spot has been cleaned. Deep scars If the stone chip has been penetrated down to the metal, proceed as follows: 1 Place a strip of masking tape over the damaged surface.
  • Page 108 Volvo 1990 780 Model When the primer surface is dry, the paint can be applied using a brush. Mix the paint thoroughly: apply several thin paint coats and let dry each application. pg. 85 Paint touch-up (cont.) 3 If there is a longer scratch, you may want to protect surrounding paint by masking it off.
  • Page 109 Volvo 1990 780 Model Touching up damaged paint on fender edges and sills Material: Primer - spray can Paint - spray can Masking tape NOTE: When touching up the car, it should be well cleaned and dry and have a temperature exceeding 60°F (+15°C).
  • Page 110 Volvo 1990 780 Model 3 When the primer has dried apply the surface enamel in the same way. Spray on several times and allow the paint to dry a minute or so between each application. pg. 86 Washing Washing the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
  • Page 111 Volvo 1990 780 Model Remove from paintwork as soon as possible. Otherwise the finish may be permanently damaged. Warning! When the car is driven immediately after being washed, carefully apply the brakes a few times in order to remove any moisture from the brake linings and to ensure proper braking.
  • Page 112 To clean leather upholstery, use soft cloth and mild soap solution, using, for instance, common bath soap. For more difficult spots, consult your Volvo dealer. On no account must gasoline, naphtha or similar cleaning agents be used on the plastic or the leather since these can cause damage.
  • Page 113 Volvo 1990 780 Model Bear in mind Take extra care when removing stains such as ink or lipstick since the coloring can spread. Use solvents sparingly. Too much solvent can damage the seat padding. Start from the outside of the stain and work toward the center.
  • Page 114 Volvo 1990 780 Model Volvo service pg. 89 Volvo Service Service - an investment! An investment which will pay dividends in the form of improved reliability, durability, and resale value. pg. 90 Maintenance schedule pg. 92 Volvo service pg. 93 Engine compartment pg.
  • Page 115 Volvo 1990 780 Model A = Adjust (Correct if necessary) I = Inspect (Correct or Replace if necessary) R = Replace Maintenance Operation 0.6-1.2 thousand miles (1.0- (16) (25) (32) (40) (48) (56) (64) (72) (80) (88) (96) (thousand km) 2.0)

  • Page 116: Miscellaneous Maintenance

    2) For services beyond 60,000 miles (96,000 km), consult your "Maintenance Records manual" and "Maintenance Service Chart". 3) Recommended, but not mandatory to maintain Volvo emission warranty. 4) Not B 280 F 5) B 230 FT: EVery 10 000 miles.
  • Page 117 Volvo 1990 780 Model Fuel (Line) Filter PCV Nipple (Orifice)/hoses Battery condition BRAKES Inspect Brakes, Replace components as necessary Change Brake Fluid STEERING Tire wear (Align front end if needed.) Check power steering fluid level. BODY Trunk, hood hinges and latches 1) For detailed information, see "brake fluid"...

  • Page 118: Maintenance

    After being driven 600-1,200 miles (1,000-2,000 km), your car should be brought to the Volvo dealer for a service inspection. Engine, transmission and rear axle oils will be changed at this time. Following this inspection, the maintenance inspections outlined in this book should be performed every 5,000 miles (8,000 km).
  • Page 119 These services are not covered by the warranty. You will be required to pay for labor and material used. Refer to your Warranty booklet for further details. In accordance with Federal Regulations, your Volvo is warranted to meet certain Emission Performance Standards. Refer to your Warranty booklet for detailed information,...
  • Page 120 Volvo 1990 780 Model pg. 93 Engine compartment Image of 780 Turbo (engine B230F-Turbo) Image of 780 (engine B280F) 1 Expansion tank, coolant 2 Oil dipstick, engine 3 Oil filler cap, engine 4 Dipstick, automatic transmission 5 Brake fluid reservoir 6 Data plate file:///K|/ownersdocs/1990/1990_780/90780_20.htm (1 of 7)12/30/2006 8:28:05 AM...
  • Page 121 Volvo 1990 780 Model 7 Battery 8 Radiator 9 Air cleaner 10 Washer fluid reservoir 11 Power steering fluid reservoir pg. 94 Engine oil Checking the oil level The oil level should be checked each time you refuel. Be sure the oil level is maintained between the upper and lower marks on the dip-stick.
  • Page 122 Volvo 1990 780 Model WARNING! The oil may be very hot. To add or change engine oil Add oil of the same kind as already used. Capacity (including filter): 4.0 us qts = 3.85 liters. If oil cooler is drained, add 0.7 US qts (0.6 liters).
  • Page 123 Synthetic or semisynthetic oils may be used if their specifications comply with the oil quality requirements. Volvo does not recommend additional oil additives, as they can adversely affect the engine. SAE 15W/40 is recommended for use in driving conditions that raise oil temperature and increase oil consumption (i.e., mountain driving;...
  • Page 124 Frequent trips of longer than 7 miles = 11 km 5,000 miles=8,000 km WHICH EVER COMES FIRST Volvo recommends the use of oils with the American Petroleum Institute (API) label. This label certifies that the oil conforms to the applicable standards and specifications of the API.
  • Page 125 Always entrust brake fluid changing to an authorized Volvo dealer. Power steering fluid 780 The dipstick has markings for hot and cold fluid. When cold, the fluid must not be above the COLD mark, and similarly, when hot it must not be above the HOT mark.
  • Page 126 Volvo 1990 780 Model Contents Top of Page file:///K|/ownersdocs/1990/1990_780/90780_20.htm (7 of 7)12/30/2006 8:28:05 AM...
  • Page 127 Check hoses and connections on distributor vacuum unit, connections on heater control servo systems and hydraulic brake servo. Checking and adjusting idle air control system Your Volvo is equipped with an electronically-controlled idle air control system that requires no checking or adjustment. Fuel system cap, tank and lines, and connections The effectiveness of the fuel system to contain hydrocarbons is dependent largely on a leakfree system.
  • Page 128 Volvo 1990 780 Model Check for proper sealing of gasoline filler cap which contains "0" ring-type seals. Check all evaporative hoses in vehicle for tightness. Check fuel lines under vehicle and repair if necessary. Fuel (line) filter The fuel line filter is located next to the fuel pump. This filter should be replaced every 60,000 miles (96,000 km).
  • Page 129 Volvo 1990 780 Model Image for 780 1 Battery 2 Injection control unit 3 Ignition control unit 4 Fuel filter 5 Fuel pump 6 Fuel feed pump 7 Air mass meter 8 Throttle switch 9 Temperature sensor 10 Injector 11 Oxygen sensor...
  • Page 130 Volvo 1990 780 Model pg. 99 Servicing (cont.) Catalytic Converter This is a supplementary device in the exhaust system, designed to clean exhaust gases. This device is mainly a container with a ceramic material insert, designed to let the exhaust gases pass through channels in the insert.
  • Page 131 100 Servicing (cont.) Evaporative control system The 780 is equipped with a gas evaporative control system, which prevents gasoline fumes from being released into the atmosphere. The system is comprised of an expansion chamber in the fuel tank, and a charcoal canister with built-in vacuum valve under the left-front wheel housing.
  • Page 132 Volvo 1990 780 Model Crankcase ventilation The engine is equipped with positive crankcase ventilation which prevents crankcase gases from being released into the atmosphere. Instead, the crankcase gases are admitted to the intake manifold and cylinders. PCV system, B280F The orifice nipple in the intake manifold should be cleaned every 60,000 miles (96,000 km).
  • Page 133 Volvo 1990 780 Model Warning! The ignition system operates at very high voltages. Special safety precautions must be followed to prevent injury. Always turn the ignition off when: connecting engine test and diagnostic equipment to the vehicle (timing light, tach-dwell tester, ignition oscilloscope, etc).
  • Page 134 Volvo 1990 780 Model pg. 102 Automatic transmission Automatic transmission oil Capacity: See "Specifications" section Fluid type: Automatic Transmission Fluid type Dexron IID. Replace: Every 20,000 miles (32,000 km). WARNING! Oil spilled on a hot exhaust pipe constitutes a fire risk.
  • Page 135 Volvo 1990 780 Model WARNING! The oil may be very Do not use rags that could leave lint on the dipstick. The transmission is topped up via the dipstick tube. The space between the MIN and MAX marks on the dipstick corresponds to 0.5 US qt (0.5 liter). Do not fill the transmission with too much oil, since this can result in oil being ejected from the transmission.
  • Page 136 Start the engine and run until hot. Check the cooling system connections for tightness. Also re-check the coolant level. Capacity: See "Specifications" Coolant: Volvo Coolant type C (blue green) CAUTION! The cooling system must always be kept filled to correct level.
  • Page 137 Belt adjustment and replacement The belts can be difficult to reach and it is advisable to let your Volvo dealer adjust the tension of the belts or replace them, if necessary.
  • Page 138 2 Vehicle emission control information Your Volvo is designed to meet all applicable safety and emissions standards, as evidenced by the certification label on the panel above the right headlight. For further information regarding these regulations, please consult your Volvo dealer.
  • Page 139 Volvo 1990 780 Model headlight. 4 Loads and tire pressures 5 Federal motor vehicle safety standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) Standards (Canada) This label is located on the rear-facing side of the driver's door. Contents Top of Page...
  • Page 140 59.8" 152 cm Turning circle, between curbs 32.5 ft 9.9 m Trunk capacity 14.3 cu. ft. 0.406 m *The maximum permissible axle loads must not be exceeded **780 Turbo 3423 lbs (1552 kg) file:///K|/ownersdocs/1990/1990_780/90780_23.htm (1 of 10)12/30/2006 8:28:06 AM...
  • Page 141 When adding accessories, equipment, luggage and other cargo to your vehicle, the total loaded weight capacity of the vehicle must not be exceeded. Consult your Volvo dealer for information. All specifications as subject to change without notice. pg. 109 Specifications (cont.) Engine (780) Liquid-cooled, gasoline, 6-cylinder V-engine with 90 angle.
  • Page 142 Exhaust-gas-driven turbo-compressor with intercooler. Electronic wastegate-control optimization. Type designation Volvo B 230 F-Turbo Output (SAE J 1349) 188 hp at 5100 rpm (141 kW at 86 rps) Max. torque (SAE J 1349)at rpm 206 ft. lbs. (279 Nm) at 3900 rpm Number of cylinders 4 Bore 3.78"...
  • Page 143 Oil with designation SG/CD, SF/CC and SF/CD comply with these demands. Synthetic or semi- synthetic oils may be used if their specifications comply with the above. Volvo recommends the use of fuel economy improving oils. Look for the API label. Volvo does not recommend oil additives as they can adversely affect the engine.
  • Page 144 Battery, type Maintenance free Capacity 500 A/115 min Electrolyte, specific gravity 1.28 Recharge at 1.23 Alternator, rated output 1400 W max. current 100 A The following bulbs may be obtained from your nearest Volvo dealer: US bulb Lights, 12 V Power Socket Halogen...
  • Page 145 Volvo 1990 780 Model 21/5 W/24/3 Turn signals, front 1157 Bay 15 d Turn signals, rear 1156 21W/32cp Ba 15s Tail lights 5 W/4cp Ba 15s Brake light 1156 21 W/32cp Ba 15s High-mounted brake 20 W Ba 9 s...

  • Page 146: Power Transmission

    Volvo 1990 780 Model Lighting, control panel W2x4.6d A/T selector W2x4.6d Ashtray, rear W2x4.6d Warning lights/ Volvo P/N Indicator lights 966326 pg. 112 Specifications (cont.) POWER TRANSMISSION Automatic transmission AW71 Reduction ratios: 1st gear 2.45:1 2nd gear 1.45:1 3rd gear 1:1 4th gear 0.69:1...
  • Page 147 113 Specifications (cont.) Vehicle Loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the rear-facing edge of the right-front door. This label lists both tire and vehicle design limits.
  • Page 148 Volvo 1990 780 Model WARNING! Improperly inflated tire will reduce tire life, adversely affect vehicle handling and can possibly lead to failure resulting in loss of vehicle control prior warning. Tool kit Wheel nut wrench. 2 Screwdrivers (1 phillips, 1 standard) Tommy bar.
  • Page 149 Volvo 1990 780 Model 1.6 liters 1.6 liters Power steering gear 1.05 US qts. 0.7 US qts. 1.0 liter 0.7 liter * If oil cooler is drained, add 0.7 US qts (0.6 liter) All specifications are subject to change without notice.
  • Page 150 A Service Manual Brochure/Order Form was placed in the car prior to delivery from the dealer to you. Complete ordering information is provided. Please note that these manuals may be offered for sale by your Volvo dealer. Prices charged by the dealer can vary from those listed in the brochure (according to Federal law.)
  • Page 151 Volvo at peak operating condition. Note that the above pertains to USA only. Your new Volvo comes with a four year road assistance program named ON-CALL. Additional information, features, and benefits are described in a separate information package in your glove compartment.
  • Page 152 Volvo 1990 780 Model WARNING! Detergents and solvents Do not use gasoline containing lead or benzene as a detergent or solvent. Both lead and benzene are toxic and may be hazardous to your health. WARNING! Carbon monoxide is a poisonous, colorless and odorless gas which is present in all exhaust gases. If you ever smell exhaust fumes from inside the vehicle, make sure the passenger compartment is ventilated and immediately return the vehicle to your retailer for correction.

  • Page 153: Usa And Canada

    Servicing (Brakes), 740 pg 97, present chart indicates this place the first 10,000 miles 760 pg 103, 780 pg 91 inspection must take place at the then every 5,000 miles first 10,000 miles then every thereafter.
  • Page 154 Servicing (Emission System The present information The correct information is: Maintenance/ Exhaust System), indicates Exhaust System within Exhaust system (B280F 760 pg 102, 780 pg 90 the chart. engine only) file:///K|/ownersdocs/1990/1990_780/90780_app.htm (2 of 4)12/30/2006 8:28:07 AM...
  • Page 155 Volvo 1990 780 Model The present information The EGR valve, clean Servicing (Miscellaneous indicates that EGR valve, clean inspection should be Maintenance/ EGR, clean), 740 pg inspection should be performed performed at the 60,000 mile at the 50,000 mile (80,000 km) (96,000 km) inspection interval.
  • Page 156 Volvo 1990 780 Model VOLVO NORTH AMERICA CORPORATION SP0257 150M 09.89 Printed in U.S.A Contents Top of Page file:///K|/ownersdocs/1990/1990_780/90780_app.htm (4 of 4)12/30/2006 8:28:07 AM...
