Air Cleaner, Muffler - Echo CS-8001(6digits)(36) Parts Catalog

2. Air Cleaner, Muffler

KEY LV PART NUMBER Q'TY DESCRIPTION
1 130302-30830
2 + 130406-30830
3 + 900720-00010
4 + 900720-00003
5 890112-60830
5 890112-60831
11 130303-30831
12 + 130356-19830
13 + 130320-30831
14 130306-30830
15 101529-30830
16 129013-30831
17 129010-19830
17 129010-38830
18 100905-19830
19 130339-30830
21 130007-30830
20 + 130012-30830
22 + 130020-19830
23 900162-05025
24 130110-30830
25 129011-19831
26 900162-05055
COVER SET, AIR CLN
1
NUT, THUMB
1
O-RING P-10
1
1 O-RING P-3
LABEL, MODEL
1
1 LABEL, MODEL
FILTER, AIR W/SEAL
1
GROMMET
1
SEAL, CLEANER
1
CASE, CARBURETOR(BS)
1
1 PLATE, GUIDE (A)
1 SCREW, IDLE SPEED
GROMMET
1
GROMMET, NEEDLE
1
CUSHION
1
PLUG
1
INSULATOR
1
1 SEAL, DUST
2 NUT
BOLT, H.S. 5*25
4
PIPE, IMPULSE
1
PLATE
1
BOLT, H.S. 5*55
2
- 4 -
CS-8001(6digits)(36)
REMARKS NOTE1
P-10
P-3
Sus. by 890112-
60831
Sr/Nr 36001000
and before
Sr/Nr 36001001
and after
5*25 W,SW
5*55 W,SW
NOTE2
