- Page 1 INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS FOR EVERDURE RANGE HOOD Models Included: RBES63 RBES91 RBES92 BERLEY DESIGNED TO PERFECTION...
-
Page 2: Table Of Contents
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS FOR EVERDURE RANGE HOOD RBES63, RBES91, RBES92 CONTENTS SECTION PAGE NO. Important Safety Instructions……………… Appliance Details ………………………… General Information …………………….. What Is Supplied ………….……………… What May Be Needed For Installation … Installation Instructions …………………… Operating Instructions ……………………... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. In certain circumstances electrical appliances may be a danger hazard. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 4: Appliance Details
Range hood (including one way valve for flue x 1) x 1 Installation kit x 1 – RBES63 & RBES91: Short bolts x 10, long screws x 7, plastic plugs x 7 Installation kit x 1 – RBES92: Short bolts x 8, Medium bolts x 4, long screws x 7, plastic plugs x 7... - Page 5 INSTALLATION OF THE EVERDURE RBES63 & RBES91 RANGE HOODS DIRECTLY TO A WALL Ensure that the wall is structurally sound, and is capable of carrying the weight of the range hood. The range hood can be placed at a minimum of 600mm away from an electric cooktop, or 650mm minimum from a gas cooktop.
- Page 6 INSTALLATION OF THE EVERDURE RBES92 RANGE HOOD DIRECTLY TO A WALL Ensure that the wall is structurally sound, and is capable of carrying the weight of the range hood. The range hood can be placed at a minimum of 600mm away from an electric cooktop, or 650mm minimum from a gas cooktop.
-
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Note: Before the unit can be operated, it must be ducted. Connect the plug into the power. FOR RBES92 ELECTRONICALLY OPERATED RANGEHOODS The range hood has indication diagrams to allow you to easily select the fan operating speed required. Push the low button, indicated by a fan with 3 blades, and the motor will run at a low speed. - Page 8 FOR RBES63 & RBES91 PUSH BUTTON OPERATED RANGEHOODS The range hood has indication diagrams to allow you to easily select the fan operating speed required. Push the low button, indicated by a fan with 3 blades, and the motor will run at a low speed.
-
Page 9: Cleaning
CLEANING SAFETY PRECAUTION Before cleaning your range hood or performing any maintenance, please ensure that the range hood is turned off at the power point. Do not use abrasive cleaners to clean the range hood. The use of warm soapy water and a cloth are recommended. -
Page 10: Troubleshooting
TROUBLESHOOTING Fault Possible Cause Solution The impellor leaf blocked Get rid of the blockage Light on, but The capacitor damaged Replace capacitor (By an authorised motor does person only) not work The motor bearing damaged or Replace motor (By an authorised jammed person only) A bad smell from the motor... - Page 11 DESIGNED TO PERFECTION...
- Page 12 A division of Shriro Australia Pty Ltd 23-27 Chaplin Drive Lane Cove NSW 2066 1300 766 066 www.everdurekitchen.com.au IM Ref: RBES63 27/2009/02FC F O R I N D O O R U S E O N L Y DESIGNED TO PERFECTION...
