Table Of Contents Safety Information ........................ 2 Features ..........................5 About Disc ..........................6 Before Operation ........................8 Preparations Before Operation ..................10 Front Panel ........................... 10 Rear Panel ..........................11 Names And Layout of Remote Control ................. 12 Connections .........................
Safety Information Please read the manual carefully before using this BD player, and keep it safe for future reference. Warning TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER - SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Safety Information This set has been designed and manufactured to assure should be moved with care. Quick stops, excessive personal safety. Improper use can result in electric shock sou rc e, and uneven surfaces may cause the video or fire hazard. The safeguards incorporated in this unit will product and cart combination to overturn.
Features OUTSTANDING SOUND QUALITY Dolby Digital system developed by Dolby Laboratories features high quality surround sound which can be played in DVD or CD disc at home, to reproduce high quality sound effects. UNIQUE FUNCTIONS Multi-angle and multi-language bring unique trick functions. Parent lock makes it easy to control the content of discs.
About Discs PRINCIPLES FOR WRITING This manual mainly introduces how to use buttons on the remote control. You may operate the unit if the buttons to the unit have the same or similar names as or to those on the remote control. PLAYAB LE DISCS DVD-video Region number 4...
Page 9
About Discs CHAPTER It is smaller than title among the units of a DVD. A title is made up of several chapters , and each chapter has a number for search. But some discs may not have numbered chapters. TRACK In a CD, each track has a number to enable search functions.
Before Operation SECURITY • Before operation, check if the voltage of the unit is in line with the local voltage. • Hold the plug to disconnect it from the mains outlet. Do not pull the power cord. • When the plug of the unit is connected to the mains outlet, the unit will be still connected to AC even if the power is turned off.
Page 11
Before Operation USE REMOTE CONTROL 1 Open the battery compartment. 2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to the marks in the battery compartment. 3 Close the battery compartment. 4 Point the remote control at the remote sensor. Note: 1.Batteries can last for about 6 months generally.
Preparations Before Operation FRONT PANEL 1. STANDBY/ON To switch the unit on or off when connected to AC power outlet. 2. DISC TRAY 3. OPEN/CLOSE BUTTON To open or close the disc tray. 4. LED DISPLAY 5. USB PORT 6. PLAY/PAUSE To play the loaded disc.
Preparations Before Operation REAR PANEL 1. POWER CORD SOCKET 2. 5.1 CHANNEL AUDIO OUT 3. AUDIO OUT (L/R) 4. DIGITAL AUDIO COAXIAL OUT Connects digital audio under play mode into an AV amplifier or receiver equipped with digital audio decoder for you to enjoy the theatre-quality sound in your home.
Preparations Before Operation NAMES AND LAYOUT OF REMOTE CONTROL * After setting the mode by using SETUP menu (for example, NTSC select in NTSC /PAL/AUTO setup), the setting is kept though you switch the unit off and turn it on. V-MODE V-MODE OPEN/CLOSE...
Connections Turn off all equipments before operation. The unit has many kinds of output modes like A/V output, S-VIDEO output and digital signal output (COAXIAL). You may select as you need. CONNECTED TO A TV AND AN AUDIO AMPLIFIER Amplifier 2 Speakers Manufactured under license from Dolby Laboratories."Dolby"...
Basic Operations PLAY DISCS Press “ON/OFF” button on the TV and audio system, Press “TV/VIDEO” button on the TV, select VIDEO mode (TV). Select S-VIDEO mode if using an S-VIDEO connection. TV/VIDEO N ote: Select the correct audio input on the amplifier. The Step2 can be •...
Basic Operations V-MODE In case of connecting the component, Press the V-MODE on the remote control to select INTERLACE, PROGRESSIVE or S-VIDEO. V-MODE When you connect the composite, picture is not displayed, Press the V-MODE on the remote control to select composite video. S-VIDEO INTERLACE PROGRESSIVE...
Basic Operations FAST PLAY When playing disc, you may play it forward fast or reverse it fast to find what you need. FORWARDX2 Press to play forward fast. Each FORWARDX4 time you press the button, the speed of FORWARDX8 picture changes like the right sides. FORWARDX20 PLAY BACKWARDX2...
Playing a Desired Scene TO SKIP SCENES ON A DISC Press to move to the next chapter (or track). The current chapter (or track) moves to the next chapter (or track). Press to move to previous chapter (or track). The current chapter (or track) moves to the previous chapter (or track) or the first scene of the current chapter (or track).
Playing a Desired Scene PLAYING A DISC CONTAINING MP3 FILES When a MP3 disc is loaded, the MP3 menu screen is displayed automatically depending on the MP3 disc’s folder structure. ” buttons to select Using the “ the folder you want to play (from the screen on the left), then press the “...
Playing a Desired Scene REPEAT PLAY When play a disc, this function can be used to repeatedly play a title, chapter or disc. REPEAT Press “REPEAT” button, the screen shows orderly. N ote: - VCD/CD- - DVD - For the case of REPEAT : [CHAPTER] VCD disc, repeat REPEAT : [1]...
Playing a Desired Scene SELECT A SUBTITLE LANGUAGE When play a multi-subtitle DVD, you may select one subtitle to show it on the screen. Keep pressing [SUBTITLE] button till N ote: the user’s preferred language [ 1 CHINESE] appears. 1. For some discs, subtitles cannot If a DVD contains subtitle data, be removed.
Playing a Desired Scene PROGRAM The function can be used to play selected chapter and titles in a desired sequences. Press the PROG button when playing DVD, the following menu will appear as: PROGRAM 1 --:-- 5 --:-- 9 --:-- 13 --:-- 2 --:-- 6 --:--...
Playing a Desired Scene SEARCH For VCD/CD: During playback, press the "SEARCH" button to display the following menu: VCD: 03/45 00:00:00 00:00:00 03/45 Use the "LEFT/RIGHT" navigation buttons to select the 'track/time'. Using the numeric buttons, input the 'track/time' you want to play. For DVD: During playback, press the "SEARCH"...
Playing Disc in Various Ways SELECT ANGLE Some discs have multiple screen angles that you can select from. For example: if watching a train in motion. You may select to view the N ote: train from the front, the left, or the right, without stopping playback. Multi Angle function is limited to a DVD disc supporting multi...
Function Setting MENU SETTING According to the recorded information and external equipment, set the following functions for DVD to obtain the best playing status. Press the “SETUP” button to set the main menu. SETUP ..ENGLISH NTSC SPANISH...
Page 27
Function Setting BASIC NAVIGATION To navigate through the setting on the screen, use the direction buttons to scroll through the list of settings. Use the “ENTER” button to select the highlighted function. SETUP MENU Press the “SETUP” button to enter the on screen display and to exit it at any time. In each of the menus, selecting the MAIN PAGE (SETUP menu) will immediately return you to the initial screen.
Page 28
Function Setting TV SYSTEM You can select from NTSC, PAL, and AUTO. • Select "NTSC" for an NTSC TV. • Select "PAL" for a PAL TV. • Select "AUTO" for a multi-system TV. SCREEN SAVER You can set the screen saver ON or OFF. VIDEO You can set the Video Output Mode to INTERLACE, PROGRESSIVE, S-VIDEO.
Page 29
Function Setting DEFAULT This allows you to reset the unit to the factory default settings. LANGUAGE N ote: “OSD” means OSD LANGUAGE “On Screen Display”. When selecting a language, the screen shows the language you have selected. For example, if you select ENGLISH, the OSD is in English. AUDIO LANG •...
Page 30
Function Setting AUDIO OUT • OFF • RAW Select this when the DVD player is connected with a power amplifier through coaxial cable or optical cable. when a dolby digital DVD, MPEG DVD is played, select this, the coaxial port or optical port will output in the corresponding digital format (source code).
Page 31
Function Setting DOWNMIX Select Downmix mode to LT/RT, STEREO, VSS, 5.1CH. In 5.1CH, there are five options to select, as follows: SUBWOOFER In this item, you can set the subwoofer to on or off. CENTER There are three options to select, there are LARGE, SMALL, OFF.
Page 32
Function Setting OP MODE LINE OUT:It will be more suitable to choose this setting for playing in the night time, for the output volume is low. DYNAMIC RANGE FULL Set “ Off ” to view a program in the dynamic range as recorded in disc.
Others TROUBLESHOOTING If you experience the following problems while using this trouble shooting guide may be able to assist in resolving the issue. • NO SOUND - Check if the player is connected securely. - Make sure you operate the TV or amplifier correctly. •...
DivX ABOUT DivX VI DEO: DivX is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. VIsit www. divx.com for more information and software tools to convert your files into DivX video. ABOUT DivX VI DEO-ON-DEMAND: This DivX Certified device must be registered in order to play DivX Video-on-Demand (VOD) content.
