Summary of Contents for SONIQ D100-AU
-
Page 2: Table Of Contents
Table of contents Safety Information ........................ 2 Features ..........................5 About disc ..........................6 Before operation ........................8 Preparations before operation ..................10 Front Panel ........................... 10 Rear Panel ..........................11 Names and Layout of Remote Controls ................12 Connections ......................... -
Page 3: Safety Information
Safety Information Please read the manual carefully before using this BD player, and keep it safe for future reference. Warning TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER - SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. -
Page 4: Power Sources
Safety Information This set has been designed and manufactured to assure should be moved with care. Quick stops, excessive personal safety. Improper use can result in electric shock sorce, and uneven surfaces may cause the video or fire hazard. The safeguards incorporated in this unit will product and cart combination to overturn. - Page 5 Safety Information 21 REPLACEMENT PARTS 14 DISC TRAY 15 OVERLOADING 22 SAFETY CHECK 16 OBJECT AND LIQUID ENTRY 23 HEAT 17 BURDEN 18 DISC 19 SERVICING 20 DAMAGE REQUIRING SERVICE...
-
Page 6: Features
Features OUTSTANDING SOUND QUALITY Dolby Digital system developed by Dolby Laboratories features high quality surround sound which can be played in DVD or CD disc at home, to reproduce high quality sound effects. UNIQUE FUNCTIONS Multi-angle and multi-language bring unique trick functions. Parent lock makes it easy to control the content of discs. -
Page 7: About Disc
About Discs PRINCIPLES FOR WRITING This manual mainly introduces how to use buttons on the remote control. You may operate the unit if the buttons to the unit have the same or similar names as or to those on the remote control. PLAYAB LE DISCS DVD-video Region number 4... - Page 8 About Discs CHAPTER It is smaller than title among the units of a DVD. A title is made up of several chapters , and each chapter has a number for search. But some discs may not have numbered chapters. TRACK In a CD, each track has a number to enable search functions.
-
Page 9: Before Operation
Before operation SCEURITY • Before operation, check if the voltage of the unit is in line with the local voltage. • Hold the plug to disconnect it from the mains outlet. Do not pull the power cord. • When the plug of the unit is connected to the mains outlet, the unit will be still connected to AC even if the power is turned off. - Page 10 Before operation USE REMOTE CONTROL 1 Open the battery compartment. 2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to the marks in the battery compartment. 3 Close the battery compartment. 4 Point the remote control at the remote sensor. Note: 1.Batteries can last for about 6 months generally.
-
Page 11: Preparations Before Operation
Preparations Before Operation FRONT PANEL 4 5 6 7 - MIC VOL + MIC 1 MIC 2 ON/OFF 10 11 1. ON/OFF To switch the unit on or off when connected to AC power outlet. 2. DISC Tray 3. OPEN/CLOSE button To open or close the disc tray. -
Page 12: Rear Panel
Preparations Before Operation REAR PANEL 1. COMPONENT (Y. Pb. Pr) Connects to TV or monitor equipped with Component input. In order to achieve a sharper and cleaner picture than when connected via VIDEO OUT (composite video). 2. VIDEO OUT Connects composite video signal to input AV or PHONO sockets of TV or monitor to achieve high fidelity colour reproduction. -
Page 13: Names And Layout Of Remote Controls
Preparations Before Operation NAMES AND LAYOT OF REMOTE CONTROLS * After setting the mode by using SETUP menu (for example, NTSC select in NTSC /PAL/AUTO setup), the setting is kept though you swith the unit off and turn it on. V-MODE V-MODE OPEN/CLOSE... -
Page 14: Connections
Connections Turn off all equipments before operation. The unit has many kinds of output modes like A/V output, S-VIDEO output and digital signal output (COAXIAL). You may select as you need. CONNECTED TO A TV AND AN AUDIO AMPLIFIER Amplifier 2 Speakers Manufactured under license from Dolby Laboratories."Dolby"... -
Page 15: Play Discs
Basic Operatiions PLAY DISCS Press “ON/OFF” button on the TV and audio system, Press “TV/VIDEO” button on the TV, select VIDEO mode (TV). Select S-VIDEO mode if using an S-VIDEO connection. TV/VIDEO N ote: Select the correct audio input on the amplifier. The Step2 can be •... -
Page 16: Basic Operations
Basic Operations MENU During DVD playback,press this button, the unit will directly back to root menu. During the playback,Press the OSD to show disc information, such as disc type, total chapter, current play chapter and so on. FAST PLAY When playing disc, you may play it forward fast or reverse it fast to find what you need. -
Page 17: Play/Pause
Basic Operations PLAY/PAUSE N ote: Press the “PLAY/PAUSE” button during playback to pause playback. Press PLAY to play normally. SELECT AUDIO LANGUAGE When playing a multi-language DVD, you can choose which language to playback in. Press the “AUDIO”button, 2CHIN then select the language you would like for playback. -
Page 18: Playing A Desired Scene
Playing a desired scene TO SKIP SCENES ON A DISC Press to move to the next chapter (or track). The current chapter (or track) moves to the next chapter (or track). Press to move to previous chapter (or track). The current chapter (or track) moves to the previous chapter (or track) or the first scene of the current chapter (or track). -
Page 19: Playing A Disc Containing Mp3 Files
Playing a desired scene PLAYING A DISC CONTAINING MP3 FILES When a MP3 disc is loaded, the MP3 menu screen is displayed automatically depending on the MP3 disc’s folder structure. ” buttons to select Using the “ ▲ ▲ the folder you want to play (from the screen on the left), then press the “... -
Page 20: Repeat Play
Playing a Desired Scene REPEAT PLAY When play a disc, this function can be used to repeatedly play a title, chapter or disc. REPEAT Press “REPEAT” button, the screen shows orderly. N ote: For the case of - DVD - - VCD- VCD disc, repeat REPEAT : [CHAPTER]... -
Page 21: Select A Subtitle Language
Playing a Desired Scene SELECT A SUBTITLE LANGUAGE When play a multi-subtitle DVD, you may select one subtitle to show it on the screen. Keep pressing [SUBTITLE] button till N ote: the user’s preferred language [ 1 CHINESE] appears. 1. For some discs, subtitles cannot If a DVD contains subtitle data, SUBTITLE... -
Page 22: Program
Playing a desired scene PROGRAM The function can be used to play selected chapter and titles in a desired sequences. Press the PROG button when playing DVD, the following menu will appear as: 1 --:-- 5 --:-- 9 --:-- 13 --:-- 2 --:-- 6 --:-- 10 --:--... -
Page 23: Search
Playing a Desired Scene SEARCH For VCD/CD: During playback, press the "SEARCH" button to display the following menu: VCD: 03/45 00:00:00 00:00:00 03/45 Use the "LEFT/RIGHT" navigation buttons to select the 'track/time'. Using the numeric buttons, input the 'track/time' you want to play. For DVD: During playback, press the "SEARCH"... -
Page 24: Play Discs In Various Ways
Play discs in various ways SELECT ANGLE Some discs have multiple screen angles that you can select from. N ote: For example: if watching a train in motion. You may select to view the train from the front, the left, or the right, without stopping playback. Multi Angle function is limited to a DVD disc supporting multi... -
Page 25: Function Setting
Function Setting MENU SETTING According to the recorded information and external equipment, set the following functions for DVD to obtain the best playing status. Press the “SETUP” button to set the main menu. SETUP ..NTSC ENGLISH TV SYSTEM... - Page 26 Function Setting BASIC NAVIGATION To navigate through the setting on the screen, use the direction buttons to scroll through the list of settings. Use the “ENTER” button to select the highlighted function. SETUP MENU Press the “SETUP” button to enter the on screen display and to exit it at any time. In each of the menus, selecting the MAIN PAGE (SETUP menu) will immediately return you to the initial screen.
- Page 27 Function Setting TV SYSTEM You can select from NTSC, PAL, and AUTO. • Select "NTSC" for an NTSC TV. • Select "PAL" for a PAL TV. • Select "AUTO" for a multi-system TV. SCREEN SAVER You can set the screen saver ON or OFF. VIDEO You can set the Video Output Mode to RGB,CVBS.
- Page 28 Function Setting DEFAULT This allows you to reset the unit to the factory default settings. LANGUAGE N ote: OSD LANGUAGE “OSD” means “On Screen When selecting a language, the screen shows the language you have Display”. selected. For example, if you select ENGLISH, the OSD is in English. AUDIO LANG •...
- Page 29 Function Setting AUDIO OUT • OFF • RAW Select this when the DVD player is connected with a power amplifier through coaxial cable or optical cable. when a dolby digital DVD, MPEG DVD is played, select this, the coaxial port or optical port will output in the corresponding digital format (source code).
- Page 30 Function Setting DOWNMIX Select Downmix mode to LT/RT, STEREO, VSS. OP MODE LINE OUT:It will be more suitable to choose this setting for playing in the night time, for the output volume is low. DYNAMIC RANGE FULL Set “ Off ” to view a program in the dynamic range as recorded in disc.
-
Page 31: Others
Others TROUBLESHOOTING If you experience the following problems while using this trouble shooting guide may be able to assist in resolving the issue. • NO SOUND - Check if the player is connected securely. - Make sure you operate the TV or amplifier correctly. •... -
Page 32: Technical Specifications
Others TECHNICAL SPECIFICATIONS Wavelength 650nm Laser NTSC/PAL/AUTO Video 20Hz ~ 20KHz (±3dB) Frequency response ≥ 90dB Signal/noise ratio ≥ 85dB ( 1kHz) Channel separation ≥ 80dB ( 1kHz) Dynamic range Output level: 2.0 + 0/-0.2Vrms Analog (Load impedance: 10k Ω) Output Audio Output level: 0.5 ±... -
Page 33: Divx
Divx ABOUT DIVX VIDEO: ABOUT DIVX VIDEO: DIVX is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified device must be registered in order to play DivX Video-on-Demand (VOD) content.
