HP Compaq 8300 Elite Specification page 9

QuickSpecs
Standard Features
INTEL® STANDARD MANAGEABILITY
Includes DASH 1.0/1.1 compliance plus:
System Defense
Agent Presence
SOL/IDE Redirection
CISCO NAC/SDN support
ME Wake on LAN
Host Based Configuration
ME Firmware Rollback
IPv6 Support
DASH 1.0/1.1 compliance:
Boot Control
HW Inventory
SW Inventory
Power State Management
HW Alerting
SMBIOS
System Management BIOS, previously known as DMI BIOS, is used to store system management information
GRAPHICS
Integrated (depends on processor)
Intel HD Graphics: Basic, 2000, 2500, or 4000
Models with Intel Core i3/i5/i7 processors include HD 2000, 2500, or 4000 graphics. Models with Pentium or Celeron processors
include HD graphics. Please see specific processors for graphics configuration.
Discrete (optional)
AMD Radeon HD 7650A 2GB DDR3 MXM Graphics
NVIDIA GeForce GT 630M 2GB DDR3 MXM Graphics
Graphics controller
Core clock
Memory clock
Memory frame buffer
Memory
Supported Graphics APIs
Graphics controller
Core clock
DA - 14352 North America — Version 38 — November 21, 2013
HP Compaq 8300 Elite All-in-One PC
AMD Radeon HD 7650A
600MHz max
800MHz max
2GB, DDR3, 128-bit wide
2GB DDR3
DX11, OpenGL, full 1080p Blu-Ray Disc
(H264) playback in hardware, Multi-
Stream DisplayPort support (supports up
to 4 displays total - 4 independent video
and audio streams)
NVIDIA GF108
675MHz
Page 9
