NEC Storage HS8 Specification

Product
Node Con guration 1HN Con guration 1HN+1SN Con guration
1 1
Hybrid Node (HN)
Number of Nodes*
1
Storage Node (SN) 0 1
12 TB (up to 48 TB) 96 TB
Raw Capacity
Capacity* 2 * 3
156 TB (up to 624 TB)
Effective Capacity 1.25 PB
5.58 TB/h 5.58 TB/h
Maximum Performance* 5
Standard
Network Interface
Optional
Standard
Number of
Network Interface Ports Optional (10GbE NIC x 1)
(per Hybrid Node)
Optional (10GbE NIC x 2)
Disk Interface
Disk Drive Speci cations
(per Node)
Capacity* 3 /Rotations/Units
Supported Protocols
Supported Backup Software* 7 NetBackup, BackupExec, ARCserve Backup, NetWorker, Data Protector, NetVault Backup, Tivoli Storage Manager, CommVault, Oracle Recovery Manager
Supported Archive Software*
7
Temperature
Ambient Operating
Conditions
Humidity*
8
Input Voltage
Weight
32 kg
Dimensions (WxDxH)*
9 448 x 696 x 89 mm (2U)
Power Consumption 673 W 1,297 W
*1: The NEC Storage HS8 scale-out model is expandable from 1 HN up to 60 total nodes. Exact con guration will vary according to your performance/capacity requirements. For details, contact us.
*2: Capacity for 3 parities. The effective capacity is calculated assuming a compression ratio of 20:1. (The compression ratio varies with the type of data.)
*3: Calculated where 1 GB = 1,000,000,000 bytes, 1 TB = 1,000 GB, and 1 PB = 1,000 TB.
*4: Capacity for a 2 HN con guration when using clustering (6 parities). The effective capacity is calculated assuming a compression ratio of 20:1. (The compression ratio varies with the type of data.)
*5: Performance achieved when OpenStorage Express I/O software is used with a typical full backup pattern (95% of existing data is duplicated).
*6: Can also be used with 100BASE-TX/10BASE-T.
*7: Supported software will gradually be increased. Contact us for details on supported software.
*8: No condensation both when operating and when on standby.
*9: Not including the front bezel, slide rails, and protrusions.
Optional Software
Replication Software product for replicating (copying) stored data to a remote site via a network
Data Protection Software product for preventing a le from being changed or deleted for a given period of time
Encryption Software product for preventing data leakage in case of theft or disposal of the HDD and/or node.
OpenStorage Software product for optimizing Symantec NetBackup
- Copies backup data from a main site to a remote site at a high speed, consolidating the management of both sites.
- Offers original protocol for performing high-speed backup and restore.
- Makes new full backup data from the existing full backup and incremental/differential backup, and saves in the storage unit.
Environmental Compliance
Eco Symbol
The Eco Symbol is a label placed on products that meet NEC's prescribed environmental soundness standards.
Eco Symbol products must be environmentally superior and assure transparency.
RoHS Compliance This product complies with the European Union's directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS).
NetBackup, BackupExec and Enterprise Vault are trademarks or registered trademarks of Symantec Corporation in the United States and other countries.
EMC and NetWorker are trademarks and registered trademarks of EMC Corporation.
HP and Data Protector are registered trademarks of Hewlett-Packard Company.
ARCserve is a trademark or registered trademark of CA, Inc. and its af liates.
Ethernet is a registered trademark of Xerox Corporation.
NetValut is a registered trademark of Quest Software,Inc.
Tivoli is a registered trademark of International Business Machines Corporation in the United States and other countries.
CommValut and Simpana are trademarks or registered trademarks of CommVault, Inc.
Oracle is a registered trademark of Oracle Corporation and/or its af liates.
All other products, brands, and trade names used in this document are trademarks or registered trademarks of their respective holders.
Before using this product, please read carefully and comply with the cautions and warnings in manuals such as the Installation Guide and
Safety Notice
Safety Precautions. Incorrect use may cause a re, electrical shock, or injury.
For further information, please contact:
Speci cations and designs in this catalog are subject to change for improvement without notice.
NEC Corporation
NEC Storage HS8
NEC Storage HS8 Scale-Out Model
Max. Con guration
2HN Con guration 2HN+2SN Con guration
(Performance Focused)
2 2 60
0 2 0
96 TB 192 TB 2.8 PB
1.25 PB (828 TB* )
4 2.50 PB 37.4 PB
11.2 TB/h 11.2 TB/h 335 TB/h
(Copper: RJ-45 connector)
1000BASE-T* 6
10GBASE-SR (Optical: LC connector)
1000BASE-T* 6 x 6
10GBASE-SR x 2 + 1000BASE-T* x 2
6
10GBASE-SR x 4 + 1000BASE-T* 6 x 2
3.5-inch SATA (6 Gbps)
4 TB/7,200 rpm/12
NFS, CIFS, Symantec OpenStorage
Enterprise Vault, StorageForce, InformationAssessmentSystem
10 to 40ºC (while operating), -10 to 55ºC (on standby)
20 to 80% RH (while operating), 20 to 80% RH (on standby)
AC100-240V 50/60Hz
64 kg 140 kg 2,004 kg
448 x 696 x 178 mm (4U) 448 x 696 x 445 mm (10U) 448 x 696 x 5,956 mm (134U)
1,346 W 2,904 W 42,550 W
As of July 2013 Cat.No.E04-13080002E
NEC Storage Series
July 2013
Max. Con guration
(Capacity Focused)
2
58 Backup/Archival Storage
11.2 TB/h
NEC Storage HS8
Backup/Archival Storage
39,708 W
for the Age of Big Data
