Subaru XV Crosstrek Specifications

XV CROSSTREK Trim Levels
®
Which XV Crosstrek is yours?
XV Cros st rek 2 .0i Prem i um
• 148-hp 2.0-liter 4-cylinder SUBARU BOXER ® engine
• Subaru Symmetrical All-Wheel Drive
• 5-speed manual transmission or optional Lineartronic ® CVT
(Continuously Variable Transmission) with manual-mode paddle shifters
• Fog lights
• 17-inch aluminum-alloy wheels
• Roof rails, black finish
• Cloth upholstery
• 6-speaker single-CD audio system with USB port/iPod control and
®
Bluetooth connectivity
®
• 6-way manually adjustable driver's seat. 4-way manually adjustable
front-passenger's seat.
• Cargo-area tray
• All-Weather Package
Protecting Your Investment
Once you're part of our family, we'll be there for you. Every Subaru comes with 24-hour roadside assistance for 3 years or 36,000 miles. If you have trouble on the road,
a tow to the nearest Subaru dealership and other services are just a phone call away. And to protect you over the long haul, we offer Added Security
agreements and maintenance plans that will help protect your car for up to 7 years or 100,000 miles. Added Security
backed by Subaru, and because we've been backing them for more than 30 years, they're agreements you can trust. Your dealer has full coverage details.
Warranties
New Car Limited Warranty 3 years or 36,000 miles, whichever comes first.
Powertrain Limited Warranty 5 years or 60,000 miles, whichever comes first.
Wear Item Limited Warranty 3 years or 36,000 miles, whichever comes first. Repairs to the following items will also be covered under
Wear Item Limited Warranty: • Brake Pads • Wiper Blades • Clutch Linings • Transmitter Batteries
Rust Perforation Limited Warranty 5 years, unlimited mileage.
X V C ro s s t re k 2. 0 i Li mi t e d
• 148-hp 2.0-liter 4-cylinder SUBARU BOXER ® engine
• Subaru Symmetrical All-Wheel Drive
• L ineartronic ® CVT (Continuously Variable Transmission) with manual-mode
paddle shifters
• Fog lights
• 17-inch aluminum-alloy wheels
• Roof rails, black finish
• 6-way manually adjustable driver's seat. 4-way manually adjustable
front-passenger's seat.
• Cargo-area tray
• All-Weather Package
Leather-wrapped 3-spoke steering wheel
s
Leather-trimmed upholstery
s
Automatic climate control system
s
6-speaker single-CD audio system with 4.3-inch LCD display, HD Radio
s
USB port/iPod ® control and Bluetooth ® connectivity
Auto-on/off headlights
s
Rear-Vision Camera
s
Additions or differences from preceding trim level.
s
® —extended service
offers the only mechanical and maintenance plans
®
XV CROSSTREK Specifications
®
EN G I N E D R I V E T R A I N
a n d
Engine
Power
Torque
Manual transmission
Automatic transmission
CA Emissions
T R AC T I O N S TA B I L I T Y
a n d
Symmetrical All-Wheel Drive
Vehicle Dynamics Control
(VDC)
Traction Control System
(TCS)
FU EL
Fuel economy
(city/highway/combined) 2
Fuel requirement
Fuel capacity
C H A S S I S
Steering
™ ,
Suspension
Brakes
Brake discs (front/rear)
Brake Assist
Brake Override System
W H EEL S T I R ES
a n d
Wheels
Tires
E X T ER I O R I N T ER I O R D I M EN S I O N S
a n d
Length/Width/Height
Wheelbase
Track (front/rear)
Headroom (front/rear)
Legroom (front/rear)
Shoulder room (front/rear)
Passenger volume
Cargo volume
Maximum cargo volume
Base curb weight
(manual/automatic)
Ground clearance
(at base curb weight)
Maximum towing capacity
2.0i
2.0-liter DOHC aluminum-alloy 16-valve horizontally opposed 4-cylinder SUBARU BOXER
148 hp @ 6,200 rpm
145 lb-ft @ 4,200 rpm
Fully synchronized 5-speed manual
2.0i Premium: Standard
2.0i Limited: N/A
Lineartronic ® CVT (Continuously Variable Transmission) with manual-mode paddle shifters
2.0i Premium: Optional
2.0i Limited: Standard
PZEV
1
Standard
VDC electronic stability control utilizes sensors which constantly monitor wheel speeds, steering angle, brake pressure, vehicle
yaw rate and lateral g-forces. If VDC detects a difference between the driver's intended path and the one the vehicle is actually
taking, VDC applies braking power and/or reduces engine torque to help correct vehicle path.
VDC also incorporates an all-wheel, all-speed traction control system which senses a loss of traction and applies braking force to
the slipping wheel or wheels as necessary to maintain vehicle motion.
Manual: 23/30/26 mpg
CVT: 25/33/28 mpg
Unleaded gasoline (87 octane)
15.9 gallons
Electric power-assisted rack-and-pinion. Turning circle: 34.8 feet.
4-wheel independent raised. Front: MacPherson strut type. Rear: Double-wishbone. Front and rear stabilizer bars.
4-wheel disc, ventilated front.
4-channel, 4-sensor ABS with Electronic Brake-force Distribution (EBD).
11.6 inches/10.8 inches
When emergency braking is detected by how quickly the brake pedal is pressed, maximum brake pressure is immediately applied.
If both brake and accelerator pedals are pressed simultaneously, the system reduces the operation of the accelerator pedal to help
prevent unintentional vehicle acceleration.
17 x 7.0-inch 5-spoke aluminum-alloy. Dark gray with machine finish.
225/55 R17 95H all-season
175.2 inches/70.1 inches/63.6 inches (with roof rails)
103.7 inches
60.0 inches/60.0 inches
39.8 inches/37.7 inches
(with moonroof: 37.2 inches/37.7 inches)
43.5 inches/35.4 inches
55.6 inches/54.2 inches
97.5 cubic feet (with moonroof: 94.0 cubic feet)
22.3 cubic feet
51.9 cubic feet with rear seatback lowered
2.0i Premium: 3,087 lbs/3,142 lbs
2.0i Limited: /3,164 lbs
n / a
8.7 inches
1,500 lbs
® engine with Dual Active Valve Control System.
