Summary of Contents for Subaru Crosstrek

  • Page 1 2017 Quick Reference Guide...

  • Page 2: Basic Operation

    For detailed operating and safety information, please refer to your Owner’s Manual. BASIC OPERATION Lock/Unlock doors Remote keyless entry system All doors and the rear gate will be locked. The driver’s door will be unlocked. (To unlock all doors and the rear gate, briefly press the button a second time within 5 seconds.) The rear gate will be unlocked.

  • Page 3: Tilt/Telescopic Steering Wheel

    Adjust each component Front seat Forward and backward adjustment Seat height adjustment (Driver’s seat only) Seatback reclining adjustment Tilt/telescopic steering wheel Adjust the seat position and pull the tilt/ telescopic lock lever down. Move the steering wheel to the desired level. Pull the lever up to lock the steering wheel in place.

  • Page 4: Start/Stop Engine

    Start/Stop engine Push-button ignition switch (if equipped) To start engine: STEP1: Carry the access key, and sit in the driver’s seat. Operation STEP2: Apply the parking brake. indicator STEP3: Shift the select lever into the P position. STEP4: Depress the brake pedal until the indicator on the push-button ignition switch turns green.

  • Page 5: Continuously Variable Transmission (If Equipped)

    Operate Select lever/Shift lever Continuously variable transmission (if equipped) With the brake pedal depressed, shift while pressing the Select lever button in. Select lever Shift while pressing the Select lever button button Shift without pressing the Select lever button. M = Manual mode With the vehicle either moving or stationary, move the select lever from the D position to the M position to select the manual mode.
  • Page 6 MAIN PARTS AND OPERATION Headlight switch/Turn signal lever/Front fog light switch (if equipped) Headlights Headlight flasher, High/Low beam change (dimmer) Turn signal Front fog lights (if equipped) To turn on the front fog lights, rotate dial to Front fog lights operate only when headlight switch is in...

  • Page 7: Hazard Warning Flasher Switch

    Wiper and washer switch Windshield wiper To operate the wiper, rotate knob to; : Mist (for a single wipe) : Off : Intermittent : Low speed : High speed Wiper intermittent time control Windshield washer Rear window wiper and washer To operate the wiper, rotate knob to;...

  • Page 8: Power Window Switches

    Defroster button/Rear window defogger button Defroster button: Turn the airflow mode selection dial. Rear window defogger button: Press the button to turn on rear window defogger, outside mirror defogger and windshield wiper deicer (if equipped). The function will automatically shut off after approximately 15 minutes.

  • Page 9: Child Safety Locks

    Fuel filler lid release lever Right side This indicates that the fuel filler door (lid) is located on the right side of the vehicle. Child safety locks Located on the edge of each rear door. When the lever is in the LOCK position, the rear door cannot be opened from the inside.

  • Page 10: Audio Control Buttons

    FUNCTION FOR MORE COMFORTABLE DRIVE Audio control buttons These buttons allow the driver to control audio functions without taking his/her hands off the steering wheel. Cruise control buttons (if equipped) Models without EyeSight system Cruise control enables you to maintain a constant vehicle speed without holding your foot on the accelerator pedal and it is operative when the vehicle speed is 40 km/h (25 mph) or more.

  • Page 11: Information Display (If Equipped)

    Models with EyeSight system EyeSight is a driving support system that uses a range of functions to assist the driver in making decisions in order to provide for more safe and comfortable driving and to reduce driver fatigue. (CRUISE) switch (Following distance setting) switch RES/+ switch SET/- switch...

  • Page 12: Multi Information Display (If Equipped)

    Multi information display (if equipped) Fuel gauge Warning screen/Basic screen Cruise control information display Warning indicator km/h Select lever/gear position indicator Odometer/double trip meter Control switch: By operating ▲ or ▼ of the control switch, the screens and selection items can be switched. When the SET switch is pulled toward you, the item can be selected and set.
  • Page 13 Steering responsive fog lights OFF switch (Models with EyeSight system) If the steering responsive fog lights OFF switch is pressed, the steering responsive fog lights OFF indicator is displayed on the Multi information display of the combination meter, and the steering responsive fog lights system is deactivated.

  • Page 14: Lane Departure Warning

    Moonroof switches (if equipped) Tilting Sliding Raise Open Lower Close Lane Departure Warning OFF switch (Models with EyeSight system) Press and hold this switch for approximately 2 seconds or longer to turn off the Lane Departure Warning and Lane Sway Warning functions. Lane Departure Warning When vehicle speed is approximately 50 km/h (30 MPH) or more, this function warns the driver if the system detects that the vehicle is likely to depart the traffic lane.

  • Page 15: Warning Lights

    Some warning/indicator lights illuminate for a few seconds in order to check themselves when the ignition switch is turned ON. Warning lights Refer to your Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized SUBARU dealer. Seatbelt warning Charge warning Remind the driver to fasten Charging system malfunction.
  • Page 16 Windshield washer fluid warning The fluid level in the windshield washer fluid tank decreases to the lower limit. Access key warning The access key is not inside the vehicle. For other situations, refer to your Owner’s Manual. Automatic headlight beam leveler warning Automatic headlight beam leveler malfunction. ABS warning Anti-lock Brake System malfunction/EBD System malfunction (Brake System warning light illuminates simultaneously).

  • Page 17: Indicator Lights

    Indicator lights The following indicators show the current status of your car. Refer to your Owner’s Manual for more information. Turn signal Headlight High beam indicator indicator indicator Front fog light Security BSD/RCTA OFF indicator indicator indicator Front passenger’s frontal Vehicle Dynamics airbag ON/OFF indicators Control OFF indicator...
  • Page 18 Notes ◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
  • Page 19 Notes...
  • Page 20 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
