Sennheiser HDA 200 Technical Data

HDA 200
Closed dynamic headphones designed for extended high frequency testing.
Features
♦
Excellent passive attenuation (based on Peltor
♦
Very high quality sound reproduction
♦
Convenient single sided cable
♦
Padded headband and additional adjustable/removable cushions for increased comfort
♦
Soft, replaceable circumaural ear pads
♦
Color coded ear cups, right (red) left (blue)
HDA200 is PTB approved. Physikalisch-Technische
Bundesanstalt, Braunschweig, Germany. PTB is equivalent to
the National Bureau of Standards.
HDA 200 Frequency Response Test Conditions
•
All measurements are done on a calibrated coupler
B&K 4153 (artificial ear) with the standard cone
YJ0304 above the adapter plate, type DB 0843.
•
The pressure of the headband shall be 10N ± 1N.
•
The RMS input voltage to the headphone is 0.5 V.
•
The measurements are done with steady state sine
wave signals.
•
The output impedance of the signal source shall be
<1 Ohm.
•
Climatic conditions:
Temperature
Humidity
Atmospheric pressure
Sennheiser Electronic Corporation One Enterprise Drive PO Box 987, Old Lyme, CT 06371
Tel: 860-434-9190 Fax: 860-434-1759 Web site: www.sennheiserusa.com
Audiometric Headphone
º
T=20 C
H=50%rel
P=approx. 100kPa
All data are influenced by temperature, humidity and static pressure.
Ear Defenders)
TM
Technical Data
Frequency response
PTB calibrated
Transducer principle
Nominal impedance
Characterisitic SPL
Max permanent load
Coupling
Caliper pressure
Weight (with cable)
Cable approx. 3 m,
Connection
Standard SPL
frequencies (dB 20 µPa) attenuation
(Hz) @ .5 Vrms
125 112.5
250 113.0
500 112.0
750 111.0
1,000 108.5
2,000 104.0
3,000 104.0
4,000 104.0
5,000 106.5
6,000 107.5
8,000 105.5
9,000 105.0
10,000 102.5
11,200 102.0
12,500 103.0
14,000 98.5
16,000 100.0
20 to 20,000 Hz
< >
see table
dynamic, closed
40 Ohm
100 dB at 1 kHz, 1 mW
500 mW
circumaural
10 N
330 g
single-sided, open-ended
yellow + L
black – L
red + R
white – R
Passive Maximum SPL
(<10 min. @
(dB) 5 V RMS)
14.3 132 ± 3
15.9 132 ± 3
22.5 132 ± 3
- 131 ± 3
28.6 129 ± 3
32.0 - 124 ± 3
-
32.0 124 ± 3
45.7 124 ± 3
- 127 ± 3
- 125 ± 3
43.8 125 ± 5
- 123 ± 5
- 122 ± 5
- 123 ± 5
- 118 ± 5
- 119 ± 5
- 120 ± 5
