GE 3413 User Manual

25832 A compliant telephone cord and modular plug is provided with
Extra Handset and Recharge Cradle
this product. It is designed to be connected to a compatible
with Call-Waiting Caller ID for Use with
modular jack that is also compliant. See installation instructions
Models 25831, 25833 and 25835
for details.
User's Guide
Notes
• This equipment may not be used on coin service provided by the
telephone company.
• Party lines are subject to state tariffs, and therefore, you may not
be able to use your own telephone equipment if you are on a
party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent
disconnection of your telephone from your line.
• If your home has specially wired alarm equipment connected to
the telephone line, ensure the installation of this product does
not disable your alarm equipment. If you have questions about
what will disable alarm equipment, consult your telephone
company or a qualified installer.
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may
harm the telephone network, the telephone company shall,
where practicable, notify you that temporary discontinuance of
service may be required. Where prior notice is not practicable
and the circumstances warrant such action, the telephone
company may temporarily discontinue service immediately. In
case of such temporary discontinuance, the telephone company
must: (1) promptly notify you of such temporary discontinuance;
(2) afford you the opportunity to correct the situation; and (3)
inform you of your right to bring a complaint to the Commission
pursuant to procedures set forth in Subpart E of Part 68, FCC
Rules and Regulations.
E A I
QUIPMENT PPROVAL NFORMATION The telephone company may make changes in its
communications facilities, equipment, operations or procedures
Your telephone equipment is approved for connection to the Public
where such action is required in the operation of its business and
Switched Telephone Network and is in compliance with parts 15 and
not inconsistent with FCC Rules and Regulations. If these changes
68, FCC Rules and Regulations and the Technical Requirements for
are expected to affect the use or performance of your telephone
Telephone Terminal Equipment published by ACTA.
equipment, the telephone company must give you adequate
1 Notification to the Local Telephone Company notice, in writing, to allow you to maintain uninterrupted service.
On the bottom of this equipment is a label indicating, among
FCC RF R
ADIATION
other information, the US number and Ringer Equivalence
Number (REN) for the equipment. You must, upon request, This equipment complies with FCC RF radiation exposure limits
provide this information to your telephone company. set forth for an uncontrolled environment. This equipment should
be installed and operated with a minimum distance of 20
The REN is useful in determining the number of devices you may
centimeters between the radiator and your body. This transmitter
connect to your telephone line and still have all of these devices
must not be co-located or operated in conjunction with any other
ring when your telephone number is called. In most (but not all)
antenna or transmitter.
areas, the sum of the RENs of all devices connected to one line
should not exceed 5. To be certain of the number of devices you For body worn operation, this phone has been tested and meets the
may connect to your line as determined by the REN, you should FCC RF exposure guidelines when used with the belt clip supplied
contact your local telephone company. with this product. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
A plug and jack used to connect this equipment to the premises
wiring and telephone network must comply with the applicable
FCC Part 68 rules and requirements adopted by the ACTA.
THE LIGHTNING
FLASH AND ARROW
WARNING: TO
HEAD WITHIN THE
PREVENT FIRE OR TRIANGLE IS A
WARNING SIGN
ATLINKS USA, Inc. ELECTRICAL SHOCK
ALERTING YOU OF
HAZARD, DO NOT
"DANGEROUS
101 West 103rd Street
EXPOSE THIS VOLTAGE" INSIDE
THE PRODUCT.
Model 25832 Indianapolis, IN 46290
PRODUCT TO RAIN
00003413 (Rev. 0 E) © 2005 ATLINKS USA, Inc. OR MOISTURE.
05-08 Trademark(s) ® Registered
Printed in China Marca(s) Registrada(s)
I I
NTERFERENCE NFORMATION
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference; and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna
for radio or television that is "receiving" the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit
different from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult
your dealer or an experienced radio/television technician for
additional suggestions. Also, the Federal Communications
Commission has prepared a helpful booklet, "How To Identify and
Resolve Radio/TV Interference Problems. " This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402.
Please specify stock number 004-000-00345-4 when ordering copies.
L
ICENSING
Licensed under US Patent 6,427,009
E S H A C
XPOSURE TATEMENT EARING ID OMPATIBILITY
This telephone system meets FCC standards for Hearing Aid Compatibility.
I
NTRODUCTION
CAUTION: When using telephone equipment, there are
basic safety instructions that should always be followed. Refer
to the IMPORTANT SAFETY INSTRUCTIONS provided with
this product and save them for future reference.
Congratulations on purchasing this extra GE cordless handset with Call
Waiting Caller ID. This telephone has been designed to be simple to
use, however, you can reach its full potential more quickly by taking a
few minutes to read this instruction book. This telephone is a
CAUTION:
multifunction product for use with Call Waiting and Caller ID services
RISK OF ELECTRIC SHOCK
DO NOT OPEN available from your local telephone company.
CAUTION: TO REDUCE THE THE EXCLAMATION
RISK OF ELECTRIC SHOCK, DO POINT WITHIN THE
Your Call Waiting Caller ID phone allows you to:
NOT REMOVE COVER (OR TRIANGLE IS A
BACK). NO USER WARNING SIGN
SERVICEABLE PARTS INSIDE. ALERTING YOU OF • view the name and telephone number of a caller while you are on
REFER SERVICING TO IMPORTANT
QUALIFIED SERVICE INSTRUCTIONS the phone (Call Waiting Caller ID).
PERSONNEL. ACCOMPANYING
THE PRODUCT.
• identify callers before you answer the phone.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
• view the time and date of each incoming call.
• record up to 40 Caller ID messages sequentially in each handset.
B Y B
EFORE OU EGIN
• know who called while you are on the other line or when you
were away.
P C
• screen unwanted calls, eliminate harassment from annoying ARTS HECKLIST
calls, or to get prepared before answering a call.
Make sure your package includes the items shown here.
IMPORTANT: Because cordless phones operate on electricity,
you should have at least one phone in your home that isn't
cordless, in case the power in your home goes out.
IMPORTANT: In order to use all of the features of this
telephone, you must subscribe to two separate services available
from your local telephone company: the standard Name/
Handset Belt Battery
Number Caller ID Service to know who is calling when the
Clip compartment
phone rings and Call Waiting Caller ID Service to know who is
cover
calling while you are on the phone.
I P
NSTALLING THE
INSTALLATION NOTE: Some cordless telephones operate at
frequencies that may cause or receive interference with nearby
IMPORTANT: Make sure the extra handset is registered
TVs, microwave ovens, and VCRs. To minimize or prevent such
to GE Models 25831, 25833, or 25835 before use. Refer
interference, the base of the cordless telephone should not be
to the GE 25831, 25833, or 25835 instruction book for
placed near or on top of a TV, microwave ovens, or VCR. If such
detailed installation and operation information.
interference continues, move the cordless telephone farther away
• Never install telephone wiring during a lightning storm.
from these appliances. Certain other communications devices may
also use the 2.4/5.8 GHz frequency for communication, and, if not • Never install telephone jacks in wet locations unless the jack is
properly set, these devices may interfere with each other and/or specifically designed for wet locations.
your new telephone. Typical devices that may use the 2.4/5.8 GHz
• Never touch non-insulated telephone wires or terminals, unless the
frequency for communication include wireless audio/video senders,
telephone line has been disconnected at the network interface.
wireless computer networks, multi-handset cordless telephone
• Use caution when installing or modifying telephone lines.
systems, and some long-range cordless telephone systems.
• Temporarily disconnect any equipment connected to the phone
H C C L
such as faxes, other phones, or modems.
ANDSET AND HARGE RADLE AYOUT
I I
MPORTANT NSTALLATION
• Install telephone near an electrical power outlet.
• Avoid sources of noise, such as a window by a busy street, and
electrical noise, such as motors, microwave ovens, and
fluorescent lighting.
Display
• Avoid heat sources, such as heating air ducts, heating appliances,
CALLER ID/VOL - /+
radiators, and direct sunlight.
(caller ID/volume button)
• Avoid areas of excessive moisture or extremely low temperature.
TALK/CALLLBACK Headset Jack
• Avoid dusty locations.
(button)
SPEAKER (button) • Avoid other cordless telephones or personal computers.
DELETE (button) 1. Plug the charge cradle power adaptor into an electrical outlet.
CONF/FORMAT
(conference/format button)
2. Install the handset battery.
#PAUSE/RINGER
*EXIT (button)
I H
NSTALLING THE ANDSET
(button)
REDIAL (button)
MEMORY (button) NOTE: You must connect the handset battery before use.
FLASH (button)
1. Locate battery and battery door which are packaged together
INT
(intercom button) inside a plastic bag and are separate from the handset.
MUTE/PROG
(mute/program button)
2. Locate the battery compartment on the back of the handset.
3. Plug the battery pack cord into the jack inside the compartment.
NOTE: It is important to maintain the polarity (black and red wires)
to the jack inside the compartment. To ensure proper battery
installation, the connector is keyed and can be inserted only one way.
4. Insert the battery pack.
charge indicator
5. Close the battery compartment by pushing the door up until it
snaps into place.
6. Place the handset in the charging cradle. The charge indicator
turns on to indicate the battery is charging.
7. Allow the handset to charge for 16 hours prior to registration to
GE Models 25831, 25833, or 25835. If you don't properly charge
the phone, battery performance is compromised.
BATTERY
BLACK WIRE
Handset battery Handset charge cradle
PRESS DOWN
pack
FIRMLY
RED WIRE
HONE
NOTE: If the battery is not properly installed in the handset, or
if the battery pack is not properly connected to the jack inside
the battery compartment. "NO BATTERY" shows in the display
when the handset is placed in the charging cradle.
IMPORTANT: After you place the handset in the cradle the
display shows "CHARGING...", then, "SEARCHING...", then
"HANDSET NEEDS REGISTRATION" alternately. Wait until the
handset charges properly, then register the handset to the base as
described below.
P T
ROGRAMMING THE ELEPHONE
NOTE: The 25832 accessory handset is equipped with only basic
features and does not have any answering features even when
registered to Model 25833.
G
UIDELINES
H R
ANDSET EGISTRATION
Registration links the base to a cordless handset. Once a handset is
registered it can use the base's phone connection. A cordless
handset will not operate until it is registered to the base. During the
registration process, keep the handset near the base.
NOTE: This extra handset is only compatible with the GE
Models 25831, 25833, or 25835 series.
When your handset displays:
HANDSET NEEDS
REGISTRATION
B
ATTERY
1. Press the MUTE/PROG button and HOLD BASE PAGE WAIT FOR
BEEP shows in the display.
HOLD BASE PAGE
WAIT FOR BEEP
2. Press and hold the PAGE button on the base of Models 25831,
25833, or 25835 until you hear a long beep. The handset displays
HANDSET # REGISTERED followed by HANDSET NAME .
HANDSET #
REGISTERED
HANDSET NAME
3. The handset number (1 to 4) is assigned. You may also give the
handset a specific identifying name.
H N
ANDSET AME
1. Use the touch-tone keypad to enter the name (up to 15 characters).
More than one letter is stored in each of the number keys. For
example, to enter the name Bill Smith, press the 2 key twice for
the letter B. Briefly pause and the cursor moves to the next field.
Press the 4 key 3 times for the letter I. Briefly pause and the cursor
moves to the next field. Press the 5 key 3 times for the second
letter L. Briefly pause and the cursor moves to the next field. Press
the 5 key 3 times for the second letter L, press 1 key to add a
space between the first and last name. Press the 7 key 4 times for
the letter S. Briefly pause and the cursor moves to the next field.
Press the 6 key once for the letter M. Briefly pause and the cursor
moves to the next field. Press the 4 key 3 times for the letter I.
Briefly pause and the cursor moves to the next field. Press the 8
key for the letter T. Briefly pause and the cursor moves to the next
field. Press the 4 key twice for the letter H.
NOTE: If you make a mistake press the DELETE button to
backspace and erase the wrong character(s).
NOTE: Press MUTE/PROG button once to skip this step and
exit to standby screen.
2. Press the MUTE/PROG button to save. You will hear a
confirmation tone, and the display returns to the main menu.
H D -
ANDSET E REGISTRATION
Deregistration cancels a handset's registration. If you do not know a
handset's name, you should deregister the handset according to the
steps below. During the de-registration process, keep the handset
near the base.
WARNING: It is not recommended that a handset be de-
registered unless absolutely necessary because once a
handset is de-registered, that handset's telephone features
cannot be used until the handset is re-registered.
1. Make sure your handset is OFF (not in talk mode).
2. Press the MUTE/PROG button to display main menus: ROOM
MONITOR and HANDSET SETUP .
3. Use CALLER ID/VOL - button to locate to HANDSET SETUP and
then press MUTE/PROG button to select.
4. Use CALLER ID/VOL - / + button to locate the DEREGISTRATION
and then press MUTE/PROG button to select.
5. Then, handset shows DEREGISTRATION 1 YES 2NO in the display.
