2. Connection and Change IP Address of APBX

2.1 Connection

The default IP address of APBX is:
WAN: 192.168.1.100/255.255.255.0
LAN: 192.168.10.1/255.255.255.0
There are two network interfaces (WAM and LAN) in IP08, it can be used as a router (WAN port connects Internet
and LAN port connects local network):
Ext:6001
192.168.10.3 Ext:6002
192.168.10.4
If you do not want APBX to act as a router and put it behind a router, please connect WAN port to your local network:
WAN
192.168.1.100
4
LAN
192.168.10.1
Ext:6003
192.168.10.5 Ext:6004
192.168.10.6
192.168.1.3
192.168.1.5
Ext:6002
192.168.1.4
DDNS
VLAN
PPPoE
Port Forward
WAN
tpcard.vicp.cc
Ext:6005
192.168.10.7
Ext:6005
Ext:6003
192.168.1.7
Ext:6004
192.168.1.6
Internet
IVSP
Ext:6006
Internet
