InSinkErator C1300 Specifications & Dimensions

PROJECT:
APPLICATION: Designed for large volume usage of steaming hot water. Up to 100 cups of 200° hot water per hour are provided by
the system's 2/3-gallon tank. Saves time, work and water – you only heat the water you use.
FEATURES
• Foodservice grade heating element provides 100 cups
of near-boiling water per hour
• Swiveling gooseneck spout travels 90° to provide
clearance for large vessels
• Easy-action lever with automatic shut-off
• Durable all brass faucet with polished chrome finish
• 2/3-gallon Stainless Steel Tank construction for
longer life
• Easy-to-adjust temperature control on front panel
• Mounts in standard sink opening or 1-1/4" drilled hole
• Tool-free tank connections and dry start protection
for easy installation
• 1-year full warranty on parts and labor

SPECIFICATIONS

Capacity 2/3-gallon tank dispenses 100 cups
of 200ºF water per hour
Electrical
120 Volts A.C., 1300 Watts, 10.8 amp
heating element with 36" cord and
grounded plug
Thermostat
Snap action, adjustable from
160°F to 210ºF (factory pre-set
at approximately 200°F)
Insulation
Meets U.L. 94HF-1
flammability specification
Valve Instant, self-closing
Recommended 30-125 psi
Supply Pressure
Shipping Weight Approximately 11.5 lbs.
To ensure optimum performance, maximum distance
between tank and base of faucet should be 14-1/2"
or less.
Our products appear on The KCL
CADalog CD-ROM based CAD
Foodservice Symbol Library. More
information is available from Kochman
Consultants, Ltd. at www.kclcad.com.
1.800.845.8345
www.insinkerator.com/foodservice
F294-12B-45-02 | Printed in U.S.A.
MODEL C1300
Hot Water Dispenser
discretion, without notice or obligation and further reserves the right to change or discontinue models.
DIMENSIONS
5-1/2"
9-7/8"
1-1/4"
7"
1-1/2"
Hole
14-1/2" Max
Inlet
Tube
Unit Depth
11"
6-3/4" Max
The Emerson logo is a trademark and a service mark of Emerson Electric Co.
InSinkErator may make improvements and/or changes in the specifications at any time, in its sole
©2012 InSinkErator, a business unit of Emerson Electric Co. All Rights Reserved.
ITEM NO.:
4-3/8"
Min.
3" Max.
to
Material Thickness
Flexible
Outlet Tube
1/4" Incoming
Water Supply
Flexible
Vent Tube
2/3 Gallon Tank
(2.5 Liters)
Adjustable
Thermostat
6-1/8"
Drain Plug
