LM35 AND LM45 LAMINATORS
FROM SERIAL NO A670945 (LM45)
FROM SERIAL NO A671035 (LM35)
ILLUSTRATED PARTS LISTS
SERVICE INSTRUCTIONS
Compiled by David Bird
Approved by Paul Aries
AND
(Technical Manager)
Issue No 4
Date 01/07/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM35 and is the answer not in the manual?

Questions and answers

Related Manuals for Rexel LM35

Summary of Contents for Rexel LM35

  • Page 1 LM35 AND LM45 LAMINATORS FROM SERIAL NO A670945 (LM45) FROM SERIAL NO A671035 (LM35) ILLUSTRATED PARTS LISTS SERVICE INSTRUCTIONS Compiled by David Bird Issue No 4 Approved by Paul Aries (Technical Manager) Date 01/07/02...
  • Page 2 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS TABLE OF CONTENTS ILLUSTRATED PARTS MANUAL LM35 AND LM45 LAMINATORS Preface Page 2 Illustrations and Parts Lists with Recommended Spares Pages 3 – 8 Mouldings Page 3 – 4 Head Page 5 – 6 Electrics Page 7 –...
  • Page 3 Details of replacement parts and ordering information are given in associated illustrated parts list. For operating instructions see OI-477-07-96 and laminator carrier instructions see OI-521-07- 97 for both LM35 and LM45. Illustrated Parts Lists For each machine, these give full details of the replacement part numbers with supporting diagrams to show the location of the components.
  • Page 4 Main Lid D50506 Paper Support D50507 Keypad Cover D50508 Pcb Cover Plate D000332 Keypad Decal D000349 LM35 Model No. Decal NOT SHOWN D000350 LM45 Model No. Decal NOT SHOWN SL18-294 Rubber Feet SCR714 M4 X 12 Plasform Pan Head Screw SCR713...
  • Page 7 Drive Roller Shaft Assembly A50617 Drive Roller Shaft Assembly Pressure Bar Support Clip Blanket Retaining Clips 5mm D50591 Top Backing Plate (2mm) Not used on LM35, replaced with Pressure D50608 Pressure Bar TRU 85 Grip Washer A50622 SPARES HEAD ASSEMBLY...
  • Page 8 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS HEAD 25, 35 Rexel Business Machines, Westbank, Droitwich Spa, Worcestershire. WR9 9AP England Tel: +44 (0) 1905 771555 Fax: +44 (0) 1905 823374...
  • Page 9 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS ELECTRICS PART DESCRIPTION COMMENT D50535 Switch Blanking Plate D50511 Keypad D50519 Keypad A50620 LM35/45 Heater Assembly NOT SHOWN comprising 15-19, 22-25 plus heads 5- 9, 21,22. SL17-508 Control Pcb SL17-309 Control Pcb SL20-267 Motor...
  • Page 11 Release three push fit connectors from the PCB (1 x 2 way-- thermistor, 1 x 2 way mains and 1 x 4 way heater/motor (LM35), 1 x 3 way heater and 1 x 2 way motor (LM45)) and put aside the pushbutton actuators.
  • Page 12 Locate and unfasten two M3 screws, with Nyloc nuts, holding the motor to the side frame. Note the position of the spacers. Remove two motor wires from the four way connector (LM35) and the two way connector (LM45) by depressing the exposed metal pin with a sharp object, such as a small screwdriver.
  • Page 13 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS SECTION 5 Removal and Replacement of Gears Remove head unit from casing as explained in Section 1, 2 & 3. Remove circlips of gears needing to be replaced (note, there is no groove for the clips), and take off the gears.
  • Page 14 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS Pull sideframes apart to release the rollers, with their bearings, as well as the heater assemblies. RE-ASSEMBLY Replace rollers and/or ball bearings as necessary. Fit re-used bearings to new rollers or vice versa One recommended method of re-assembly, is firstly to fit rollers with bearings to ‘gear-end’...
  • Page 15 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS To reassemble, fit frame back on to rollers/bearings, paying particular attention to locating the heater assemblies properly (refer section 7). Fit and connect up lever arms and springs, replace idler gear and thermal fuse.
  • Page 16 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS SECTION 11 Removal and Replacement of Main Lid Unclip main lid from front shelf by pushing in firmly.from the sides, slightly deflecting the middle of the lid. Replace the lid by aligning its hinge pegs with holes in the front shelf and pushing into place.
  • Page 17 LM35, LM45 LAMINATORS SECTION 13 Replacement of Keypad Cover -- LM45 only THE KEYPAD COVER ON THE LM35 IS FIXED INTO POSITION AND SHOULD NOT BE REMOVED. The keypad cover is secured to the front shelf by two side fixing/hinge pegs which clip into two holes.

  • Page 18: Specifications

    ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS SPECIFICATIONS LM35/LM45 Power Supply 220/240v 50HZ Height mm 113.4 Width mm Depth mm 324.2 Weight kg 0.42W (LM35) Motor Power W (LM45) Pouch size (max) 0.5m/min (LM35) Feed Rate 0.5m/min to 1.0/min (LM45) Maximum Pouch Thickness 500 micron Rexel Business Machines, Westbank, Droitwich Spa, Worcestershire.
  • Page 21 ILLUSTRATED PARTS MANUAL LM35, LM45 LAMINATORS AMENDMENT RECORD SHEET ISSUE NO DECRIPTION CARO No Original Not recorded PCB and Heater Assemblies now being supplied from a single source resulting in changed work procedures affecting servicing procedures. Rexel Business Machines, Westbank, Droitwich Spa, Worcestershire. WR9 9AP England...

This manual is also suitable for:

Lm45
