- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. GE ZBD7100G05SS Owner's Manual Shop genuine replacement parts for GE ZBD7100G05SS Find Your GE Dishwasher Parts - Select From 6722 Models -------- Manual continues below --------...
- Page 2 Owner’s Manual Dishwasher ZBD6400 ZBD6500 ZBD6600 ZBD6700 ZBD6900 ZBD7000 ZBD7100...
-
Page 3: Table Of Contents
Consumer Information Dishwasher Introduction Your new Monogram dishwasher makes an eloquent statement of style, convenience and kitchen planning flexibility. Whether you chose it for its purity of design, practical features or assiduous attention to detail—or for all of these reasons—you’ll find that your Monogram dishwasher’s superior blend of form and function will delight you for years to come. -
Page 4: Consumer Information
1 Factory Lane, Suite 310 In most cases, this will solve the problem. Moncton, N.B. E1C 9M3 NEXT, if you are still not pleased, write all the details—including your phone number—to: Manager, Customer Relations GE Appliances Appliance Park Louisville, KY 40225... -
Page 5: Safety Instructions
Before You Throw Away Your Old Dishwasher: •Take off the door of the washing compartment or remove the door latch keeper (as shown). AVERTISSEMENT! RISQUE D’ENFANT MIS AU PIÈGE BONNE DISPOSITION DU LAVE-VAISSELLE Les machines à laver la vaisselle abandonnée ou jetée sont dangereuses...même si elles sont... -
Page 6: Water Heater Safety
WATER HEATER SAFETY Under certain conditions hydrogen gas may be If the hot water has not been used for two produced in a water heater that has not been weeks or more, prevent the possibility of used for two weeks or more. HYDROGEN damage or injury by turning on all hot water GAS IS EXPLOSIVE. -
Page 7: Proper Installation And Maintenance
IMPORTANT SAFETY INSTRUCTIONS MESURES DE SÉCURITÉ IMPORTANTES PROPER INSTALLATION AND MAINTENANCE This dishwasher must be properly installed and •Dispose of discarded appliances and shipping located in accordance with the Installation or packing material properly. Instructions before it is used. If you did not •Do not attempt to repair or replace any part receive an Installation Instructions sheet with of your dishwasher unless it is specifically... -
Page 8: Conservez Ces Directives
WHEN USING YOUR DISHWASHER Use this appliance only for its intended •Non-Dishware Items: Do not wash items such purpose as described in this Owner’s Manual. as electronic air cleaner filters, furnace filters and paint brushes in your dishwasher. Damage CAUTION: to dishwasher and discoloration or staining of Contents washed dishwasher may result. -
Page 9: Operating Instructions
Control Panel — ZBD6400 & ZBD6500 Dishwasher You can locate ZBD6400 & ZBD6500 your model number on the inside upper tub flange. Throughout this manual, features and appearance Cycle Selections may var y from your model. This display tells you what is happening while the dishwasher is in operation. 1. - Page 10 Control Panel/Operation — ZBD6400 & ZBD6500 Dishwasher 3. HEATED DRY— When selected, turns the drying heater and fan on for fast drying. This option will extend the cycle by 30 minutes. When this is NOT selected, the fan will turn on to dry your dishes without added heat—and energy is saved. HEATED DRY is not available on RINSE ONLY.
-
Page 11: Control Panel And Settings For Zbd6600
Control Panel — ZBD6600 Dishwasher You can locate ZBD6600 your model number on the inside upper tub flange. Throughout this manual, features and appearance may var y from your model. 1. WASH CYCLES Knob—Use to select the desired wash cycle based on dishware and soil level. Control Settings POTS &... - Page 12 Operation — ZBD6600 Dishwasher Start a To start the dishwasher, close the door until it locks in place. To start the last selected cycle, press the START button. To select a different cycle, turn the knobs to the desired WASH CYCLE and wash load HEAT OPTIONS and press the START button.
-
Page 13: Zbd6700 And Zbd6900
Control Panel — ZBD6700 & ZBD6900 Dishwasher You can locate ZBD6700 & ZBD6900 your model number on the inside upper tub flange. Throughout this manual, features and appearance Cycle Selections may var y from your model. This display tells you what is happening while the dishwasher is in operation. 1. - Page 14 Control Panel/Operation — ZBD6700 & ZBD6900 Dishwasher 3. SMART DRY— When selected, sensors detect the presence of rinse aid and the final rinse temperature. The drying heater and fan are then turned on for the minimum time to achieve optimum drying results. This saves energy as compared to conventional heated dry and saves time as compared to non-heated dry.
-
Page 15: Zbd7000 And Zbd7100
Control Panel — ZBD7000 & ZBD7100 Dishwasher You can locate ZBD7000 & ZBD7100 your model number on the inside upper tub flange. Throughout this manual, features and appearance may var y from your model. 1. Cycle Selections—The light on the selected pad will illuminate to indicate which cycle has been Control selected. - Page 16 Control Panel/Operation — ZBD7000 & ZBD7100 Dishwasher 4. DELAY START—This option will allow you to delay the start time of any wash cycle except Control RINSE ONLY for up to 6 hours. Settings • Select the delay start time you want by pressing the DELAY START button. Multiple pressing will alternate the delay time between 2, 4 or 6 hours and OFF.
-
Page 17: Clean Sensor
Features — ZBD6400, ZBD6500, ZBD6700, ZBD6900, ZBD7000 & ZBD7100 Dishwasher The Clean Sensor monitors the circulating water during the cycles and sets the water temperature Clean and cycle length to match soil levels. Cycle length is automatically increased to handle increasing Sensor levels of soil. -
Page 18: Using The Dishwasher
Using the dishwasher Dishwasher The entering water must be at least 120°F nearest the dishwasher, place the thermometer Water (49°C) and not more than 150°F (66°C), for in a glass and let the water run continuously into Temperature effective cleaning and to prevent dish damage. the glass until the temperature stops rising. -
Page 19: Loading The Racks
Loading the Racks Dishwasher Upper Rack The upper rack is for glasses, cups, bowls and saucers. Fold-down cup rack Cups and glasses fit best along the sides. This is also a can support extra cup secure place for dishwasher-safe plastics. The cup shelf may be placed in the up or down position to add flexibility. -
Page 20: Silverware Basket
Features and appearance of racks and silverware baskets may vary from your model. Silverware Put flatware in the removable basket with fork and knife handles up to protect your hands. Place spoons in the basket with handles down. Mix knives, forks and spoons so they don’t nest together. Basket Distribute evenly. -
Page 21: Care And Cleaning
Use stainless steel cleaner on stainless steel panel. You can order Stainless Steel Magic # WX10X15 through GE Parts in the USA, by calling 800.626.2002. In Canada, call 1.888.880.3030. The stainless steel tub can be cleaned with Stainless Steel Magic or a similar product using Interior a clean, soft cloth. - Page 22 Periodically, remove and clean the spray arms Removing to make sure that none of the nozzles have Pull up to remove and Cleaning become blocked. the Spray To remove the lower spray arm, grasp the Arms and center of the spray arm and pull upwards, it Glass Trap will unclip.
- Page 23 Care and Cleaning Dishwasher In addition to the glass trap, your dishwasher The Wash has three fine filters— Filters • a two piece round perforated stainless steel filter located in the base of the dishwasher. • a finer micro-mesh filter located under the stainless steel filter.
-
Page 24: Optional Accessories
Care and Cleaning/Optional Accessories Dishwasher For best performance, check the water fill level of your Water Fill dishwasher. Level Once the dishwasher is fully connected, run it through a Maximum level Minimum level complete RINSE ONLY cycle to ensure it is emptying and filling correctly. -
Page 25: Before You Call For Service
Before You Call For Service Dishwasher PROBLEM POSSIBLE CAUSE WHAT TO DO Questions? Use this Dishwasher will not run Door not properly closed • Press door until it clicks shut. problem Door is opened during • Relatch door. Wait a few minutes; the cycle when the water dishwasher will restart automatically after solver... - Page 26 PROBLEM POSSIBLE CAUSE WHAT TO DO Questions? Use this Suds in the tub Correct detergent • Use only automatic dishwasher detergents was not used to avoid sudsing. problem • To remove suds from the tub, open the solver dishwasher and let suds evaporate. Add 1 gallon of cold water to the tub.
- Page 27 Before You Call For Service Dishwasher Questions? PROBLEM POSSIBLE CAUSE WHAT TO DO Use this Spots and filming on Extremely hard water • Use a rinse agent to reduce spots glasses and flatware and prevent new film buildup. problem Low inlet water •...
- Page 28 PROBLEM POSSIBLE CAUSE WHAT TO DO Questions? Dishwasher won’t start Door not properly closed • Press door until it clicks shut. Use this Door opened during cycle • Re-latch door. Wait a few minutes. problem when water is hot Dishwasher will restart automatically. solver Child Lockout mode is •...
-
Page 29: Consumer Services
800.626.2000 Service Contracts You can have the secure feeling that GE Consumer Service will still be there after your warranty expires. Purchase a GE contract while your warranty is still in effect and you’ll receive a substantial discount. With a multiple-year contract, you’re assured of future In the USA: service at today’s prices. -
Page 30: Warranty For Customers In The Usa
Any part of the dishwasher which fails due to a defect in materials or workmanship. During this COVERED full one-year warranty, GE will also provide, free of charge, all labor and in-home service to From the Date replace the defective part. -
Page 31: Warranty For Customers In Canada
Any part of the dishwasher which fails due to a defect in materials or workmanship. During this COVERED full one-year warranty, GE will also provide, free of charge, all labor and in-home service to replace the defective part. From the Date... -
Page 32: Appliance Registration
Place 1st Class Letter Stamp Here General Electric Company Warranty Registration Department P.O. Box 32150 Louisville, KY 40232-2150... - Page 33 Consumer Product Ownership Registration Dear Customer: Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer! Follow these three steps to protect your new appliance investment: Complete and mail After completing this Read your “Owner’s...
