Preparing the Opener

For left hand side installations
the wire jumper should be removed.

Attaching the Extension Poles (if required)

• Insert the extension poles into the gear.
• Align the extension pole holes with the gear holes.
• Using the supplied screws secure the extension poles.
Place the Opener in Manual Release mode.
• Pull the release cord down and across to
engage the ball into the cup.
The drive forks should now be able to be
moved manually.
NOTE: To re-engage the opener, pull the
release cord across and up.

Set Opener Position (Left or Right hand)

5
For right hand side installations
the wire jumper should be in place
(factory installed).
Engaged
Operation Mode Manual Release Mode
Disengaged
