Intergraph S1832DL Tiger 100 System Board Manual page 7

Physical Dimensions
BIOS Information
Disk Drive & System I/O
Warranty
http://www.tyan.com
•
One shared, seven usable slots.
•
ATX design.
•
12 inches x 9.8 inches.
•
Requires Intel Venus compatible I/O
shield.
•
AMI Plug and Play flash BIOS.
•
Deep Green, Energy Star, ACPI,
Year 2000, and PC98 compliant.
•
Soft power-down, multiple boot
options.
•
Win98/NT5 ready, DMI 2.0
compliant.
•
PCI 2.1, APM 1.1 compliant.
•
Two PCI bus mastering EIDE
channels.
•
Supports EIDE CD-ROMs.
•
PIO Mode 3 & 4 (up to 17MB/sec
DTR).
•
UltraDMA/33 bus mastering mode
(up to 33MB/sec DTR).
•
Support for two floppy drives (up to
2.88MB).
•
Two serial ports (16550 UARTs).
•
One ECP/EPP parallel port.
•
One IR (InfraRed) I/O interface port.
•
Two USB rev 1.2 (universal serial
bus) connectors.
•
One PS/2 mouse connector.
•
One PS/2 keyboard connector.
•
3 year manufacturer's warranty.
7
