- 1 Table of Contents
- 2 Warning Decal Placement
- 3 Important Precautions
- 4 Before You Begin
- 5 Assembly
- 6 Operation and Adjustment
- 7 How to Fold and Move the Treadmill
- 8 Troubleshooting
- 9 Exercise Guidelines
- 10 Part List
- 11 Exploded Drawing
- 12 Ordering Replacement Parts
- 13 Limited Warranty
- Download this manual
www.imagefitness.com
Model No. IMTL29212.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-800-753-4645
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.imagefitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for Image Fitness 10.0 Dlx Treadmill
Summary of Contents for Image Fitness 10.0 Dlx Treadmill
- Page 1 www.imagefitness.com Model No. IMTL29212.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care. IMPORTANT: Please register this product (see the limited warranty on the back cover of this manual)
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 20. The heart rate monitor is not a medical 24. Do not change the incline of the treadmill by device. Various factors, including the user’s placing objects under the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.
-
Page 5: Before You Begin
10.0 DLX reading this manual, please see the front cover of this ® treadmill. The 10.0 DLX treadmill offers a selection of manual. To help us assist you, note the product model features designed to make your workouts at home number and serial number before contacting us. -
Page 6: Assembly
ASSEMBLY To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. After shipping, there may be an oily substance on the exte- rior of the treadmill. - Page 7 1. With the help of a second person, carefully tip the treadmill onto its side. Unfold the Frame (51) away from the Uprights (53, 54). Orient the Base (52) as shown. Attach the Base to the Left Upright (53) and the Right Upright (54) with four M10 x 58mm Bolts (2) and four M10 Nuts (73).
- Page 8 3. Set the Right Handrail (33) on the console assembly. Make sure that the console wire is Wire Tie not pinched. Remove the tie from the bracket Console Wire on the Right Handrail. If necessary, press the Cage Nuts (94) back into place. Start an M5 x 16mm Screw (85) with an M5 Star Washer (7) into the Right Handrail, and Bracket...
- Page 9 6. Start an M8 x 15mm Bolt (8) with an M8 Star Washer (5) into each Upright (53, 54). Then, firmly tighten all six M8 x 15mm Bolts (8). 7. Attach the Latch Housing (48) to the Left Upright (53) with two M4.2 x 18mm Screws (58); start both Screws, and then tighten them.
-
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit. - Page 11 CONSOLE DIAGRAM Clip FEATURES OF THE CONSOLE To turn on the power, see page 12. To use the man- ual mode, see page 12. To use a preset workout, see page 13. To change the incline of the treadmill, The treadmill console offers a selection of features designed to make your workouts more effective.
- Page 12 HOW TO TURN ON THE POWER 3. Start the walking belt. IMPORTANT: If the treadmill has been exposed to To start the walking belt, press the Start button or cold temperatures, allow it to warm to room tem- the Speed increase button. The walking belt will perature before you turn on the power.
- Page 13 The lower right dis- If the displayed heart rate appears to be too high play—The lower right or too low, or if your heart rate is not displayed, lift display can show the your thumb for a few seconds, and then reposition speed of the walking your thumb on the heart rate monitor.
- Page 14 3. Start the walking belt. HOW TO CHANGE THE INCLINE OF THE TREADMILL Press the Start button or the Speed increase button To vary the intensity of your exercise, you can change to start the workout. When you press the button, the incline of the treadmill.
-
Page 15: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Remove the key and unplug the power cord. Before moving the treadmill, fold it as described at the CAUTION: You must be able to safely lift 45 lbs. (20 left. -
Page 16: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by follow- SYMPTOM: The displays of the console do not ing the simple steps below. Find the symptom that function properly applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. a. - Page 17 SYMPTOM: The walking belt slows when walked on of a turn; if the walking belt has shifted to the right, turn the left idler roller screw counterclock- a. Use only a surge suppressor that meets all of the wise 1/2 of a turn. Be careful not to overtighten the specifications described on page 10.
-
Page 18: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 19: Part List
PART LIST Model No. IMTL29212.0 R0912A Key No. Qty. Description Key No. Qty. Description M10 x 110mm Bolt Frame M10 x 58mm Bolt Base M4.2 x 13mm Tek Screw Left Upright M4.2 x 16mm Screw Right Upright M8 Star Washer Idler Roller Warning Decal Motor Belt... -
Page 20: Exploded Drawing
EXPLODED DRAWING A Model No. IMTL29212.0 R0912A... - Page 21 EXPLODED DRAWING B Model No. IMTL29212.0 R0912A 42 21...
- Page 22 EXPLODED DRAWING C Model No. IMTL29212.0 R0912A 43 43...
- Page 23 EXPLODED DRAWING D Model No. IMTL29212.0 R0912A...
-
Page 24: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
