Jenn-Air CVEX4100 Dimension Manual

20" (50.8 CM), 30" (76.2 CM) AND 43" (109.2 CM)
ELECTRIC DOWNDRAFT COOKTOP
PRODUCT MODEL NUMBERS
CVEX4100 CVEX4270
ELECTRICAL REQUIREMENTS:
Before You Make the Electrical Connection:
A 4-wire or 3-wire, single phase, 120/240 volt, 60 Hz., AC only electrical supply is
required on a separate, 40-amp circuit (30" [76.2 cm] models), 20-amp circuit
(20" [50.8 cm] models) or 60-amp circuit (45" [114.3 cm] models), fused on both
sides of the line.
PRODUCT DIMENSIONS
20" (50.8 cm) Single Cartridge Cooktop
A
A. 19¼" (48.9 cm)
B. 21 " (53.6 cm)
C. Grease container
D. Blower
A
G
F
A. Side clearance - See *NOTE.
B. 4¾" (12.0 cm)
C. 6¼" (15.9 cm)
D. Grease container
E. 2" (5.0 cm) min. to cabinet,
6" (15.2 cm) recommended to motor service
F. 12½" (31.8 cm)
G. 17½" (44.5 cm)
*NOTE: Grills installed near a side wall must allow a minimum clearance of 6"
(15.2 cm) between cooktop and sidewall for maximum performance. Minimum
clearance of 1" (2.5 cm) is required to sidewalls and
**A minimum clearance of 6 " (15.9 cm) is recommended for removal of the
grease filter(s). Installed dimension for the grease filter(s) is 5 " (14.0 cm).
**A minimum clearance of 2" (5.1 cm) is required between the blower motor and
cabinet for proper cooling. A clearance of 6" (15.2 cm) is recommended to allow
for blower motor service.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
CVEX4370
B
C
D
B
C*
D
E**
" (1.9 cm) to rear wall.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
30" (76.2 cm) Double Cartridge Cooktop
A
A. 30
B. 21 " (53.6 cm)
C. Grease container
D. Blower
A
H
D
G
A. Side clearance - See *NOTE.
B. 4¾" (12.0 cm)
C. 6¼" (15.9 cm)
D. Grease containers
E. 2" (5.0 cm) min. to cabinet,
6" (15.2 cm) recommended to motor service
*NOTE: Grills installed near a side wall must allow a minimum clearance of 6"
(15.2 cm) between cooktop and sidewall for maximum performance. Minimum
clearance of 1" (2.5 cm) is required to sidewalls and " (1.9 cm) to rear wall.
**A minimum clearance of 6 " (15.9 cm) is recommended for removal of the grease
filter(s). Installed dimension for the grease filter(s) is 5 " (14.0 cm).
**A minimum clearance of 2" (5.1 cm) is required between the blower motor and cabinet
for proper cooling. A clearance of 6" (15.2 cm) is recommended to allow for blower
motor service.
43" (109.2 cm) Triple Cartridge Cooktop
A
A. 42
B. 21 " (53.6 cm)
C. Grease container
D. Blower
B
C
D
" (78.6 cm)
B
C*
D
E**
F
F. 12½" (31.8 cm)
G. 11 " (29.1 cm)
H. 17½" (44.5 cm)
B
C
D
" (108.2 cm)
Ref. W10421939B
Page 1 of 2
8/7/12
