Di VC USD for Nikon & Canon (Model A007)
Di USD for Sony (models without the VC) (Model A007)
Thank you for purchasing the Tamron lens as the latest addition to your photographic
equipment. Before using your new lens, please read the contents of this Owner's Manual
thoroughly to familiarize yourself with your lens and the proper photographing
techniques for creating the highest quality images possible. With proper handling and
care, your Tamron lens will give you many years of photographing beautiful and exciting
pictures.
NOMENCLATURE (Refer to Fig. 1, if not specified)
2. Hood attaching alignment mark
3. Hood attaching indicator
4. Filter ring
5. Hood attaching bayonet ring
6. Focusing ring
7. Distance scale
8. Distance index
10. Focal length scale
11. Zoom lock switch (Figs. 3 & 4)
12. VC (Vibration Compensation) Switch
13. AF/MF switch (Figs. 5 & 6)
14. Zoom index mark
15. Lens attachment mark
16. Lens mount/Lens mount contacts

SPECIFICATIONS

Focal Length
Maximum Aperture
Angle of View
Lens Construction
Minimum Focus Distance
Maximum Magnification Ratio
Filter Size
Length/Overall Length*
Diameter
Weight
Lens Hood
*Values are specifications of Nikon products. Length: From the lens front extremity to
the mount surface. Overall length: From the lens front extremity to the rear projection
extremity. Features and appearance of lenses listed in this owner's manual are subject to
change without notice.
SP 24-70mm F/2.8
SP 24-70mm F/2.8
A007
24-70mm
F/2.8
84º 04' - 34º 21'
12/17
0.38m (14.9")
1:5 (at 70mm)
82mm
108.5mm (4.3") / 116.9mm (4.6")*
88.2mm (3.5")
822 g (29oz)
HA007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A007 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tamron A007

  • Page 1 SP 24-70mm F/2.8 Di USD for Sony (models without the VC) (Model A007) Thank you for purchasing the Tamron lens as the latest addition to your photographic equipment. Before using your new lens, please read the contents of this Owner’s Manual thoroughly to familiarize yourself with your lens and the proper photographing techniques for creating the highest quality images possible.
  • Page 3 Press the shutter button further to photograph. • Using the full-time manual function? A007 is equipped with the full-time manual function. The full-time manual function is a function that the focus can be fine-tuned by the manual focus without switching the AF/MF changing switch when taking a picture of auto focus.
  • Page 4 • At infinity, make sure the image in the viewfinder appears sharp. The infinity position is made with certain allowances to insure proper focus under a variety of conditions. • For further details, please read the instruction manual of your camera. VC MECHANISM (Ref.
  • Page 5 (Fig. 9) and then rotate it clockwise to secure. The lens hood will be secure when the mark “TAMRON O” is at the top (Fig. 10). When attaching the lens hood, hold the focus and zoom control rings, so they are not rotated unintentionally.
  • Page 6 -The Tamron lenses described here employ an internal focusing (IF) system. Because of the characteristics of this optical design, the angles of view at distances other than infinity are wider than that of the lenses applying an ordinary focusing system.
